This is a supplemental Service Manual for Models R-1510 and R-1511. These models are quite similar to base model
R-1500 and R-1501. Use this supplemental manual together with the Base Models Service Manual (Reference No.
is S8123R1500X//) for complete operation, service information, etc..
BEFORE SERVICING ...................................................................................................... INSIDE FRONT COVER
WARNING TO SERVICE PERSONNEL ................................................................................................................ 1
MICROWAVE MEASUREMENT PROCEDURE ................................................................................................... 2
FOREWORD AND WARNING ............................................................................................................................... 3
PRODUCT SPECIFICATIONS .............................................................................................................................. 4
CONTROL PANEL ................................................................................................................................................. 5
OPERATION .......................................................................................................................................................... 5
TROUBLESHOOTING GUIDE .............................................................................................................................. 7
TEST PROCEDURE .............................................................................................................................................. 8
TOUCH CONTROL PANEL ASSEMBLY ............................................................................................................ 14
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE ................................................................ 19
PICTORIAL DIAGRAM ........................................................................................................................................ 22
POWER UNIT CIRCUIT ...................................................................................................................................... 23
LSI UNIT CIRCUIT ............................................................................................................................................... 24
PRINTED WIRING BOARD ................................................................................................................................. 25
PARTS LIST ........................................................................................................................................................ 26
PACKING AND ACCESSORIES ......................................................................................................................... 28
SHARP CORPORATION
SERVICE MANUAL
OVER THE RANGE
MICROWAVE OVEN
MODELS
In the interest of user-safety the oven should be restored to its
original condition and only parts identical to those specified should
be used.
WARNING TO SERVICE PERSONNEL: Microwave ovens con-
tain circuitry capable of producing very high voltage and
current. Contact with the following parts may result in a
severe, possibly fatal, electrical shock. (High Voltage Capaci-
tor, High Voltage Power Transformer, Magnetron, High Volt-
age Rectifier Assembly, High Voltage Harness etc..)

TABLE OF CONTENTS

This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
31
R-1510
R-1511
R-1510
R-1511
S2205R1510X//
Page
