Radio Systems Millenium-A Console
2.1

Overview

One Six Channel Control Board is provided for every six input channels. This card sends DC control voltages to the Six
Channel Audio Board that:
Select A/B Inputs
Set output bus and cue routing
Set input level attenuation
Activate muting buses
Activate timer reset bus
This information is conveyed by a 16 conductor ribbon cables; one cable for every mixing channel.
Eighteen programming straps also reside on this board at each channel position and are used to set all unique channel
and input board functions.
The board also includes a 15-pin remote control connector for each channel providing user access to all remote and
channel functions.
Programming options available for each channel include:
Remote Control Options – by channel
Remote Control Options – by input
Muting Buses – by input
Timer Reset – by input
Cue Options- by channel
Cue Options – by input
Off (ready) lamp control operations – by input
2.2

Function Programming

2.2.1

Channel Power-Up Mode

It is sometimes desirable that certain channels 'power up" in pre-set logic states. A common application for this feature is
that channel(s) associated with an automation system intended to run unattended, be set to power up with the channel
ON, and the correct input (e.g. A) and output bus (e.g. PGM) selected.
To set a channel to always power up in a specific pre-set mode - take the following steps:
1. Set the channel's buttons in the desired INPUT, OUTPUT(S) and CUE modes
2. (For power up in the ON mode) - press and hold the ON switch for 5 seconds until the ON lamp blinks
3. (For power up in the OFF mode) - press and hold the OFF switch for 5 seconds until the OFF lamp blinks
4. Repeat this procedure on each channel where a special power-up mode is desired
5. Whenever the console power is re-cycled for any reason, these/this channel will power-up in its pre-set
mode
Notes:
ON or OFF lamps blink and then extinguish to indicate that the programming is stored
When programming the ON function, the OFF lamp may also blink depending on the remote control wiring/configuration
of the OFF lamp)
The default power-up mode is Input A / PGM / no CUE / Channel OFF
Fader position will not be memorized of changed, so faders must be left at standard operating level
It is still highly recommended that a good quality UPS of at least 1.5 KVA be installed prior to the console power supply
to provide temporary back-up power as well as power line filtering

Six Channel Control Board

Page 12
