Anchor KP-800C User And Installation Manual

Video intercom system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Anchor AN-3668 Video
Intercom System
User's and Installation Manual
KP-800C/AN-3668/GS-001
Please read this manual carefully and save for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP-800C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anchor KP-800C

Summary of Contents for Anchor KP-800C

  • Page 1 Anchor AN-3668 Video Intercom System User's and Installation Manual KP-800C/AN-3668/GS-001 Please read this manual carefully and save for future reference.

  • Page 2: Table Of Contents

    Contents Introduction Operating Instructions 2.1 Instructions for the AN-3668 Room Station Operation 2.2 Instructions for the KP-800C Entrance Station Operation Conduit Tubing 3.1 Conduit Tubing Layout 3.2 Conduit Tubing Tips 3.3 Pulling the Wires Interface Wiring Other Wiring Installation 6.1 Pre-Installation 6.2 Installation of the KP-800C Entrance Station...

  • Page 3: Introduction

    1: Introduction Thank you for purchasing the Anchor Security System's AN-3668 Video Intercom system. We are sure that once you have started using it, you will find that it is a very convenient and reliable system, designed to make the process of protecting your home, business, or factory a little easier.
  • Page 4 DOOR OPEN button. The KP-800C Entrance Stations consist of a IN U S E CCD camera, a microphone, a keypad, and an O p e r a tio n In s tr u c tio n 1 .K e y in re s id e n t‘...
  • Page 5 Gas Leak Detectors, Door and Window Alarms, and Panic Buttons. The AN-3668 also has an optional Auto-Selector Controller, for selecting which of several cameras to connect with in systems with multiple cameras. Please contact your Anchor representative for more information on these options.

  • Page 6: Operating Instructions

    2:Operating Instructions 2.1 Operation Instructions for Room Station Speaker Hole 4" LCD Receive "Door Open" Indicator LED Magnetic Hook "Open Door" Button Magnetic Hook "Monitor" Button Microphone "Call" Button Handset Contrast Knob Power / Volume Brightness Knob Knob Fig. 2.1 The Room Station a.
  • Page 7 2.2 Operation Instructions for Entrance Station Host Station Code LED Lens Display Infra-Red Illumination LEDs I N U S E O p e r a tio n I n s tr u c tio n 1 .K e y in r e s id e n t ‘ s d ig it c o d e a n d p r e s s “ C a ll” . 2 .I n t h e n e v e n t o f e r r o r ,p re s s “...

  • Page 8: Conduit Tubing

    3: Conduit Tubing 3.1 Conduit Tubing Layout Before any system can be installed or hooked up, the first step is to install conduit tubing to protect the wiring. This step should be at the same time the building is under construction, as it will be difficult to install the tubing once the building has been completed.
  • Page 9 3/4“ 3/4“ Approx. 30-40 cm from Each floor must have Room Station a extension box. Pre-Installation Box . Recommended Size: 1“ typical 90*60*40mm+ 400 * 300 * 100 mm power box is suitable. 3/4“ 3/4“ Ground Floor Distribution Box, must be 40x30x10cm or larger Distance from floor: 30-40cm 3/4“...

  • Page 10: Pulling The Wires

    d. While using conduit tubing that is too large will cause no problem, using conduit tubing that is too small is a bad idea, as this will make it difficult to pull the wires up, as well as increasing the risk of insulation being rubbed off the wires.
  • Page 11 Wiring Possibility 2: 3C Lines One 3C/2V One 9C Power Entrance Distribution Box Station Electronic Lock One 6C Central Control Guard Station Wire Specifications Diagram: Room Room Station Top Floor Station Distribution Box 3C/2V+8C 3C/2V+8C 3C/2V+ AC+8C Please Note: Ground Floor Entrance Station We suggest using wire Distribution Box...

  • Page 12: Interface Wiring

    4:Interface Wiring Terminator Brn./Yel./Blue 5 6 7 8 10 11 12 Insert Extra Room Stations here Video Signal Resistance is usually 50 ~ 75 ohms. If the resistance in the system is not at this level, a resistor can be added here. 5 6 7 8 Backpanel 10 11 12...
  • Page 13 4:Interface Wiring Terminator Brn./Yel./Blue 5 6 7 8 10 11 12 Insert Extra Room Stations here Video Signal Resistance is usually 50 ~ 75 ohms. If the resistance in the system is not at this level, a resistor can be added here. 5 6 7 8 Backpanel 10 11 12...

  • Page 14: Other Wiring

    5: Other Wiring The Anchor AN-668 uses two different types of wiring: Single Core ( the 9C wire used in the main conduit) and Multi Core (the 3C/2V used for power supply in the system). At several points during the wiring process, wires are required to be spliced together. When splicing two wires of the same type, we recommend twisting the two wires together, at least 7 times, and then using electrical tape to insulate the splice.

  • Page 15: Installation

    6: Installation 6.1 Pre-installation Before room station the unit itself, you must first install the Pre-Installation Box. This is the box that feeds the wiring into the unit, and that holds it in place on the wall. 6.2 Installation of the Entrance station We recommended placing the center of unit approximately 120-140cm (4’...

  • Page 16: Installation Of The An-3668 Room Station

    6.3 Installation of the Room station We recommend placing the unit approximately 120cm-150cm (4’-5’) above the ground. Please note: Avoid mounting the unit in places with excessive amounts of oil, smoke, or high temperatures, as these may have an effect on the quality and life of the unit. 6.4 Code Setting Board on the Room Station Instructions...
  • Page 17 Code Setting Procedure DIP Switch Number Symbol Position represented Hexadecimal Displayed 0+0+0+0= 0 1+0+0+0= 1 0+2+0+0= 2 1+2+0+0= 3 0+0+4+0= 4 1+0+4+0= 5 0+2+4+0= 6 1+2+4+0= 7 0+0+0+8= 8 1+0+0+8= 9 0+2+0+8=10 1+2+0+8=11 0+0+4+8=12 1+0+4+8=13 Not Used 0+2+4+8=14 Not Used 1+2+4+8=15 Not Used...

  • Page 18: Decoding Process

    Decoding Process 1. When the room station receives a signal that matches it’s own identification code, it will automatically emit a ringing sound, and the display will be powered on. Room Station Code Set Switch Settings...
  • Page 19 Digit Digit Digit 1 ON = 0 OFF = 1 2 ON = 0 OFF = 2 = 2 3 ON = 0 OFF = 2 * 2 = 4 4 ON = 0 OFF = 2 * 2 * 2 = 8 Using these 4 switches, it is possible to make any combination from 0(all 4 ON)to 15(all 4 OFF), or 16 combinations.

  • Page 20: Detailed Wiring Diagram

    7: Detailed Wiring Diagram 7.1 AN-3668 Detailed Wiring Diagram Wiring Diagram 5 6 7 8 BROWN ORANGE 9 10 11 12 YELLOW GREEN BLUE CONDUCTOR BIRAID SHIELD DC IN...
  • Page 21 KP-800 OPEN: TWO OR MORE KP-800 OR GUARD STATION EXIT 2 PIN VIDEO SELECT CONNECT TO AS-001-1 CONNECTOR (ONLY ONE KP-800) PS: The explain of connector are standard for connect on KP-800C. COLOR INDEX COLOR INDEX COLOR INDEX COLOR INDEX...
  • Page 22 KP-800 OPEN: TWO OR MORE KP-800 OR GUARD STATION EXIT 2 PIN VIDEO SELECT CONNECT TO AS-001-1 CONNECTOR (ONLY ONE KP-800) PS: The explain of connector are standard for connect on KP-800C. COLOR INDEX COLOR INDEX COLOR INDEX COLOR INDEX...
  • Page 23 7.3 KP-800C & AN-3668 STANDARD DIAGRAM PW-108 ENDING CONNECTOR AC 220V/ 110V DC JACK DC18V IN COAXIAL CABLE AC 220V/110V (RG-58U) CABLE WIRE 0.65mm 1 2 3 4 5 6 8 9 9 PIN FEMALE CONNECTOR AC 220V/ 110V KP-800...
  • Page 24 7.3 KP-800C & AN-3668 STANDARD DIAGRAM PW-108 ENDING CONNECTOR AC 220V/ 110V DC JACK DC18V IN COAXIAL CABLE AC 220V/110V (RG-58U) CABLE WIRE 0.65mm 1 2 3 4 5 6 8 9 9 PIN FEMALE CONNECTOR AC 220V/ 110V KP-800...

  • Page 25: Maintenance And Repair

    8.2 Checking System Wiring The Anchor Intercom System uses a compromised design, making it easy for repair or service personnel to do maintenance. All that is needed to find problems in the system is a basic Multi-meter.
  • Page 26 Please use the chart on page 25 for instructions on how to adjust the room station. Not Functioning? A. The Power switch is turned off. B. The power fuse is burned out. Does the C. The power to this area has been cut off. System have A.

  • Page 27: Specifications

    Interface: 4 Wire Polarized Dimensions: 60mm ( D ) x 200mm ( W ) x 235mm( L ) Weight: Approx. 1200 g 9.2 KP-800C Entrance Station Specifications Power Source: +12VDC and +24VDC Power Consumption: 6 Watts Maximum Video Output: 1 V.P.P. EIA/CCIR (Factory Set) Audio Input 0.5 watt - 1 watt...

  • Page 28: Service Guarantee

    After the end of this period, service is offered at rates dependent on the condition of the unit. Manufacturer: Anchor Security Systems Co., Ltd. Floor - 1, No. 70, Chien Liu Rd. Chung Ho, Taipei Hsien, Taiwan Tel: 886 (2) 22256651 (6 lines)
