Summary of Contents for Anchor PORTACOM
- Page 1 OWNER’S MANUAL PO RTACO M...
-
Page 2: Table Of Contents
Our Technical Support team will help to troubleshoot. If unsuccessful and under warranty, they will issue you a Return Merchandise Authorization (RMA) number. Once you ship your product back to Anchor Audio with the RMA number clearly noted on the box, we will diagnose your unit and repair your unit then ship it back to you. -
Page 3: Basic System Operation
PORTACOM BASIC SYSTEM OPERATION Plug in headset connector into the 4-pin XLR Headset Input on the BP-2000 belt pack Plug in the AC Adapter into a standard 110V AC outlet (230V AC export) Connect the BP-2000 belt packs to the output jacks on the PC-2000 using standard microphone cables with 3-pin XLR connectors. -
Page 4: Branch Box (B3-2000) - Optional Accessory
The PortaCom can be expanded up to 20 users using the Branch Box (B3-2000). Follow the PortaCom Basic System Operation instructions on page 2 to initially set up your wired intercom Connect a 3-pin XLR cable from the Branch Box XLR input to one of the XLR outputs on the PC-2000 Power Console... -
Page 5: Program Mixer (Pgm-2000) - Optional Accessory
LEVEL PROGRAM MIXER (PGM-2000) The PGM-2000 is a two-channel Program Insertion Station for use with the PortaCom wired intercom system. It provides a means to insert program audio (from a tape player, mixer, or stage mics) onto the intercom line. - Page 6 B3-2000 AUDIO/INTERCOM OUT PGM-2000 (CHANNEL A) PROGRAM IN If you have any questions about the setup of your PortaCom wired intercom system, the Program Mixer (PGM-2000), or HEADSET any other Anchor Audio product, please contact HEADSET Anchor Audio Technical Support.
-
Page 7: Wingman (Wm-500) - Optional Accessory
Select Wired Channel (A or B) to be used according to Turn power switch to ON the pin description above (also shown on pack panel) . Adjust the headset volume to desired level The Wired Channel Switch matches the Anchor Audio PortaCom belt pack channels. WingMAN MASTER WIRED... -
Page 8: Troubleshooting
Shields can be connected to chassis ground pin. Headset pin configuration: 1 = Mic (-), 2 = Mic (+), 3 = Headphone (-), 4 = Headphone (+) With the use of branch boxes (B3-2000), the PortaCom has a 50 headset How many belt packs can I use? capacity. -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS PORTACOM WIRED INTERCOM Normal Line Level -15 dBV Signal-to-Noise-Ratio -65 dBV Distortion < 0.5% Standard 1-pair shielded mic cable with 3-pin XLR (heavy-duty cable Connecting Cables recommended for runs over 250 ft.) Compatibility Generally compatible with industry standard system (call for info) - Page 10 TECHNICAL SPECIFICATIONS (CONT’D) PORTACOM WIRED INTERCOM B3-2000 - Branch Box Input One 3-pin XLR female Output Three 3-pin XLR male Dimensions (HWD) 1.9” x 4.1” x 4.25” (4.8 x 10.4 x 10.8 cm) Weight 1.2 lbs / 0.54 kg Warranty 2 years...
-
Page 11: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read Instructions – All the safety and operation instructions should be read before the 15) Outdoor Antenna Grounding – If an outside antenna or cable system is connected to product is operated. the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. -
Page 12: Warranty
ANCHOR AUDIO WARRANTY Anchor Audio products are warranted to be free from defects in materials and workmanship for the period of SIX (6) YEARS from the date of original purchase unless listed below. Warranted for a period of TWO (2) YEARS: •...
