3 Specifications

3.1

Mechanical

The dimensions of the remote are approximately 195mm long by 48mm
wide.
The weight is approximately 78g without batteries and 112g with batteries
The body of the remote is ABS plastic in a light gray colour (Pantone Cool
Gray 3U). Being a solid colour rather than a spray finish, the remote does
not easily show small scratches or other minor damage.
A fine spark-texture finish is applied to the body of the remote. As well as a
pleasing aesthetic finish, this also provides a good grip.
Primary button functions are clearly printed onto the top of each rubber
button in highly wear-resistant ink, tested to over 100,000 operation cycles.
The buttons provide positive tactile feedback and are tested to over 100,000
operations.
The remote is rugged, capable of surviving a drop from 2m onto concrete
floor on any face.
3.2

Security

In order to deter battery theft, the battery compartment cover can be
secured by a screw. The screw is supplied fitted into the base of the remote.
In order to fit the battery cover screw:
1. Remove the battery compartment cover.
2. Remove the silver screw at the base of the remote using a 0pt
Posidrive™ screwdriver.
3. Fit the batteries and re-fit the battery cover.
4. Insert the screw into the hole in the base of the battery cover
The remote has an unobtrusive feature molded into the case to allow secure
fixing by cable lock (not supplied)
