Shift Shaft - Yamaha FZ150 Parts Catalogue

FIG. 17 SHIFT SHAFT
REF.
PART NO. DESCRIPTION
NO.
1 3C1–E8140–00 STOPPER LEVER ASSY
2 3C1–E8119–00 BOLT, SHIFT
3 3C1–E8337–00 SPRING
4 3C1–E8101–00 SHIFT SHAFT ASSY
5 90508–32837 .SPRING, TORSION
6 99001–10600 .CIRCLIP
7 93608–30839 PIN, DOWEL
8 93102–12891 OIL SEAL
9 3C1–E8110–00 SHIFT PEDAL ASSY
10 1EG–E8113–01 .COVER, SHIFT PEDAL
11 3C1–E8115–00 .ROD, SHIFT
12 92907–06200 .WASHER
13 91401–20012 .PIN, COTTER
14 5BP–E8112–00 .ARM, SHIFT
15 97024–06020 BOLT
21
REMARKS
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
