Anchor ProLink Owner's Manual

TECHNICAL SPECIFICATIONS
ProLink Belt Pack (BP-9000)
RF Frequency Range 902-928MHz
Modulation FSK
Range (line of sight) Duplex 250' / 75 m
Antenna 1/2 - wavelength dipole
Power Supply 9VDC, 1.2ADC
Battery Life 15 hours
Weight 15oz. / 0.42kg (w/ batteries)
Dimensions 4.5 x 6.25 x 3.75" /
114.3 x 158.75 x 95.25 mm
Single-Ear (H-2000S & Dual-Ear Headphones H-2000)
Drivers Dynamic, 40mm
Impedance 300ohm +/- 15%
Frequency Response 20Hz - 20kHz
SPL 91dB +/- 3dB
Rated Power > 40mW
Distortion < 5%
Microphone Dynamic, Uni-directional,
Low impedance
Mic Sensitivity Referenced to 0dB=1V/μbar, 1kHz
Min -85 dB / Typical -83 dB /
Max -81 dB
Frequency Response 200Hz-12kHz
Connector Plug 4-pin XLR, female
Weight Single: 13 oz. / 0.37 kg &
Dual: 16 oz. / 0.45 kg
FCC ID: J8ZBP-9000
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that my cause undesired operation.
"This device has been designed to operate with the antennas listed below, and having a maximum gain
of [x] dB. Antennas not included in this list or having a gain greater than [x] dB are strictly prohibited for
use with this device. The required antenna impedance is [y] ohms."
"To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for
successful communication."
"Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
the device."
Warning: Changes or modifications not expressly approved by Anchor Audio, Inc.
could void the user's authority to operate this device
ANCHOR AUDIO CUSTOMER SERVICE
888/444-6077 • 310/784-2300
Anchor Audio, Inc.
Portable Sound Systems • Torrance, California
For videos on how to setup & use the ProLink:
ProLink
™
WIRELESS INTERCOM SYSTEM -
OWNER'S MANUAL
GETTING STARTED .......................................................................................................................................................... 2
WHAT IS PROLINK? .......................................................................................................................................................... 3
BELT PACKS ................................................................................................................................................................... 3
HEADSETS ...................................................................................................................................................................... 3
RECHARGEABLE BATTERIES ............................................................................................................................................. 3
BASIC OPERATION / SYSTEM RANGE ............................................................................................................................. 4,5
DEFINITIONS AND APPLICATIONS ...................................................................................................................................... 6
FREQUENTLY ASKED QUESTIONS ...................................................................................................................................... 7
TROUBLESHOOTING ........................................................................................................................................................ 7
TECHNICAL SPECIFICATIONS ............................................................................................................................................ 8
100-0200-000/A - 04/10
www.anchoraudio.com
PATENT PENDING
CONTENTS
