Mem; Dual - XCOM 760 Installation And User Manual

Gen On
General Coverage option is enabled. This extends the receive range
from 137.00 to 163 MHz. The receive sensitivity is reduced above 150
MHz. Above 137 MHz. the radio will receive in FM rather than AM. This
enables monitoring of the popular Amateur 2 meter band and marine
frequencies. Push the F/CH knob to toggle the option between on & off.
Rotating the F/CH knob anti-clockwise will return to the VOR option
screen.
VoLTS
Shows the current voltage. Rotating the F/CH up or down will show the
high volts set point and the low volts set point.
Sidevol
Adjusts the level of sound you hear through the headsets when
transmitting (sidetone). Generally this does not need to be adjusted
from the factory default value.
ScanCH
Adjusts the number of memory channels to scan when memory
scanning is activated. Note that the priority channel 0 (121.500) is
always scanned.
MEM - Press this button once to access the 99 memory channels. The memory
channels are displayed with the channel number on the bottom line and stored
frequency on the top.
When accessed for the first time, the memory channel will show the priority or
emergency frequency 121.500 MHz. as this is stored as a factory default in memory
location 0. Subsequent returns to the memory screens will show the last accessed
memory channel.
Memory locations are cycled by rotating the F/CH knob. Only those locations which
have frequencies stored will be displayed. The top 10 locations, channels 90
through 99, contain the NOAA weather frequencies for use within the United States.
Channels 1 to 5 may be pre-stored with tuning frequencies used when your radio
underwent quality control and tuning. These may be overwritten at any time.
While in the memory screen, pressing the PTT will transmit on the current memory
frequency. Pressing and holding
programming mode (see below). Pressing
the default screen with no memory channel loaded.
For details on how to program the memory channels, please refer to the memory
programming section below.
DUAL - When in the default screen, this button enables the dual watch function,
indicated by the DUAL WATCH icon.
When this function is active, the transceiver will receive on the standby frequency
and intermittently check the active frequency for activity. If a signal is received on
the active frequency, the transceiver automatically switches to that frequency.
When the signal ceases, the unit returns to the standby frequency and continues
scanning the active.
Release 1.7
for 2 seconds will enter the memory
© XCOM Avionics 2005
momentarily will simply return you to
www.xcom760.com Page 11
