Summary of Contents for Celestron NexStar 102 GT 102x1000 AZ
- Page 1 Инструкция Celestron NexStar 102 GT 102x1000 AZ Перейти в карточку товара 8 800 775 98 98...
- Page 2 COMPUTERIZED TELESCOPE INSTRUCTION MANUAL...
-
Page 3: Table Of Contents
Slewing to an Object Finding Planets Tour Mode Constellation Tour Direction Buttons Rate Button Set Up Procedures Tracking Mode Tracking Rate View Time-Site User Defined Objects Get RA/DEC Go to RA/Dec Identify Scope Setup Features Setup Time-Site Slew Limits www.celestron.com... - Page 4 TELESCOPE MAINTENANCE Care and Cleaning of the Optics APPENDIX A - TECHNICAL SPECIFICATIONS APPENDIX B – GLOSSARY OF TERMS APPENDIX C – RS 232 CONNECTION APPENDIX D – OTHER RESOURCES APPENDIX E – TIME ZONE MAPS SKY MAPS WARRANTY www.celestron.com...
-
Page 5: Introduction
INTRODUCTION COMPUTERIZED TELESCOPE Congratulations on your purchase of the Celestron NexStar! The NexStar ushers in a whole new generation of computer automated technology. Simple and friendly to use, the NexStar is up and running after locating just three bright objects. It’s the perfect combination of power and portability. - Page 6 Accessory Tray Fork Arm Focuser Knob Power Outlet Erect Image Diagonal - 45˚ Stainless Steel Tripod 10. Eyepiece Tripod Leg Extension Clamp 11. StarPointer Finderscope Computerized Hand Control 12. Optical Tube with Hand Control Holder 13. Dovetail Mounting Clamp www.celestron.com...
-
Page 7: Assembly
2. Slide the inner portion of each leg down 6” to 8” inches. 3. Adjust the tripod height until the bubble level on the tripod leg is centered. See Fig. 2-2 4. Tighten the tripod locking bolts to hold each leg in place. FIGURE 2-2 www.celestron.com... -
Page 8: Attaching The Hand Control Holder
3. Tighten the tube clamp knob by hand to secure the tube to the fork arm.See Figure 2-5 FIGURE 2-5 Your NexStar is fully assembled and is ready to attach the accessories. www.celestron.com... -
Page 9: The Erect Image Diagonal
Turn the focus knob until the image is sharp. Once sharp, turn the knob towards you to focus on an object that is closer than the one you are currently observing. Turn the knob away from you to focus on a more distant object than the one you are currently observing. www.celestron.com... -
Page 10: The Starpointer Finderscope
See figure 2-8. 2. Orient the StarPointer so that the sight tube is facing towards the front of the tube. 3. Secure the StarPointer bracket by tightening the thumb screw on the mounting platform. FIGURE 2-8– INSTALLING STARPOINTER FINDERSCOPE www.celestron.com... -
Page 11: Starpointer Operation
This will make it easier to get an accurate alignment. The StarPointer is now ready to be used. Azimuth Adjustment Knob Protective Battery Alignment Cover FIGURE 2-9 FIGURE 2-10 BATTERY COMPARTMENT STARPOINTER FINDERSCOPE www.celestron.com... -
Page 12: Hand Control
NGC – Many of the brightest deep sky objects from the Revised New General Catalog. Caldwell – A combination of the best NGC and IC objects. Planets - All 8 planets in our Solar System plus the Moon and Sun. Stars – A compiled list of the brightest stars from the SAO catalog. www.celestron.com... - Page 13 11. RATE: Instantly changes the rate of speed of the motors when the direction buttons are pressed. 12. RS-232 Jack: Allows use with a computer and software programs for telescope control and to update your NexStar’s firmware via PC. www.celestron.com...
-
Page 14: Computerized Hand Control Operation
“Saved Site”. The bottom line of the LCD will display either the current time or the time when you last used the telescope. Since this is your first time using the NexStar, press UNDO to enter current time/site information. www.celestron.com... - Page 15 “Match Confirmed”. Press UNDO to display the names of the three bright objects you aligned to, or press ENTER to accept these three objects for alignment. You are now ready to find your first object. www.celestron.com...
-
Page 16: Auto Two-Star Align
Use UP and DOWN buttons (6 and 9 on the keypad) to scroll to the desired star and then press ENTER. 5. Use the arrow buttons to slew the telescope to the star you selected. Center the star in the finderscope and press ENTER. Finally, center the star in the eyepiece and press ALIGN. www.celestron.com... -
Page 17: Two-Star Alignment
Stars that are at least 40º to 60º apart from each other will give you a more accurate alignment than stars that are close to each other. Once the second star alignment is completed properly, the display will read “Align Successful,” and you should hear the tracking motors turn-on and begin to track. www.celestron.com... -
Page 18: One-Star Align
finderscope. Press ENTER when centered. 5. Then, center the object in the eyepiece and press ALIGN. Once in position, the NexStar will model the sky based on this information and display “ALIGN SUCCESSFUL.” www.celestron.com... -
Page 19: Nexstar Re-Alignment
If you have used one of the single object alignment methods then it is always best to replace the object that is “unassigned” with an actual object. 7. Press ALIGN to make the change. www.celestron.com... -
Page 20: Object Catalog
Object information can be obtained without having to do a star alignment. After the telescope is powered on, pressing any of the catalog keys allows you to scroll through object lists or enter catalog numbers and view the information about the object as described above. www.celestron.com... -
Page 21: Finding Planets
(up and down) and azimuth (left and right). The telescope can be controlled at nine different speed rates. 1 = 2x 6 = .5º / sec 2 = 4x 7 = 1º / sec 3 = 8x 8 = 2º / sec 4 = 16x 9 = 4º / sec 5 = 32x www.celestron.com... -
Page 22: Rate Button
Note: The EQ North and EQ South tracking modes are only needed with telescopes that can be polar aligned. The NexStar GT series are exclusively Alt-Az mounted telescopes and do not require equatorial tracking. www.celestron.com... -
Page 23: Tracking Rate
ENTER RA - DEC: by entering the R.A. and declination for that object. Scroll to the “ENTER RA-DEC” command and press ENTER. The display will then ask you to enter first the R.A. and then the declination of the desired object. www.celestron.com... -
Page 24: Get Ra/Dec
Press ENTER to slew to the bright alignment star. > Use the direction buttons to carefully center the alignment star in the eyepiece. Press ENTER to slew to the desired object. www.celestron.com... -
Page 25: Scope Setup Features
(left and right) or Altitude buttons (up and down) and press ENTER. Pressing ENTER again will reverse the direction of the Hand Control buttons from their current state. Direction buttons will only change the eyepiece rates (rate 1-6) and will not affect the slew rates (rate 7-9). www.celestron.com... -
Page 26: Utility Features
This menu allows you to change the rate of speed that the text scrolls across the Hand Control display. > Press the UP (number 6) button to increase the speed of the text. > Press the DOWN (number 9) button to decrease the speed of the text. www.celestron.com... -
Page 27: Nexstar Menu Tree
SAVED SITE SAVE SKY OBJ ENTER IF OK SAVE DB OBJ UNDO TO EDIT ENTER RA & DEC SELECT OBJECT SAVE LAND OBJ CENTER OBJECT GO TO LAND OBJ GET RA-DEC GOTO RA-DEC IDENTIFY SELECT CATALOG PRECISE GO TO www.celestron.com... -
Page 28: Telescope Basics
240 power. Although this is the maximum useful magnification, most observing is done in the range of 20 to 35 power for every inch of aperture which is 80 to 140 times for the NexStar 102GT telescope. www.celestron.com... -
Page 29: Determining Field Of View
> If you wear corrective lenses (specifically glasses), you may want to remove them when observing with an eyepiece attached to the telescope. When using a camera, however, you should always wear corrective lenses to ensure the sharpest possible focus. If you have astigmatism, corrective lenses must be worn at all times. www.celestron.com... -
Page 30: Celestial Observing
See the “Seeing Conditions” section later in this section. To increase contrast and bring out detail on the planetary surface, try using Celestron eyepiece filters. OBSERVING THE SUN Although overlooked by many amateur astronomers, solar observation is both rewarding and fun. -
Page 31: Solar Observing Hints
To save land objects into your Hand Control’s database as User Defined Objects, first complete the Quick Alignment procedure, this will bypass the normal two star alignment needed for nighttime viewing. Since daytime land objects usually remain stationary, remember to turn off the telescope’s tracking. www.celestron.com... -
Page 32: Seeing Conditions
“seeing” quality. Under good seeing conditions, fine detail is visible on the brighter planets like Jupiter and Mars, and stars are pinpoint images. Under poor seeing conditions, images are blurred and stars appear as blobs. The conditions described here apply to both visual and photographic observations. www.celestron.com... -
Page 33: Telescope Maintenance
Or, liquid dish soap diluted with water (a couple of drops per one quart of water) can be used. To minimize the need to clean your telescope, replace all lens covers once you have finished using it. This will prevent contaminants from entering the optical tube. www.celestron.com... -
Page 34: Appendix A - Technical Specifications
Alt-Az, EQ North & EQ South 125x (8 mm) Alignment Procedures 250x (4 mm) SkyAlign, Auto Two-Star, Two-Star, One-Star, Optical Tube Length Solar System Align 35 inches Database 25 user defined programmable object. Enhanced information on over 100 objects Total Object Database 40,000+ Objects www.celestron.com... -
Page 35: Appendix B - Glossary Of Terms
The distance between the Earth and the Sun. It is equal to 149,597,900 km., usually rounded off to 150,000,000 km. Aurora The emission of light when charged particles from the solar wind slams into and excites atoms and mol- ecules in a planet’s upper atmosphere. www.celestron.com... - Page 36 The distance between a lens (or mirror) and the point at which the image of an object at infinity is brought to focus. The focal length divided by the aperture of the mirror or lens is termed the focal ratio. www.celestron.com...
- Page 37 Polaris lies less than a degree from this point and is therefore referred to as the “Pole Star”. Nova Although Latin for “new” it denotes a star that suddenly becomes explosively bright at the end of its life cycle. www.celestron.com...
- Page 38 This is the angular speed at which the Earth is rotating. Telescope tracking motors drive the telescope at this rate. The rate is 15 arc seconds per second or 15 degrees per hour. Terminator The boundary line between the light and dark portion of the Moon or a planet. www.celestron.com...
-
Page 39: Appendix C - Rs 232 Connection
APPENDIX C - RS-232 CONNECTION For detailed information about controlling NexStar via the RS-232 port, communication protocols and the RS-232 cable, refer to the NexStar Hand Controls section of the Celestron Knowledge base web site at: www.celestron.com APPENDIX D – OTHER RESOURCES... -
Page 40: Appendix E - Time Zone Maps
APPENDIX E – MAPS OF TIME ZONES COMPUTERIZED TELESCOPE www.celestron.com... - Page 41 APPENDIX E – MAPS OF TIME ZONES COMPUTERIZED TELESCOPE CONTINUED www.celestron.com...
- Page 42 COMPUTERIZED TELESCOPE www.celestron.com...
-
Page 43: Sky Maps
COMPUTERIZED TELESCOPE www.celestron.com... -
Page 44: Warranty
Celestron, is found to be defective in materials or workman- ship. As a condition to the obligation of Celestron to repair or replace such product, the product must be returned to Celestron together with proof-of-purchase satisfactory to Celestron. -
Page 45: Www.celestron.com
COMPUTERIZED TELESCOPE 2835 Columbia Street | Torrance, CA 90503 TEL (310) 328-9560 | FAX (310) 212-5835 www.celestron.com Copyright 2011 Celestron | All rights reserved. 22093 (Products or instructions may change without notice or obligation.) 06-11 This device complies with Part 15 of the FCC Rule. - Page 46 Celestron NexStar 102 GT 102x1000 AZ Описание...
