Port Triggering
Some applications require specific ports in the Router's firewall to be open for access by remote parties. Port Triggering opens up
the 'Open Ports' in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the
'Triggering Ports'.
The Router allows the remote party from the WAN side to establish new connections back to the application on the LAN side using
the 'Open Ports'. A maximum 32 entries can be configured.
To add a Trigger Port, press the Add button.
FIELD
Select an Application or Custom
Application
Trigger Port Start
Trigger Port End
Trigger Protocol
Open Port Start
Open Port End
Open Protocol
www.netcommwireless.com
A user can select a pre-configured application from the list or select the Custom Application option to
create custom application settings.
Enter the starting trigger port number (when you select Custom Application). When an application is
selected the port range values are automatically entered.
Enter the ending trigger port number (when you select Custom Application). When an application is
selected the port range values are automatically entered
Options include TCP, UDP or TCP/UDP.
Enter the starting open port number (when you select Custom Application). When an application is
selected the port range values are automatically entered.
Enter the ending open port number (when you select Custom Application). When an application is
selected the port range values are automatically entered.
Options include TCP, UDP or TCP/UDP.
DESCRIPTION
.
