Vizio S4220w-E4 Quick Start Manual

High definition sound bar

Hide thumbs

Table Of Contents

VIZIO

QUICK START GUIDE

Model: S4220w-E4

Table of Contents

Need help?

Do you have a question about the S4220w-E4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vizio S4220w-E4

Page 1 VIZIO QUICK START GUIDE Model: S4220w-E4...
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Your Unit is designed and manufactured to operate within defined design limits, and misuse may result in electric • The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert shock or fire. To prevent your Unit from being damaged, the following rules should be observed for its installation, use, the user to the presence of un-isolated, dangerous voltage within your Unit that may be of and maintenance.
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents ..............3 Package Contents ..............4 Controls & Connections ............5 FIrst-Time Setup ................7 Bluetooth Pairing ..............12 Using Bluetooth Mode .............13 Advanced Setup ..............14 Wall Mounting the Sound Bar ..........15 Adjusting Sound Bar Settings ..........17 Help & Troubleshooting ............19 One-Year Limited Warranty ............22 Legal &...
Page 4: Package Contents
PACKAGE CONTENTS High Definition Sound Bar Remote Control Quick with Batteries Start Guide Power Cable Stereo RCA to 3.5mm Coaxial Audio Digital Optical Audio Cable Cable Cable 2 x Sound Bar Wall 2 x Wall Wall Mount Mount Brackets Mount Screws Template (Size: M4 x 10)
Page 5: Controls & Connections
CONTROLS & CONNECTIONS Back of Sound Bar Power Port (USB 5) (Digital 3) (Aux 1) USB Port Coaxial In Analog Audio In (Optical 4) (Aux 2) Digital Optical Analog Audio In Audio In...
Page 6 Back of Sound Bar Control Buttons are located here: Power Input Bluetooth Input (Hold to force pair, See “Bluetooth Pairing” on page 12) Volume...
Page 7: First-Time Setup
FIRST-TIME SETUP Connect one of the included cables to ONE TV Connection ports are located here: audio output as shown.* BETTER BETTER GOOD GOOD DIGITAL OPTICAL DIGITAL COAXIAL 3.5MM TO 3.5MM TO CABLE** CABLE** RCA CABLE RCA CABLE CHOOSE ONE CABLE: BETTER GOOD AND CONNECT IT TO YOUR TV...
Page 8 Connect a power cable to the sound bar. Plug the power cable into a power outlet.
Page 9 Sound bar is centered below the TV. For the best surround sound experience, position the sound bar as shown. The sound bar should be close to ear level.
Page 10 Remove the battery cover Insert the included batteries by gently sliding it away and gently slide the battery from the remote. cover back into place. Input Power Turn your TV on, then press the Power button on the remote to turn the Sound Bar on. Press the Input button to switch between audio sources.
Page 11: Using The Remote
USING THE REMOTE Bluetooth Input Press to enter Bluetooth input. Press to change input source. (To enter force pair mode, press and hold for 5 seconds) Power Press to turn on or off. Volume + Enter/Play/Pause Press to increase volume. Press to select an option.
Page 12: Bluetooth Pairing
Indicators on the Display Panel on the front of the Sound Bar will light sequentially from left to right and back again. Once the device is paired, the LED Indicators will stop flashing. 2. You can now search for the Sound Bar (VIZIO S4220w) using your Bluetooth device. For more information, see the documentation that came with your device.
Page 13: Using Bluetooth Mode
USING BLUETOOTH MODE Your Sound Bar supports music streaming from smartphones, tablets, and computers with Bluetooth capability. Device compatibility will vary, see your device’s documentation for more information. Once you have paired your source device to the Sound Bar, as long as you stay within range of the Sound Bar, your device should remain paired, even if you change the input on the Sound Bar.
Page 14: Advanced Setup
ADVANCED SETUP Connect up to five (5) different devices to the Sound Bar (devices shown are examples-you can use any device). Connection ports are located here: To listen to a device, change the input source on the Sound Bar. Optical, Coaxial, and 3.5mm cables transmit audio only.
Page 15: Wall Mounting The Sound Bar
WALL MOUNTING THE SOUND BAR Wall-Mount Back of Sound Bar Screw Holes Insert and tighten two Wall-Mount Screws with a Phillips-head screwdriver into the Wall-Mount Screw Holes. Place the included wall mounting template against the wall under your TV. Mark the four bracket holes using a pencil.
Page 16 Be sure your screws are attached to wood studs or drywall anchors (for drywall) or concrete anchors (for brick/concrete walls). Wall mounting hardware is not included. 15.75 in (400 mm) Wall Mount Screw Screw Size: M4 x 10 If you are unfamiliar with power tools or the layout of electrical wiring in the walls of your home, consult a professional installer.
Page 17: Adjusting Sound Bar Settings
1 to 12 and from 12 back to 1, a single LED at a time every 80 milliseconds. You can now search for the Sound Bar (VIZIO S4220w) using your Bluetooth Device. The sound bar will power down if no device is found.
Page 18 Function LED Behavior Description Press the TSHD button to enable/disable DTS TruSurround. When enabled DTS TruSurround Surround On: On/Off (On), TruSurround will produce a wider sound for a more enjoyable listening Surround Off: experience. TSHD...
Page 19: Help & Troubleshooting
HELP & TROUBLESHOOTING • Press the POWER button on the remote control or on the top of your Sound Bar. There is no power. • Ensure the power cord is securely connected. • Plug a different device into the electrical outlet to verify that the outlet is working correctly. •...
Page 20 DO YOU HAVE QUESTIONS? LET US HELP! YOUR PRODUCT INCLUDES FREE LIFETIME TECH SUPPORT The VIZIO support team is highly trained and is based in the United States. We can help with: • New Product Setup • Connecting Your Devices •...
Page 21 VIZIO RECOMMENDS Introducing the new E-series slim frame design. The VIZIO E-series LED TV is shattering the mold in a way only VIZIO can, with high-quality design and picture at the best value. With a stunningly slim outer frame design – and LED with 1080p Full HD for rich colors and vivid details, this HDTV gives you the best picture at the best value.
Page 22: One-Year Limited Warranty
VIZIO provides a warranty to the original purchaser of a new Product against defects in materials and workmanship for a period of one year of non-commercial usage and ninety (90) days of commercial use. If a Product covered by this warranty is determined to be defective within the warranty period, VIZIO will either repair or replace the Product at its sole option and discretion.
Page 23: Legal & Compliance
LEGAL & COMPLIANCE FCC Class B Radio Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
