PC1404 v1.0

Installation Guide

WARNING: This manual contains information on limitations regarding product use and function
and information on the limitations as to liability of the manufacturer. The entire manual should
be carefully read.

Advertisement

Table of Contents
loading

Related Manuals for DSC PowerSeries PC1404

Summary of Contents for DSC PowerSeries PC1404

  • Page 1: Installation Guide

    PC1404 v1.0 Installation Guide WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Important Note

    EQUIPMENT MUST BE QUICKLY DISCONNECTED. IT IS IMPERATIVE THAT ACCESS TO THE MAINS PLUG AND ASSOCI- ATED MAINS SOCKET/OUTLET IS NEVER OBSTRUCTED. IMPORTANT NOTE! equipment, alarm controller PC1404, - damage of conductor insulation. c) Disposal of used batteries shall be made in accordance with local waste recovery and recycling regulations.
  • Page 3 Smoke alarms should be installed outside of each sleeping area and on each storey of the home. DSC recommends that additional smoke alarms beyond those required for minimum protection be installed. Additional areas that should be protected include: the basement;...

  • Page 4: Limited Warranty

    Customer and a Return Merchandise Authorization number (RMA) is issued by DSC' s Customer Service. products purchased from DSC. Custom products are only warranted to the extent that they do not function upon delivery. In such cases, DSC can replace or credit at its option.

  • Page 5: Table Of Contents

    Table of Contents Safety Instructions for Service Personnel ................i 1 Introduction .
  • Page 6 1.2, 4, 7 Ah CON1 BAT+BAT- 200–350 mA Telephone line wiring For NA Use a Class 2 Transformer 16.5V 40 VA DSC PTD 1640U. installations RING RJ-31X not connect transformer to receptacle only (NA) controlled by a switch. Note: It is the installer’s responsibility...

  • Page 7: Introduction

    PC-Link header. Shown 1.1 Compatibility Requirements below are the supported and unsupported modules for the PC1404. The PC1404 product is the central component of the four-zone security system. Interaction with associated system devices is Module Current Draw, mA...

  • Page 8: Out Of The Box

    • DSC PTD1640U, DSC PTC1640U. Transformers must be Energy Efficient as per the local rules and regulations Cabinets • High-efficiency transformer for Australia Several different cabinets are available for the PC1404. They are Battery as follows: • 12V sealed lead acid battery PC5003C Cabinet •...

  • Page 9: Installation

    After you have attached the cabi- net to the wall, stick the provided DSC logo sticker on the front Feet Metres of the cabinet.

  • Page 10: Wiring Routing For Power And Non-Power Limited

    PC1404 Keybus Terminals – AUX+, AUX-, YEL, GRN be maintained at all points between power limited and non- power limited wiring and connections. The Keybus is used by the panel to communicate with modules and vice versa. Each module has four Keybus terminals that must be connected to the four Keybus terminals on the panel.

  • Page 11: Current Ratings - Modules & Accessories

    (14) and Quick Exit (16). You can change the function of each key on every keypad: In order for the PC1404 system to operate properly, the power Go to the keypad where you want to change the function output capabilities of the main control and the expansion devices key programming and enter Installer Programming.

  • Page 12: Zone Doubling

    PC1404 2.10 Zone Doubling Single End Of Line (EOL) Resistors (5600) To enable panel detection of single end of line resistors, Section Zone Doubling is a feature that will allow you to double the [013], Options [1] and [2] must be OFF.

  • Page 13: Fire Zone Wiring

    (12V , 35mA) must be entered in the location corresponding to the keypad The following CO detector models can be used with PC1404 to which each zone is connected. v1.0 and higher control panels: Example: The zone on an PK5500 keypad in Slot 8 is to be •...

  • Page 14: Keypad Commands

    3.1 Arming and Disarming For a description of basic arming and disarming, please see the PC1404 User Manual. For other methods of arming, please refer to [*][0] – Quick Arm, [*][9][User Code] – No-Entry Arming and [000] Keypad Function Programming.

  • Page 15: Led Keypad

    3 Keypad Commands ][7][x] Command Functions 1–4 ][8][Installer Code] Installer Programming ][9][User Code] No-Entry Arming ][0] Quick Arm (disarmed state)/Quick Exit (armed state) ][1] Bypassing and Activating Stay/Away and Night Zones LED Keypad Press [ ][1] to enter the bypass mode. If the Code Required for the Bypass option is enabled, enter a valid user code. The Bypass light will flash.
  • Page 16 PC1404 Light Trouble AC Failure: There is no audible annunciation on AC power failure unless trouble beeps on AC failure are enabled in Section [018] Option [8]. The system "Trouble" light will come ON but the audible indication will not sound until there is a low battery condition.

  • Page 17: Erasing An Access Code

    • Latching System Tampers • Zone Expander Supervisory Fault. PC1404 only supports one entry of Auto-Arm Time programming, which means the programmed time shall be used for every day auto arm. System Test: The system's Bell Output (2 sec), Keypad Lights and Communicator are tested. This test will also measure the panel's standby battery.

  • Page 18: Additional Keypad Functions

    When disarmed, press [ ][8][Installer Code] to enter Installer Programming. Installer Programming allows the installer to program all system functions. Refer to Section 4.1 Installer Programming for details. The PC1404 v1.00 is completely programmable from any sys- tem keypad using this command.

  • Page 19: Programming

    4 Programming 4 Programming The PC1404 can be programmed using the following methods: Programming Method Description Procedure Installer Programming Allows direct access to all programming sections. Press [ ][8][Installer’s Code] while the system is dis- armed. See 4.1 Installer Programming for details.

  • Page 20: Programming Toggle Option Selections

    PC1404 If you are using a pulse communications format, a decimal zero [0] does not transmit. Programming a zero [0] tells the panel not to send any pulses for that digit. Decimal zero [0] is a filler digit. To transmit a zero [0], it must be programmed as a Hexadecimal ‘A’.

  • Page 21: Programming Worksheets

    5 Programming Worksheets 5 Programming Worksheets 5.1 Index to Programming Worksheets and Descriptions Programming Option PWS/Desc. Programming Option PWS/Desc. [000] Keypad Function Key Programming ....16/34 [367] Opening/Closing Comm. Call Directions ..25/50 [001] Zone Definitions..........16/35 [375] System Maint. Alarm/Rest. Comm Call Dir..25/50 [005] System Times ..........

  • Page 22: Programming Worksheets

    PC1404 5.2 Programming Worksheets Keypad Partition/Slot and Function Key Programming [000] Function Key Programming Note: Keypad enrollment must be done at each keypad requiring programming. Function keys are programmable in each individual keypad. The keypad being programmed must be used to access Installer Programming, followed by Section [000] and digits 1-5 for function keys 1 to 5.

  • Page 23: System Times

    5 Programming Worksheets [005] System Times Valid entries for Entry Delay are between 030-255. Valid entries for SIA CP-01 Exit Delay are between 045-255. Default Enter 3 digits from 001-255 Subsection [01] I___I___I___I Entry Delay 1 I___I___I___I Entry Delay 2 I___I___I___I Exit Delay Subsection [09]...

  • Page 24: Pc5204 Pgm Output Programming

    PC1404 [011] PC5204 PGM Output Programming Default PGM 11 I_______I_______I PGM 12 I_______I_______I PGM 13 I_______I_______I PGM 14 I_______I_______I [012] Keypad Lockout Options Note: If Keypad Lockout is active, the panel CANNOT be disarmed with a keyswitch. Default Number of Invalid Codes Before Lockout...

  • Page 25: Fifth System Options

    5 Programming Worksheets   Keypad Backlighting Enabled  Keypad Backlighting Disabled  Power Save Mode Enabled   Power Save Mode Disabled  Bypass Status Displayed While Armed   Bypass Status Not Displayed While Armed  Keypad Tampers Enabled ...

  • Page 26: Zone Loop Response Options

    PC1404  Trouble Beeps are Silent   Trouble Beeps Sound Every 10 seconds    Keyswitch Arms In Away Mode Only Keyswitch Arms In Stay or Away Modes [030] Zone Loop Response Options Def.  Zone 1 is Fast Loop Response ...

  • Page 27: Zone Attributes

    5 Programming Worksheets Attribute:  =ON Cross Zone Attributes 10-13 for SEOL DEOL Future Use Loops Zone Type: Config. Config. Config. 00 Null Zone 01 Delay 1 02 Delay 2 03 Instant 04 Interior 05 Interior Stay/Away 06 Delay Stay/Away 07 Delay 24-hr.

  • Page 28: Cross Zone/Police Code Timer

    PC1404 [176] Cross Zone/Police Code Timer Default 060 Valid entries are 000-255 seconds/minutes I_______I_______I_______I [181] Auto-Arm Time of Day Default 99:99 Valid entries are 0000-2359 hrs, 9999 to disable I_______I_______I_______I_______I [190] No Activity Arming Pre-alert Timer Default 001 Valid entries are 001-255 minutes, 000 for no pre-alert...

  • Page 29: Priority Alarm/Restore Rep. Codes

    5 Programming Worksheets [329] Priority Alarm and Restore Reporting Codes |___|___| Keypad [F] Fire Alarm |___|___| Keypad [A] Auxiliary Alarm |___|___| Keypad [P] Panic Alarm |___|___| Auxiliary Input Alarm |___|___| Keypad [F] Fire Restore |___|___| Keypad [A] Auxiliary Restore |___|___| Keypad [P] Panic Restore |___|___| Auxiliary Input Restore...

  • Page 30: Misc. Opening (Disarming) Rep. Codes

    PC1404 [343] Opening (Disarming) Reporting Codes, Access Codes 17-32 Code 17 Code 18 Code 19 Code 20 Code 21 Code 22 Code 23 Code 24 |___|___| |___|___| |___|___| |___|___| |___|___| |___|___| |___|___| |___|___| Code 25 Code 26 Code 27 Code 28...

  • Page 31: Programming Option [367] Opening/Closing Comm. Call Directions

    5 Programming Worksheets [367] Opening/Closing Communicator Call Directions Option 1 Option 2 Option 3 Option 4 Option 5-8 First Telephone Second Telephone Third Telephone Fourth Telephone Future Use Number (Default OFF) Number (Default OFF) Number (Default OFF) Number (Default OFF) (Default OFF) ...

  • Page 32: Third Communicator Options

    PC1404  SIA Sends Programmed Reporting Codes   SIA Sends Automatic Reporting Codes    Closing Confirmation Enabled Closing Confirmation Disabled  For Future Use    Contact ID Uses Programmed Reporting Codes   Contact ID Uses Automatic Reporting Codes ...

  • Page 33: Panel Id Code

    5 Programming Worksheets [404] Panel ID Code (Enter 6 Hexadecimal Digits) Default = 140400 | _ ______| _ ______| _ ______| _ ______| _ ______| _ ______| [405] Answering Machine Double-Call Timer Default 060 Valid entries are 000-255 seconds I_______I_______I_______I [406] Number of Rings To Answer On Default 000 Valid entries are 000-255 rings...

  • Page 34: Pgm Zone Assignment

    PC1404  Not Used Not Used True Output Follows Timer Code Req. Not Used Not Used Not Used – – Inverted ON/OFF No Code Option Police Code  For Future Use Zone Follower  Status Alarm Memory  Notes: A change of default setting will NOT affect the output.

  • Page 35: Closing (Arming) Reporting Codes

    5 Programming Worksheets Section Number Output Number Zone Follower Zone PC5204 [561] PGM 11 [562] PGM 12 [563] PGM 13 [564] PGM 14 [601] Closing (Arming) Reporting Codes, Access Codes 33-40 Code 33 Code 34 Code 35 Code 36 Code 37 Code 38 Code 39 Code 40...

  • Page 36: Local Keypad Programming

    PC1404 Programming PK5500 Keypads If you have an PK5500 keypad, additional programming is required for proper operation. All LCD programming is done per keypad. If more than one LCD keypad is present on the system, labels programmed at one keypad can be broadcast to all other LCD keypads. The...

  • Page 37: Label Programming (Zones 1-8)

    Programming PK5500 Keypads [001]-[008] Zone Labels Default Z o n e _ _ _ _ 1 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Default Z o n e _ _ _ _ _ 8 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ [065] Fire Alarm Label Default...

  • Page 38: Second User Display Mask

    PC1404 [072] Second User Display Mask Def.   User Initiated Call-up prompt ON  User Initiated Call-up prompt OFF    For Future Use   Walk Test prompt ON  Walk Test prompt OFF   Command Output #1 prompt ON ...

  • Page 39: Pgm Terminal 1

    Programming PK5500 Keypads [080] PGM Terminal 1 Default |_____|_____| PGM Output Number [082] Local PGM Output Activation Time Default |_____|_____| Minutes |_____|_____| Seconds [101] Partition 1 Label Default |____|____|____|____|____|____|____|____|____|____|____|____|____|____| S y s t e m _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ |____|____|____|____|____|____|____|____|____|____|____|____|____|____| [102]–[108] Partition 2–8 Labels...

  • Page 40: Programming Descriptions

    PC1404 5.3 Programming Descriptions The following is a description of the programming features and options available in the control panel. [000] Keypad Function Programming Function Key Description [00] Null The key is not used and will perform no function when pressed.

  • Page 41: Zone Programming

    5.3 Programming Descriptions [25] Instant Stay Arming This function key was formerly used for Recall Bypass Group 2. This feature operates similarly to the stay arming function key except for the following: When this function key is pressed, no acknowledgement beeps are sounded, there is no exit delay;...
  • Page 42 PC1404 [08] Standard 24-hr Fire Zone (hardwired) Note: Do not wire Fire zones on keypad zone terminals if the DEOL supervision option is enabled for the panel (Section [013], Option [2]). This zone type requires a SEOL resistor, and it cannot be reconfigured using the NC, EOL or DEOL options in the panel. The alarm state is short, the restored state is 5k6, and an open condition will generate a zone tamper and fire trouble.
  • Page 43 5.3 Programming Descriptions A bypass of this zone type must be manually removed. With an audible alarm active, using the keyswitch when disarmed is the same as entering an access code at the keypad. Activating this zone type during the first 30 seconds of a delayed fire alarm is the same as entering an access code at the keypad (the 90 second delay will start).
  • Page 44 PC1404 [005] System Times Enter Section [005] then Subsection [01] to program the Entry Delay 1, Entry Delay 2 and Exit Delay for the system. Entries are in seconds. A value of 000 in the entry or exit delay sections causes a 255 second delay; however, the time is displayed as 000. Enter Sec- tion [005] then Subsection [09] to program the Bell Cut-Off Time.
  • Page 45 Two 2-second pauses (hex E) must be inserted at the beginning of the telephone number when using this option. Remote Operation. This output can be activated or deactivated remotely by using DSC's Downloading Software. Not Used Away Armed Status. This output will activate at the beginning of exit delay when the system is armed using away mode.
  • Page 46 PC1404 PGM Output Options Command Output #1. This output is activated by entering the [*][7][1] command. The configuration of the corresponding attributes determines how this PGM will activate. Command outputs 1-4 are user initiated by entering [*][7][1-4] at any key- pad.
  • Page 47 OFF: Audible Exit Fault is Disabled. The siren will not activate during the entry delay created by leaving a delay zone violated when exit delay expires. ON: Zone Doubling Enabled. When the Zone Doubler option is enabled on a PC1404, Zone 1 will become Zones 1 and 5, Zone Zone 2 will become Zones 2 and 6, and so on, up to 8 hardwired zones.
  • Page 48 PC1404 Exit Delay Termination Enabled. The exit delay will be reduced to 5 seconds when the system detects that a delay 1 zone has been restored during exit delay. All audible indications associated with the exit delay (keypad tones, bell squawks) will...
  • Page 49 5.3 Programming Descriptions ON: Blank Keypad When Not Used. If no keys are pressed for 30 seconds, the display and all keypad lights except Keypad backlighting (if enabled) turn OFF until the next keypress, entry delay, audible alarm, or keypad buzzer condition. Key- Blanking pad function and FAP keys still operate during keypad blanking.
  • Page 50 PC1404 ON: Cross Zoning is Enabled. The panel will use the Cross Zone attribute for Burglary Verification. This feature Cross requires two or more trips from a zone that has the Cross Zone attribute enabled within a specified time before starting an Zoning/ alarm sequence.

  • Page 51: Daylight Savings Time

    5.3 Programming Descriptions [030] Zone Loop Response Options Fast loop response for the onboard zones is programmable using Installer Programming Section [030]. Section [030] is an 8 bit toggle option that controls which main board zones will use fast loop response (~40mS) or normal loop response (~250mS). Note: Fast loop response should not be enabled for zones that are "doubled"...
  • Page 52 [181] Auto-Arm Time of Day Program the desired auto-arming time of day in military time format, HH:MM. The PC1404 will attempt to auto-arm at this time every day unless the feature is disabled in [*][6] User Functions. Valid entries are 00:00 to 23:59, 99:99 to disable.
  • Page 53 These sections determine which type of communicator is activated in the event of an alarm condition or other communicated event. The PC1404 only supports one method of communications, PSTN. GPRS and Ethernet communicators are not supported. • Entry of [D] followed by a [Telephone Number] terminated with “F” configures the section for telephone dialing.
  • Page 54 PC1404 [330]-[334] Tamper/Restore Reporting Codes, Zones 01-8 These reporting codes are used by the communicator to transmit zone tampers and restores for Zones 1 to 8. These reporting codes are sent to the Tamper Alarm & Tamper Restore call direction group of the system.
  • Page 55 5.3 Programming Descriptions Fire Trouble & Restore An open circuit or any Low Sensitivity, Tamper or Fault report from a wireless smoke detector causes this trouble to be reported. These reporting codes are sent to the System Maintenance call direction group. Auxiliary Power Supply Trouble &...
  • Page 56 PC1404 [348] Test Transmission Reporting Codes Walk Test Begin/End These reporting codes are sent when the walk test is initiated and terminated. These codes precede and terminate the alarm reporting codes for the zones that are activated during the walk test period, if the alarms are to be transmitted (Section [382] Option [2]). The walk test reporting codes are sent to the System Test Transmission call direction group.
  • Page 57 5.3 Programming Descriptions Delinquency Transmission Delay: Number of hours (Activity Delinquency) or days (Arming Delinquency) the panel delays before transmitting the event to the central station. Whether this value is in hours or days is determined if Delinquency is for Activity (Hours) or Closing (Days) as specified in Section [380] Option 8.
  • Page 58 PC1404 [381] Second Communicator Options Option Description ON: Opening After Alarm Keypad Ringback Enabled. When the Opening After Alarm reporting code is successfully Ringback transmitted to the monitoring station, the keypad sounds a series of 8 beeps to confirm to the end user that the Opening After Alarm Code was sent and received.
  • Page 59 5.3 Programming Descriptions ON: Number of Dialing Attempts is 1 for Residential Dial. If the residential dial format is programmed, the Residential Dial panel will only attempt to call the user's phone once. Regardless of whether the alarm is acknowledged by the end user by pressing a DTMF digit, the panel will not call back unless a new alarm has occurred.
  • Page 60 PC1404 ON: 300 Baud Call-up. 300 baud is the minimum baud rate used by 56K modems. When performing call-back or Baud Rate user initiated call-up with a 56K modem, this option should be enabled. Selection OFF: 110 Baud Call-up. 110 baud is the supported baud rate for the MD-12 modem. When performing call-back or user initiated call-up with an MD-12, this toggle option should be disabled.
  • Page 61 5.3 Programming Descriptions The following attributes are available for the System Trouble PGM Option [09]. System Trouble PGM (Type 09) [1] Service Required [2] A.C. Failure [3] Telephone Line Fault [4] Communications (Failure to Communicate) [5] Device (Fire) Fault / WLS Zone Supervisory Fault Enabled [6] Device Tamper—hardwired or wireless device [7] Device Low Battery—wireless device [8] Loss of Clock...
  • Page 62 PC1404 [700] Automatic Clock Adjust The value entered here adds or subtracts seconds at the end of each day to compensate for inaccuracies in the system time. Valid entries are 00-99, with 60 seconds being the default. To determine the value to be programmed in this section, perform the following: Monitor the time lost by the panel over a period of time.
  • Page 63 5.3 Programming Descriptions ON: ID Tone Enabled. After the telephone number is dialed, the panel will emit a tone (as speci- I.D. Tone fied by Option 6). OFF: ID Tone Disabled. After the telephone number is dialled, the panel will not emit an I.D. Tone. ON: 2100 Hz I.D.
  • Page 64 PC1404 [903] View Module Supervision In this mode, the system displays all of the modules presently enrolled on the system as indicated by the corresponding lights below: Indicator Light Module Keypads 1-8 PC5208 PC5204 26-29 PC520X 1-4 [990] Installer Lockout Enable If enabled, the panel gives a distinctive audible indication on power-up (the phone line relay clicks 10 times).

  • Page 65: Testing And Troubleshooting

    6 Testing & Troubleshooting 6 Testing & Troubleshooting Testing: • Power up system • Program options as required (see Section 5 Programming Worksheets) • Violate, then restore zones • Verify correct Reporting Codes are sent to the central station Troubleshooting: •...
  • Page 66 PC1404 Trouble Cause Troubleshooting PC520X Aux Power Supply Trouble • Ensure that a the power supply aux power terminal is not shorted to ground. • Ensure that the maximum power supply aux current has not been exceeded. [4] General System Tamper Tamper input on module(s) open circuit Short tamper terminal to COM terminal on unused modules connected to KEYBUS (PC5200, PC5204, PC5208, PC5601).
  • Page 67 6 Testing & Troubleshooting Trouble Cause Troubleshooting Trouble [5] Zone Fault Press [5] to determine specific zones with a Fault trouble Open circuit is present on one or more • Ensure fire zones have a 5.6K resistor (Green, Blue, fire zones on the main panel or zone Red) connected.

  • Page 68: Appendix A: Reporting Code Formats

    [344] Special Opening Opening (disarming) using one of the following methods: E(4)AA-000 OP-00 keyswitch, maintenance code, DLS software, wireless key [345]-[346] Battery Trouble/Rest. PC1404 System battery is low/battery restored. MA/R E(3)A2-000/ YT-00/YR-00 R(3)A2-000 [345]-[346] AC Line Trouble/Rest. AC power to control panel is disconnected or interrupted/...
  • Page 69 Control panel has detected an alternate communicator MA/R E(3)3A-000 ET-00/ER-00 Trouble/Rest. fault/communications restored. [346] Cold Start The PC1404 has restarted after total power loss. MA/R R(3)A5-000 RR-00 [347] Phone 1-4 FTC Restore Control panel has restored communications to central MA/R...
  • Page 70 PC1404 Table 3: Automatic Zone Alarm/Restoral Codes Delay 1 BA-ZZ/BH-ZZ E(1)3A-ZZZ E(1)3A-ZZZ Delay 2 BA-ZZ/BH-ZZ E(1)3A-ZZZ E(1)3A-ZZZ Instant BA-ZZ/BH-ZZ E(1)3A-ZZZ E(1)3A-ZZZ Interior BA-ZZ/BH-ZZ E(1)3A-ZZZ E(1)3A-ZZZ Interior Stay/Away BA-ZZ/BH-ZZ E(1)3A-ZZZ E(1)3A-ZZZ Delay Stay/Away BA-ZZ/BH-ZZ E(1)3A-ZZZ E(1)3A-ZZZ 24-Hr. Supervisory US-ZZ/UR-ZZ E(1)5A-ZZZ E(1)5A-ZZZ 24-Hr.

  • Page 71: Appendix B: Communicator Format Options

    Appendix B: Communicator Format Options Appendix B: Communicator Format Options The following format options are programmable in Section [350] Communicator Format Options 20 BPS, 1400 Hz handshake 20 BPS, 2300 Hz handshake • BPS Formats - 0 is not valid in Account or Rep Code (A must be used). Depending on the pulse format, the panel communicates using the following: 3/1, 3/2, 4/1 or 4/2, 1400 or 2300 Hz handshake, 20 bits per second, non-extended.
  • Page 72 PC1404 Residential Dial If Residential Dial is programmed and an event that is programmed to communicate occurs, the panel will seize the line and dial the appropriate telephone number(s). Once the dialing is complete, the panel will emit an ID tone and wait for a handshake (press a 1, 2, 4, 5, 7, 8, 0, , or # key from any telephone). It will wait for this hand- shake for the duration of Post Dial Wait for Handshake timer.

  • Page 73: Appendix C: Regulatory Approvals Information

    FCC COMPLIANCE STATEMENT Equipment Maintenance Facility If trouble is experienced with this equipment (PC1404) for repair or warranty infor- mation, contact the facility indicated below. If the equipment is causing harm to the CAUTION: Changes or modifications not expressly approved by...
  • Page 76 European Directives. Also a CE decla- ration of conformity (DoC) for this product can be found at www.dsc.com under Agency Listings section. © 2012 Tyco International Ltd. and its Respective Companies. All Rights Reserved. The trademarks, logos, and service marks displayed on this document are registered in the United States [or other countries]. Any misuse of the trademarks is strictly prohibited and Tyco International Ltd.
