Earthing Instructions
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord
having an earthing wire and with an earthing plug. The plug must be plugged into an outlet that is properly
installed and earthed.
WARNING: Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified
electrician if the earthing instructions are not completely understood or if doubt exists as to whether the
appliance is properly earthed. If it is necessary to use an extension cord, use only a 3 wire extension cord
that has a 3 blade earthing plug and a 3 slot receptacle that will accept the plug on the appliance. The
marked rating of the extension cord should be equal to or greater than the electrical rating of the appliance.
Ensure that the extension cord cable does not over hang the counter top.
IMPORTANT
You should only plug the appliance into a 230V – 240V ~50Hz supply. Connecting it to other power sources
may damage the appliance.
The wires in this mains lead are coloured in accordance
with the following code
GREEN & YELLOW – Earth
BLUE – Neutral
BROWN - Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows: The earth wire which is coloured green &
yellow must be connected to the terminal in the plug which is marked with the letter 'E' or by the earth
symbol or by green & yellow.
The neutral wire which is coloured blue must be connected to the terminal which is marked with the letter 'N'
or coloured black.
The live wire which is coloured brown must be connected to the terminal which is marked with the letter 'L' or
coloured red.
Installation
1.
Make sure that all the packing materials are removed from the inside of the door.
2.
WARNING: Check the oven for any damage, such as misaligned or bent door, damaged door seals and
sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. If there is
any damage, do not operate the oven and contact qualified service personnel.
3.
This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to
be cooked in the oven.
4.
Do not place the oven where heat, moisture, or high humidity are generated, or near combustible materials.
5.
For correct operation, the oven must have sufficient airflow. Allow 30cm of space above the oven, 20cm at
both sides. The minimum installation height is 85cm from the ground. Do not cover or block any openings on
the appliance. Do not remove feet.
6.
Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
7.
Make sure that the power supply cord is undamaged and does not run under the oven or over any hot or
sharp surface.
8.
The socket must be readily accessible so that it can be easily unplugged in an emergency.
Green &
(Neutral)
4
Yellow
(Earth)
Blue
Brown
(Live)
Fuse
