Fd Series Scales Parts List - OHAUS FD SERIES Service Manual

ITEM NO. PART NO.
1 71172937
2 80500435
2 80500521
2 80500437
2 80500436
2 80500462
2 71143794
3 71167489
4 71168359
5 71172938
6 71172932
7 71167490
8 71158353
9 71119058
9 71123142
9 71123141
10 71172916
10 71172917
10 71172918
11 71172934
12 71172940
13 71172933
14 71169710
15 71158347
16 71158350
17 71172935
18 71167481
19 71172939
Not Shown 71172941
TABLE 5-1. FD SERIES SCALES PARTS LIST.
DESCRIPTION
Seal, Adapter & Foot Switch Socket, FD
AC Adapter, US 120 Volts, 60 Hz
AC Adapter, US 220 Volts, 60 Hz
AC Adapter, UK 230 Volts, 50 Hz
AC Adapter, EU 230 Volts, 50 Hz
AC Adapter, AU 240 Volts, 50 Hz
AC Adapter, JP 110 Volts, 50 Hz
Base Housing, FD
Rechargeable Battery Pack, FD
Battery Holder, FD
Top Housing
Pan, FD
Harness, Rechargeable Battery, FD
Load Cell, 3 kg, FD
Load Cell, 6 kg, FD
Load Cell, 15 kg, FD
Load Cell with Spiders (3 kg), FD
Load Cell with Spiders (6 kg), FD
Load Cell with Spiders (15 kg), FD
Harness, Adapter & Foot Switch, FD
Pan Support Caps, (4), FD
LFT Sealing Kit
Membrane Switch, FD
LCD Display, FD
Main PCB (with LCD), FD
Level Bubble, FD
Gasket, FD
Adjustable Feet (4), FD
Hardware Kit
5-3
CHAPTER 5 PARTS LISTS
QUANTITY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
