StarTech.com USB562KEMH Instruction Manual

Instruction Manual
2 Port External V.92 56K USB Data/Fax Modem - Hardware Based
USB562KEMH
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x 2 Port USB 56K Modem
• 1 x RJ11 Cable
• 1 x Driver CD
• 1 x Instruction Manual
System Requirements
• Available USB port
• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64),
2000, Windows Server® 2012, 2008 R2, 2003(32/64)
Mac OS 10.7 and up (Tested up to 10.9)
Product Overview
LED Indicators
RJ11 Connectors
USB A Connector
LED Indicators
• Power (red) - Indicates whether the modem is powered
• Data (Green) - Indicates the modem is in use (dialing/connected)
For the most up-to-date information, please visit: www.startech.com
Installation
Windows
Note: The modem may auto-install using native drivers, however it
is recommended to use the procedure below to update to the latest
version.
1. Connect the device to an available USB port.
2. Insert the provided CD into your DVD/CD-ROM drive and browse
to the D:\Driver folder.
3. Select the appropriate folder for your operating system and run
the Setup.exe application.
4. Follow the on-screen instructions to complete the installation.
NOTE: You may be prompted to restart once the install completes.
Verifying Installation
1. Open the Device Manager by right-clicking on Computer, and
then select Manage. In the new Computer Management window,
select Device Manager from the left window panel (For Windows
8, open the Control Panel and select Device Manager).
2. Expand the "Modems" section. On a successful install, you should
see the following device in the list with no exclamation points or
question marks.
Manual Revision: 07/07/2014
