- Page 1 NE 151 Highway 300, Suite A PO Box 2609 Belfair, WA 98528 360.464.2119 www.boxlight.com TraveLight3...
- Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright January, 2008 Disclaimer The information in this document is subject to change without notice.
- Page 3 — ’ — ’ — ’ Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference.
- Page 4 Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
- Page 5 — ’ — ’ — ’ Main Features • Lightweight unit, easy to pack away and transport. • Compatible with all major video standards including NTSC, PAL, and SECAM. • A high brightness rating allows for presentations in daylight or in lit rooms. •...
-
Page 6: Table Of Contents
Table of Contents GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Top view—On-screen Display (OSD) buttons and LEDs ....................3 Rear view ..................................4 Bottom view..................................5 ..............................6 EMOTE ONTROL ARTS .......................... - Page 7 — ’ — ’ — ’ ................................. 39 PECIFICATIONS Input connectors................................39 V.S. P ........................40 ROJECTION ISTANCE ROJECTION ................................ 41 IMING ABLE ..............................45 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ............................. 46 FCC W .................................. 46 ARNING .................................... 46 ANADA ..............................46 AFETY ERTIFICATIONS EN 55022 W...
-
Page 8: Getting Started
– ’ – ’ – ’ ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: PROJECTOR EMOTE CONTROL 3V CR2025 WITH ONE BATTERY RGB T CABLE OWER CORD OMPONENT DAPTER PTIONAL CD-ROM (T ’... -
Page 9: Views Of Projector Parts
— ’ — ’ — ’ Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE Ventilation opening Do not block in order to keep the projector lamp cool Height-adjuster button Push to release height adjuster Height adjuster Adjusts level of projector Lens cap Covers lens to protect when not in use IR receiver... -
Page 10: Top View-On-Screen Display (Osd) Buttons And Leds
– ’ – ’ – ’ Top view—On-screen Display (OSD) buttons and LEDs ABEL ESCRIPTION PAGE Turns the projector On or Off (Power) ▲ (Up cursor) Navigates and changes settings in the OSD Green Power On Power LED Power Off (AC Off) Flashing Error code System over temperature... -
Page 11: Rear View
— ’ — ’ — ’ Rear view ABEL ESCRIPTION EE PAGE AC IN Connect the POWER CABLE Connect the USB CABLE from a computer AUDIO Connect the AUDIO CABLE from the input device S-VIDEO Connect the S-VIDEO CABLE from a video device VIDEO Connect the VIDEO CABLE from a video device Connect the RGB cable (supplied) from a computer... -
Page 12: Bottom View
– ’ – ’ – ’ Bottom view ABEL ESCRIPTION EE PAGE Lamp cover Remove when changing the lamp. Lens cap hook Place strap through to fasten the lens cap cover. Tilt adjustor Rotate adjuster lever to adjust angle position. Height adjustor button Push to release adjustor. -
Page 13: Remote Control Parts
— ’ — ’ — ’ Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 14 – ’ – ’ – ’ ABEL ESCRIPTION EE PAGE Up cursor Navigates and changes settings in the OSD Enter Changes settings in the OSD Power Turns the projector On or Off Right cursor Navigates and changes settings in the OSD Volume + Increase volume Volume -...
-
Page 15: Remote Control Operating Range
— ’ — ’ — ’ Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level. -
Page 16: Setup And Operation
ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. (A) Pull out the cover. (B) Insert the battery with the positive side facing up. Replace the cover. Caution: 1. -
Page 17: Connecting Input Devices
— ’ — ’ — ’ Connecting Input Devices A PC or notebook computer and video devices can be connected to the projector at the same time. Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras. Check the user manual of the connecting device to confirm it has the appropriate output connector. - Page 19 — ’ — ’ — ’ When the “Power Off? /Press Power again” message appears, press the Pow- er button. The projector turns off. Caution: 1. Be sure to remove the lens cap before starting projector. 2. Do not unplug the power cord until the Ready LED stops flashing–indicating the projector has cooled down.
-
Page 20: Setting An Access Password (Security Lock)
– ’ – ’ – ’ Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the OSD on page 18 and Setting the OSD Language on page 19 for help on using OSD menus.) Important: Keep the password in a safe place. - Page 21 — ’ — ’ — ’ You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.
-
Page 22: Adjusting The Projector Level
– ’ – ’ – ’ Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. •... -
Page 23: Adjusting The Zoom, Focus And Keystone
— ’ — ’ — ’ Adjusting the Zoom, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the pro- jected image and screen size Use the Image-focus control (on the projector only) to sharpen the pro- jected image Use the Quick Menu but- ton on the projector or... -
Page 24: Adjusting The Volume
– ’ – ’ – ’ Adjusting the Volume Press the Volume +/- buttons on the remote control. The volume control appears on the display. Press the Down Cursor button on the keypad to adjust Volume +/-. Press the Mute button to turn off the volume (This feature is available only on the remote). -
Page 25: On-Screen Display (Osd) Menu Settings
(OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD. -
Page 26: Setting The Osd Language
– ’ – ’ – ’ Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the Menu button. Press the cursor ◄► button to navigate to Installation I. 2. Press the cursor ▲▼ button until Language is highlighted. 3. -
Page 27: Osd Menu Overview
— ’ — ’ — ’ OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 20 –... -
Page 28: Osd Sub-Menu Overview
– ’ – ’ – ’ OSD Sub-Menu Overview – 21 –... -
Page 29: Image Menu
— ’ — ’ — ’ Image Menu Press the Menu button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to change values for settings. -
Page 30: Color Manager
– ’ – ’ – ’ Color Manager Press (Enter) / ► to enter the color manger sub menu. ESCRIPTION Select to enter the Red Color Manager. Press the ◄► buttons to adjust the Hue, Saturation, and Gain. Select to enter the Green Color Manager. Green Press the ◄►... -
Page 31: Computer Menu
— ’ — ’ — ’ Computer Menu Press the Menu button to open the OSD menu. Press the cursor ◄► button to move to the Com- puter menu. Press the cursor ▲▼ button to move up and down in the computer menu. Press ◄► to change values for settings. -
Page 32: Video/Audio Menu
– ’ – ’ – ’ Video/Audio Menu Press the Menu button to open the OSD menu. Press the cursor ◄► button to move to the Vid- eo/Audio menu. Press the cursor ▲▼ button to move up and down in the Video/Audio menu. Press ◄►... -
Page 33: Installationi Menu
— ’ — ’ — ’ Installation I Menu Press the Menu button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion I menu. Press the cursor ▲▼ button to move up and down in the Installation I menu. Press ◄►... -
Page 34: Installation Ii Menu
– ’ – ’ – ’ Installation II Menu Press the Menu button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion II menu. Press the cursor ▲▼ button to move up and down in the Installation II menu. ESCRIPTION Auto Power Off Press the cursor ◄►... -
Page 35: Osd Menu Setting
— ’ — ’ — ’ OSD Menu Setting ESCRIPTION Menu Position Press ◄► button to select different OSD location. Translucent Menu Press ◄► button to select OSD background translucent level. Menu Display Press ◄► button to select OSD timeout delay. –... -
Page 36: Peripheral Test
– ’ – ’ – ’ Peripheral Test ESCRIPTION Press (Enter) / ► to test the IR remote controller for diagnostic. Remote Control Test (Enter) / ► to test the button on keypad. Button Test Press Press (Enter) / ► to select different colors on screen. Color Test Sound Test Press... -
Page 37: Factory Reset
— ’ — ’ — ’ Factory Reset Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the Factory Reset sub menu and press (Enter) / ► to reset all the menu items to the factory default values. Status Press the cursor ▲▼... -
Page 38: Maintenance And Security
– ’ – ’ – ’ AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. - Page 39 — ’ — ’ — ’ Remove the two screws from the lamp module (A). Lift the module handle up (B). Pull firmly on the module han- dle to remove the lamp module. – 32 –...
-
Page 40: Resetting The Lamp
– ’ – ’ – ’ Reverse steps 1 to 5 to install the new lamp module. While installing, align the lamp module with the connec- tor and ensure it is level to avoid damage. Note: The lamp module must sit securely in place and the lamp connector must be con- nected properly before... -
Page 41: Cleaning The Projector
— ’ — ’ — ’ Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn. -
Page 42: Using The Kensington Lock
– ’ – ’ – ’ ® Using the Kensington Lock If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System. -
Page 43: Troubleshooting
ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection. -
Page 44: Led Error Messages
– ’ – ’ – ’ LED Error Messages Power LED Blink Over Temp LED Ready LED Blink RROR ESSAGES Over temperature Thermal break status error Lamp error Fan1 error Fan2 error Fan3 error Lamp door open DMD error Color wheel error In the event of an error, please disconnect the AC power cord and wait for one (1) minute before re- starting the projector. -
Page 45: Lamp Problems
Include a description of the problem and a checklist of the steps you took when trying to fix the problem: The information may be useful to service personnel. For servicing, contact the BOXLIGHT Service department at 866.972.1549. – 38 –... -
Page 52: P Rojector D Imensions
– ’ – ’ – ’ Projector Dimensions 220 mm (8.6 inches) – 45 –... -
Page 53: Fcc W Arning
EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communica- tions.
