Alpha Microsystems AM-6060 Owner's Manual page 73

Status Display Codes
Front Panel
Status Code
48
49
4A - 4E
4F
88
95
96
97
98
99
B0
B1
C5
CC
CE
CF
D0
EF
F
F0
F1
F2
F4
AM-6060 Computer Owner's Manual, Rev. 00
An internal fault has been detected in the UPS.
An internal fault has occurred in the UPS and it is in bypass.
Not valid.
UPS cable has been unplugged from UPS port.
Trying to execute an unimplemented SVCA (Monitor) call.
Logger CREATE error.
Logger CLOSE error.
Logger FILOTX error.
Logger OPENA error.
Logger semaphore not available.
CMOS batteries need to be replaced. Data that was stored in CMOS RAM is
not guaranteed.
The battery voltage dropped temporarily (i.e., after replacing the batteries).
The initial CMOS parameters are not guaranteed. Access the CMOS setup
routine by pressing Reset, then pressing the
appears on the front panel. Re-enter CMOS settings.
Do you want to enter CMOS setup? You have three seconds to press the
key on the boot terminal, which must be set at 19200 baud.
ESC
The computer is testing the CMOS RAM for proper operation after
detecting a CMOS checksum error.
CMOS parameter checksum error. This code will flash on the front panel for
several seconds.
CMOS RAM failure. The system is going into a halt state. Contact your
VAR or the Alpha Micro Technical Assistance Center.
Tried deleting all three valid timer chips and all failed.
System has detected an attempt to write outside of the supervisor stack area.
On boot-up, memory is being cleared and sized.
Bus error was encountered.
Address error was encountered.
Illegal instruction was encountered.
CHK instruction.
Front Panel Status Codes (continued)
Description
key when the code "C5"
ESC
Page 8-5
