Six Channel Audio Board - Rj-45 - Radio Systems Millenium-A Analog Console Installation And Operation Manual

Radio Systems Millenium-A Console
Jumper Programming
Input or Chassis
Ground Select
Input Ground Chassis Ground
(Default)
Mono/Stereo Select
Stereo Input (Default)
Mono Input
Channels Sensitivity Select
Loop Thru Bypass
and Mono Select
No pins strapped
Loop-Thru
Connector in Circuit
Position A and C strapped
(Pins 1/2 & 4/5 strapped)
Loop-Thru
Connector in Bypass
Position B and C strapped
(Pins 2/3 & 4/5 strapped)
Loop-Thru Connector Bypassed
and A & B Inputs in Mono
Illustration C-2

Six Channel Audio Board - RJ-45

SIX CHANNEL INPUT BOARD with RJ-45 CONNECTORS
1
IN CH IN CH IN CH
INPUT INPUT INPUT
2
1B 1A 2B
3
5
4
C B A C B A C B A
7
6
8
10
9
11
12
13
14
15
Input
Connectors
(Stereo balanced)
2
Pre Fader Audio
Loop-Thru Connectors
(Stereo unbalanced)
Post Fader Audio
Output Connectors
(Stereo unbalanced)
IN CH IN CH IN CH IN CH IN CH
INPUT INPUT INPUT INPUT INPUT
2A 3B 3A 4B 4A
C B A C B A C B A C B A
1 L+ In
1. Input or Chassis Ground Select
2 L- In
2. Input Connector
3 R+ In
3. Mono/Stereo Select
6 R- In
4. Input B Attenuator Dip
5. Input A Attenuator Dip
6. Right Channel Sensitivity Select
1 L In
7. Left Channel Sensitivity Select
2 L Out
8. Pre-Fader Audio Loop-Thru Bypass Select
3 Ground
9. Pre-Fader Audio Loop-Thru Connector
4 R Out
10. Aux. Power Supply Output
5 R In
11. Power Supply Input
9
12. Post Fader Audio Patch Point Connector
13. Mixer Control Cable DIP Socket
1 L Out
14. Mix Buses - Loop Out
2 Ground
15. Audio Ground - Loop Out
3 R Out
16. Audio Ground - Loop In
17. Mix Buses - Loop In
12
IN CH IN CH IN CH IN CH
INPUT INPUT INPUT INPUT
5B 5A 6B 6 A
C B A C B A C B A C B A C B A
Page 23
17
16
