Summary of Contents for Nonin 9570

  • Page 1 MODEL 9570 User Guide...

  • Page 2: Table Of Contents

    Intended Use ....................4 Testing Summary ..................24 Installing the Battery..................8 Accuracy Testing ................24 Applying the GO Model 9570 to Your Finger ..........10 Pulse Rate Motion Testing ..............24 Activating the Device and Verifying Operation ..........12 Low Perfusion Testing ................24 Reading Your Results ..................13...

  • Page 3: Introduction

    (the amount of Symbol Definition of Symbol oxygen in your blood) and pulse rate at your fingertip! The Model 9570 is easy to use and needs no routine maintenance except battery replacement. This User Guide explains how to Consult Instructions for Use use and care for your GO Model 9570.
  • Page 4 Intended Use Battery Model 9570 is intended to measure blood oxygen saturation (%SpO ) (the amount of oxygen in your blood) and pulse rate of both adults and children. It is designed for fingers (not the thumb) between 0.3 and 1.0 inch (0.8 – 2.5cm) thick. The index finger Indicates separate collection for electrical and electronic equipment (WEEE).
  • Page 5 Cautions - low hemoglobin; • Do not use the GO as the only basis for making medical decisions. It is intended - arterial catheters; only to be used as additional information that you can give to your licensed - nail polish, and/or artificial nails; and health care professional.
  • Page 6 (as shown inside of the battery compartment). • Follow local disposal and recycling laws for the GO and its components, including the battery. • The GO is a precision electronic instrument and must be repaired by Nonin Technical Service.
  • Page 7 3. Carefully reposition the battery door. NOTE: Do not force it into place; it fits only Applying the GO Model 9570 to Your Finger when positioned correctly. Hold the GO with the display facing toward you; slide your finger into the opening at the bottom of the device, as shown below, until the fingertip touches the built-in stop guide.
  • Page 8 NOTE: Correct positioning of the device on your finger is critical for accurate Activating the Device and Verifying Operation measurements. While on the finger, do not press the GO against any surface and The GO automatically turns on when a finger is inserted. When a finger is inserted, do not squeeze or hold it together.
  • Page 9 Reading Your Results excessive motion. If this symbol does not turn off while your finger is in the device, reposition your finger or switch to a different finger. When you put your finger in the GO , you’ll notice an LCD display come on. The numbers you see show: Percent Oxygen Saturation Pulse Quality Indicator...
  • Page 10 Caution: Do not place the GO in liquid or clean it with agents containing ammonium chloride, isopropyl alcohol, or products that are not listed in this User’s Guide. device is on the finger). If the problem persists contact Nonin Technical Service.
  • Page 11 Possible Cause Possible Solutions Problems Possible Cause Possible Solutions Reposition finger to activate Missing segments Faulty display. Contact Nonin Technical the device. on LCD display. Service. Verify battery is correctly If the indicator is visible and inserted. Note: If battery is...

  • Page 12: Specifications

    Use the lanyard with caution. Infrared 910 nanometers @ 1.2mW For more information about Nonin parts and accessories, contact your distributor, or Max Average contact Nonin at (877) 577-2635 (USA and Canada) or (763) 553-9968.
  • Page 13 Temperature (Operating) +41°F to +104°F (5°C to +40°C) Classifications per IEC 60601-1 / CAN/CSA-C22.2 No. 601.1 / UL 60601-1 Storage/Transportation -22°F to +158°F (-30°C to +70°C) Degree of Protection Type BF-Applied Part Device temperature will not exceed 41°C as measured Enclosure Degree of Ingress Protection IP33 during a controlled environment test.

  • Page 14: Equipment Response Time

    Equipment Response Time Testing Summary accuracy and low perfusion testing were conducted by Nonin Medical, Inc., as described below: Reference 4 Beat Average Accuracy Testing accuracy testing is conducted during induced hypoxia studies on healthy, non-smoking, light- to dark- skinned subjects during motion and no-motion conditions in an independent research laboratory. The measured...

  • Page 15: Warranty

    The GO Model 9570 is warranted for Home Health Care Use Only. MPS, Medical Product Service GmbH All non-warranty work shall be done at Nonin’s standard rates and charges in effect at the Borngasse 20 time of delivery to Nonin.
  • Page 16 Please take a moment to find and record the 9-digit serial number found on the back of your GO Model 9570. You’ll need this number if you have to contact Nonin with technical service issues or if you have any questions regarding the use or performance of your pulse oximeter. Nonin’s technical service department can be reached at (877) 577-2635.
