NOTE
1. If you are unsure how to connect your oven, please
consult an authorized qualified electrician.
2. Neither the manufacuture nor the dealer can accept
any liability for damage to the oven or personal

INSTALLATION INSTRUCTIONS

WARNING : Always keep the caution sheet (SPECIAL INSTRUCTIONS AND WARNINGS) close to the oven
for your reference.
1) Remove all packing materials from the inside of the
oven cavity. Remove all the blue protective film
from the outside of the oven.
2) Check the oven carefully for any signs of damage.
3) Place the oven on a flat, level surface strong enough
to support the oven's weight plus the heaviest item
likely to be cooked.
Do not place this oven in a position which is not
easily accessible. To position the oven too high
can be dangerous because food can not be
removed safely.
4) Ensure there is a minimum free space above the
oven of 15 cm.

ACCESSORIES

Check to make sure the following accessories are provided:
• Operation manual
• Caution Sheet (SPECIAL INSTRUCTIONS AND WARNINGS : part code TCAUHA429WRRZ,
TCAUHA430WRRZ and TCAUHA445WRRZ)
NOTE:
• When you order accessories, please mention the two items: part name and model name to your dealer or
SHARP authorized service agent.
• The model name is printed on the cover of this operation manual.

BEFORE OPERATION

Plug in the oven.
1. The oven display will flash:
2. Touch the STOP button the display will show:
STOP
x1
injury resulting from failure to observe the correct
electrical connection procedure.
3. Water vapour or drops may occasionally form on the
oven walls or around the door seals and sealing
surfaces. This is a normal occurrence and is not an
indication of microwave leakage or a malfunction.
5) Securely connect the plug of the oven to a standard
earthed (grounded) household electrical outlet.
6) The unit may be secured to a countertop or stand.
There is a screw hole in the bottom of the unit. After
the oven is permanently placed, drill a hole through
the counter top for a 5 mm self-tapping screw. The
hole should be 20 mm from the left side of the outer
case cabinet and 180 mm back from the front edge
of the cavity face plate.
15 cm
7) This oven is not intended to stack one on top of
another.
Using the STOP button
Use the STOP button to:
1. Erase a mistake during programming.
2. Stop the oven temporarily during cooking.
3. Cancel a programme during cooking, touch twice.
3
180 mm
20 mm
Hole
