Control or Icon

Turn-By-Turn Icons

Control
4 — Icons and Controls
Name Description
Route Calculation Crite- Tap to cycle through the route calculation criteria options.
ria button
SET ORIGIN Tap to set the current location as the starting vehicle posi-
tion.
POI Icons These icons denote locations of interest, including restau-
rants, banks, hotels, and more.
Green Flag Location of the next maneuver.
Checkered Flag Destination location.
Description
Turn-by-Turn start.
Turn-by-Turn end.
The next maneuver is a distance away. (The arrow points left or
right as appropriate.)
The next maneuver is closing in. (The arrow points left or right as
appropriate.)
The next maneuver is imminent. (The arrow points left or right as
appropriate.)
17
