Prestige APS-687E Owner's Manual

Deluxe 7 channel remote start system with keyless entry
Hide thumbs Also See for APS-687E:

Advertisement

Quick Links

Download this manual See also: Installation Manual
Table Of Contents:
Features and Options
Your "Spread Spectrum" Transmitters
Keyless Entry
Optional Remote Function Channels
Optional Additional Remote Channel 4
Optional Additional Remote Channel 5, 6, 7
Valet Override, Programming & Safety Control Switch
Vehicle Service / Remote Start Override Mode
Turbo Timer Operation
Remote Starting The Vehicle
Automatic Start Timer Operation
Telematic Upgrade
Programmed Transmitter Notification (PTN)
Programming New or Replacement Transmitters
Features And Function Setting Chart
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that may
cause undesired operation.
Warning!
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment
PATENTED: www.voxxintlcorp.com/company/patents
Model APS-687E
Owners Guide
Deluxe 7 Channel
Remote Start System
With Keyless Entry
Page 1
Page 2
Page 3
Page 3 - 4
Page 4
Page 4
Page 5
Page 6
Page 6
Page 6 - 7
Page 7 - 8
Page 9 - 10
Page 10
Page 10
Page 11
Page 12
128-9301
1 of 12

Advertisement

loading

Related Manuals for Prestige APS-687E

Summary of Contents for Prestige APS-687E

  • Page 1 Model APS-687E Owners Guide Deluxe 7 Channel Remote Start System With Keyless Entry Table Of Contents: Features and Options Page 2 Your "Spread Spectrum" Transmitters Page 3 Keyless Entry Page 3 - 4 Optional Remote Function Channels Page 4 Optional Additional Remote Channel 4...
  • Page 2 Deluxe 7 Channel Remote Start System With Keyless Entry FEATURES :  2 Five Button Programmable RF Transmitters  Seven Channel Receiver (capable of accepting 4 transmitters)  Code Hopping Technology  External Superheterodyne Antenna w/Push Button Switch and LED ...
  • Page 3 Your Spread Spectrum transmitters will shift frequencies PRESTIGE making it impossible for a thief to grab and rebroadcast your code. If your transmitter button is pressed more than fifty times while it is out of...
  • Page 4 NOTE: This system has the ability to unlock the driver's door with the first press of the unlock transmitter button and then unlock all other doors when the unlock button is pressed a second time. This op- tional feature may require additional components. Consult your installation center to determine if this feature has been added to your vehicle.
  • Page 5 ADDITIONAL REMOTE FUNCTION (CHANNEL 5) This system has an additional feature that can be connected to a number of different optional accessories. Some of the more common uses for this channel are:  Remote Trunk Release  Remote Window Closure ...
  • Page 6 PUSH-BUTTON LED RECEIVER VALET/OVERRIDE/SAFETY CONTROL SWITCH The PushButton LED switch located in the receiver allows you to temporarily disable the remote starting function of the system. This IS recommended whenever the vehicle is being serviced. To place the system in the service mode: 1) With the system disarmed/unlocked, and the ignition switch off, Press and Hold the Push-Button, found on the windshield receiver, in.
  • Page 7 TO ACTIVATE THE TURBO TIMER Anytime the ignition key is in the on position for more than 15 seconds: 1) Place the gear selector in park. 2) Set the parking, (hand), brake. 3) Be certain your foot is off the brake pedal. 4) Press the receiver's program/Push-Button switch 2 times within 5 seconds.
  • Page 8 WARNING! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device. A running engine produces dangerous carbon monoxide fumes which can be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if the car is garaged. TO REMOTE START THE VEHICLE Press and release the trunk/key button of your keychain transmitter two times within 2 seconds.
  • Page 9 OPERATING ON AUTOMATIC START UP TIMER MODE The system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine.
  • Page 10 The parking lights will flash and the siren will chirp 4 times indicating the timed start mode is activated. CANCELING THE AUTOMATIC START UP TIMER To cancel the automatic start up timer do one of the following; 1. Start the vehicle manually with the use of the ignition key and depress the brake pedal.
  • Page 11 Programming New Or Replacement Transmitters (BANK 1) Transmitter Model Name 145SP Is Also Found On Back Of Transmitter Case. Use Battery CR2032 1) Turn the ignition key to the on position. 2) Press and release the valet/programming switch 3 times (Siren Chirps). 3) Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or siren.
  • Page 12 will the system allow a transmitter button to be programmed into 2 receiver channels at the same time. This remote has the ability to operate 2 Audiovox Alarms From A Single Transmitter. To toggle on and off vehicle one or two: Press the Trunk/Key button + the Lock button for 5 seconds.
