MANUAL
RA/RM-2D
0402
822 70 89-06
Piezo igniter version
Reigniter version
CARAVAN
RM 4601
page
page 11
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM 4601 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dometic RM 4601

Summary of Contents for Dometic RM 4601

  • Page 1 MANUAL CARAVAN RA/RM-2D 0402 RM 4601 Piezo igniter version page Reigniter version page 11 822 70 89-06...

  • Page 3: Table Of Contents

    OPERATING AND INSTALLATION INSTRUCTIONS FOR DOMETIC REFRIGERATORS INTRODUCTION CONTENTS We are pleased that you have chosen this refrigerator and hope you will derive much satisfaction from using it, OPERATING INSTRUCTIONS ......4 but first a few well-meant words of advice: CONTROLS ............

  • Page 4: Voltage

    2. Set the thermostat knob (E) to the highest setting. OPERATING INSTRUCTIONS 3. Turn the energy selector (A) to position “GAS”. CONTROLS 4. Push the button (D) in until it reaches the bottom - and hold, push the button (C) for the piezo igniter sev- eral times to light the burner.

  • Page 5: Ice-Making

    Most kinds of frozen food can be stored in the frozen The cooling unit behind the refrigerator should be cleaned food compartment for about a month. This period of time with a brush from time to time, but make sure that the may vary, however, and it is important to follow the in- refrigerator is switched off when doing this.

  • Page 6: Maintenance

    Code AG 601 for Gas Burning Appliances and Equip- ment, and any other relevant statutory regulations. REPOSITIONING THE HINGES The refrigerator is equipped with reversible doors. A special door reversing kit must be used to reverse the doors. For further information, contact your dealer or Dometic. FIG. 2...

  • Page 7: Securing The Refrigerator

    A length of sealing strip is applied to the rear surface of the front frame for this purpose, see fig. 2. Note: A wood strip must be in place across the upper opening of the enclosure. The top frame of the refrigera- tor will be anchored to the wood strip with screws.

  • Page 8: Ventilation Of The Unit

    We recommend fitting the Dometic ventilation system, reducing valve on the LP gas container. which is specially developed by Dometic for this purpose. The Dometic ventilation grilles permit inspection and The gas installation and servicing must be carried out by...

  • Page 9: Electrical Connection

    The electrical installation must be carried out in a proper and durable manner; taking into accounts all relevant regulations and codes of practice. TECHNICAL DATA RM 4601 For mains voltage operation, it is important that the Overall dimensions, refrigerator circuit to and in the caravan is effectively earthed.
  • Page 10 FIG. 8 Wiring diagram RM 4601 with piezo igniter...
  • Page 11 OPERATING AND INSTALLATION INSTRUCTIONS FOR DOMETIC REFRIGERATORS INTRODUCTION CONTENTS We are pleased that you have chosen this refrigerator OPERATING INSTRUCTIONS ......12 and hope you will derive much satisfaction from using it, CONTROLS ..........12 but first a few well-meant words of advice: STARTING THE REFRIGERATOR ....

  • Page 12: Voltage

    3. Turn the energy selector (A) to position “GAS”. OPERATING INSTRUCTIONS A ticking sound will be heard and the lamp (B) will CONTROLS start flashing. 4. Push the button (C) in until it reaches the bottom - and hold. This opens the flame failure device and allows gas to flow to the burner.

  • Page 13: Ice-Making

    Most kinds of frozen food can be stored in the frozen The cooling unit behind the refrigerator should be cleaned food compartment for about a month. This period of time with a brush from time to time, but make sure that the may vary, however, and it is important to follow the in- refrigerator is switched off when doing this.

  • Page 14: Maintenance

    Code AG 601 for Gas Burning Appliances and Equip- ment, and any other relevant statutory regulations. REPOSITIONING THE HINGES The refrigerator is equipped with reversible doors. A special door reversing kit must be used to reverse the doors. For further information, contact your dealer or Dometic. FIG. 2...
  • Page 15 A length of sealing strip is applied to the rear surface of the front frame for this purpose, see fig. 2. Note: A wood strip must be in place across the upper opening of the enclosure. The top frame of the refrigera- tor will be anchored to the wood strip with screws.

  • Page 16: Ventilation Of The Unit

    LP gas container. We recommend fitting the Dometic ventilation system, which is specially developed by Dometic for this purpose. The Dometic ventilation grilles permit inspection and The gas installation and servicing must be carried out by...

  • Page 17: Electrical Connection

    The supply pipe should preferable be of copper. If any 12 V Supplies other material is used, it must be of a type approved for The 12 V connection of the refrigerator is shown in fig. 7. use with continuously operating bottled-gas appliances Connect the refrigerator to the vehicle battery or alterna- and have threaded connections throughout.

  • Page 18: Technical Data

    TECHNICAL DATA RM 4601 Overall dimensions, refrigerator Height (incl. controls) ......1427 mm Width ..........632 mm Depth (incl. handle) ......668 mm Recess dimensions Height ..........1415 mm Width ..........607 mm Depth ..........620 mm Capacity Gross ..........186 litres Net .............
  • Page 19 Wiring diagram RM 4601 with reigniter...

  • Page 20: Positioning Of Shelves

    Positioning of shelves MO-FO 0335...
