PCI Express V.92 56K Internal Data/Fax Modem
PEX56KIM
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 01/22/2014
Advertisement
Table of Contents
Related Manuals for StarTech.com PEX56KIM
Summary of Contents for StarTech.com PEX56KIM
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 01/22/2014...
- Page 2 FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 4: Table Of Contents
Table of Contents Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Installation .....................2 Hardware Installation ..........................2 Driver Installation ............................3 Verifying Installation ................6 Specifications ..................7 Technical Support ..................8 Warranty Information ................8 Instruction Manual... -
Page 5: Introduction
WARNING! PCI Express cards, like all computer equipment, can be severely damaged by static electricity. Be sure that you are properly grounded before opening your computer case or touching your PCI Express card. StarTech.com recommends that you wear an anti-static strap when installing any computer component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-up by touching a large grounded metal surface (such as the computer case) for several seconds. -
Page 6: Driver Installation
5. Place the cover back onto the computer case. 6. Insert the power cable into the socket on the power supply and reconnect all other connectors removed in Step 1. 7. Connect a standard telephone cable (included) from the “Line” port on the card to the telephone outlet on the wall. - Page 7 5. From the next screen labeled Select your device’s type from the list below, select Show All Devices (should be highlighted by default), and then click Next. Note: This screen does not appear on all systems, move on to the next step if this does not apply.
- Page 8 2. Open the Device Manager by right-clicking on My Computer, and then select Manage. In the new Computer Management window, select Device Manager from the left window panel. 3. Expand the Modems section, right-click on the newly detected “PCIe CX9S610 Soft Modem”...
-
Page 9: Verifying Installation
Verifying Installation Windows 1. Open the Device Manager by right-clicking on Computer, and then select Manage. In the new Computer Management window, select Device Manager from the left window panel (For Windows 8, open the Control Panel and select Device Manager). 2. -
Page 10: Specifications
Specifications Bus Type PCI Express Card Type Standard Profile (LP bracket incl.) Chipset ID Conexant - CX95610 Port Style Integrated on Card Ports Connector Type(s) 1x PCI Express x1 Male External Port(s) 2x RJ-11 Female 56 Kbps Down Maximum Data Transfer Rate 48 Kbps Up 14.4 Kbps Fax Modem Modulation: ITU-T V.92, V.90, V.34,... -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
