Amerec 3K Series Installation And Service Instructions Manual

Possible Controls
K200i
OR
K60/KT60
OR
K30
STEAM
OR
R30K
AMEREC STEAMBATH GENERATORS
(AK,3K and K200i Compatible 9011-XXX Models)
Note: To be used with the K200i,K60,KT60,K30 or R30K
Control.

SAVE THESE INSTRUCTIONS

READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLATION.
POST "WARNING" LABEL OUTSIDE STEAMBATH FOR SAFETY
WARNINGS. REQUIRED POSTING ON DOOR OF STEAM ROOM
OR ADJACENT TO DOOR FOR ALL COMMERCIAL
INSTALLATIONS.
SECTION 1: GENERAL INFORMATION
AMEREC Steam Generators are listed by UL or NRTL Laboratory. The steam generators come assembled and
ready for installation. Check that the size and rating of the generator is suitable for your application, refer to
Steam Room Construction and Generator Sizing Guide (AMEREC document 4211-38).
IMPORTANT
An exhaust fan installed outside the steam
room is strongly recommended to remove
excess steam from the bathroom or shower
area.
4211-171 06-25-10
AK and 3K Series Installation and Service
Instructions
(K200i Compatible 9011-XXX Models)
Electrical grounding is required on
all AMEREC Steam bath Generators.
All electrical supplies should be
disconnected when servicing
All wiring must be installed by a
licensed electrical contractor in
accordance with local and national
All plumbing must be installed by a
licensed plumber in accordance with
all applicable local and national
AK GENERATOR
AK series generators are for indoor
AK series generators are not for
enclosures are properly sealed to
avoid water damage from escaping
steam. It is recommended that 100%
silicone caulk be used to seal all
pipes and fittings. Steam must be
prevented from escaping into the
Never shut off the water to a steam
Electric Shock Hazard - High voltage
exists within this equipment. There
are no user serviceable parts in this
OVERHEATING AND SCALDING
1. Exit immediately if uncomfortable, dizzy or sleepy. Staying too long in
a heated area is capable of causing overheating.
2. Supervise children at all times.
3. Check with a doctor before use if pregnant, diabetic, in poor health or
under medical care.
4. Breathing heated air in conjunction with consumption of alcohol, drugs
or medication is capable of causing unconsciousness.
CAUTION!
SLIPPING AND FALL INJURY
Use care when entering or exiting the steam room, floor may be slippery.
NOTE: For additional safety instructions, see owner's manual.
WARNING
generator.
codes.
codes.
use only.
space heating purposes.
Be certain that steam bath
wall cavity.
generator that is in use.
equipment.
WARNING
REDUCE THE RISK OF
Do not contact steam head. Stay at least 12" away
from hot steam escaping from the steam outlet.
REDUCE THE RISK OF
