System Summary - Eclipse Combustion Vortometric v2.00 Installation Manual

S
YSTEM SUMMARY
GENERAL SYSTEM
PARAMETERS
Customer:
Customer P.O.:
Customer signature:
Date:
Furnace type:
Furnace temperature:
Number of burners:
High fire input per burner:
Orifice sizes:
Operating voltage & frequency:
Altitude:
A-7
Write down the settings for the burner system in the table that follows:
BURNER SETTINGS
HIGH FIRE
Air pressure from the blower:
Air pressure drop across the burner:
Gas pressure drop across the burner:
Oil pressure across the burner:
Atomizing pressure drop across the burner:
Eclipse Vortometric Burner v2.00, Installation Guide 248, 6/00
LOW FIRE
Main gas pressure:
Main oil pressure:
Atomizing pressure:
Flame signal strength:
Flame length:
