- Page 1 USER MANUAL Lightdrop (AL3-Series) Manual Version: 3.2.20 Release Date: July. 23 .2010 Astera LED Technology GmbH Address : Nahestrasse 68-70, 55593 Rüdesheim an der Nahe, Germany Tel.: +49(0)6536-355361 Email: sales@astera-led.com...
-
Page 2: Table Of Contents
1 Table of Contents 1 Table of Contents..................2 2 Safety......................3 3 Specifications....................4 3.1 Technical Data....................5 4 Quick Start....................6 4.1 Overview....................6 4.2 Advantages....................7 4.3 Button and Operation..................7 5 Battery Runtime..................8 6 Troubleshooting..................9 7 Disposal....................10... -
Page 3: Safety
2 Safety Before you operate the unit, read this manual carefully. Make sure to keep the manual, in case you need to consult this manual again or you give the unit to another person. Always make sure to include this manual if you hand out the unit to another person. -
Page 4: Specifications
3 Specifications Wireless spot light, for Indoor and outdoor use Narrow light beam angle can be widened with diffuser lens Displays more than 16 million colors. Low power consumption Controllable by Radio Frequency Remote Control DMX integration via ART3 wireless DMX Transmitter 8-24 hours operation time without recharging the battery. -
Page 5: Technical Data
3.1 Technical Data Light Sources Light Sources 5mm bullet LEDs with 15 degree beam angle Amount or LEDs AL3-S: 16 (4xR, 4xG, 4xB, 4xW) AL3-M: 96 (24xR,24xG, 24xB, 24xW) LED Power AL3-S: 1.7W AL3-M: 10.2W Power Supply Power supply unit Shipping with the Lightdrop Input power AC 100-240V, 50/60Hz, 0.3A... -
Page 6: Quick Start
ARC2 remote control or the IR Remote Control. For a larger setup, AL3s can be grouped and paired with other AL3 units and other wireless Astera lamps. This can be done with the ARC2 remote control or the ART3 Wireless DMX transmitter. 4.1 Overview... -
Page 7: Advantages
ARC2 Remote Control. The AL3 can be used as a stan- dalone unit or grouped and paired with other Astera lamps and be controlled with an ARC2 RF Remote Control. -
Page 8: Battery Runtime
5 Battery Runtime The work temperature is 0~60 Celsius degree. When you switch on but it's not working and the red light is keep shining means you need recharge the battery. The LED POWER modes description: When we use maxium runtime, we setting the LED power is 50% full power, the LED •... -
Page 9: Troubleshooting
6 Troubleshooting Faulty condition Cause Troubleshooting LED no light when you switch on Due to the vast number of settings, one Set the brightness to other value. can not always predict behavior of the units, if setup was already done earlier. Units behave incorrectly Due to the vast number of settings, one Do FACTORY RESET on units and/or re-... -
Page 10: Disposal
7 Disposal Follow local ordinances and/or regulations for disposal! PACKAGING: The unit is shipped in protective packaging. This packaging can be recycled! UNIT: Don't throw the unit into the garbage at the end of its lifetime. Make sure to dispose is according to your local ordinances and/or regulations, to avoid polluting the environment! BATTERIES:... - Page 11 If discrepancies occur in the translated text, the original instruction manual has to be used to solve them tor the manufacturer has to be contacted. Astera LED Technology GmbH ©2010, All rights reserved Rüdesheim an der Nahe, Germany...
