NSA-220 Plus
Network Storage Appliance
Default Login Details
Web Address
User Name
Password
Firmware Version 3.10
Edition 1, 2/2009
www.zyxel.com
Color: Black / White
www.zyxel.com
nsa220plus
admin
1234
Copyright © 2008
ZyXEL Communications Corporation
