Invisible Technologies, Inc.
1-800-826-5527
www.innotek.net
Quick Start Guide
Step 1
Step 2
Step 3
Step 4
2100218-2
Deluxe & Premium In-ground Pet Fencing Systems
Design Your Fence
Have the local utility companies mark your underground lines. On a sheet of
paper, draw your house and yard. Draw a line around your property that repre-
sents the containment area for your dog.
Install the Wall-mount transmitter
Most people find that the inside of an exterior
wall of a garage or basement is ideal. From the
sample layouts, you can see the twisted wire
running from the house attaches directly to the
transmitter.
Lay Out the Fence Wire
Run the containment wire around the property as outlined
in your plan.
Final Connections
Splice the containment loop wires to the twisted wire using the supplied water-
proof splices. Connect the other end of the twisted wire to the wall-mount trans-
mitter. Plug in the AC adapter, connect it to the transmitter, and turn it on. The
green light should illuminate on the transmitter indicating a successful loop.
Charge your collar receiver by placing it in the receiver cradle located on top of
the transmitter.
1.
SD-2100, SD-2200
Boundary Wire
10'
90˚
10'
Boundary Wire
Splice
To wall-mount transmitter
