56K USB Dial-up and Fax Modem - V.92 - External
Product ID
USB56KEMH2
2
1
Component
• Connect the USB Dial-up and Fax Modem to a
1
RJ11 Port
Telephone Jack
• Indicates the Phone Line is being used
• Green LED Indicator
2
OH LED (Off-Hook)
• Off = Phone Line not being in used
• Steady On = Phone Line is being used
• Indicates the Phone Line is being used
• Green LED Indicator
3
Data LED
• Off = No data is being transmitted
• Flashing = Data is being transmitted
• Connect the USB Dial-up and Fax Modem to a
4
USB 2.0 Type-A Port
USB-A Port on the Host Computer
Product Information
For the latest manuals, product information, technical specifications, and declarations
of conformance, please visit:
www.StarTech.com/USB56KEMH2
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
3
4
*Product may vary from image
Function
Requirements
• USB enabled computer with an available USB Type-A port
Package Contents
• USB 56K Modem x 1
• RJ11 cable x 1
• Quick-Start Guide x1
Installation
Download
the Driver
1. Navigate to
www.StarTech.com/USB56KEMH2
2. Click the Drivers & Downloads tab.
3. Under Driver(s), download the Driver Package to the Host Computer.
Install the Driver
Windows
1. Right-Click the zipped Driver Package that was downloaded. Click Extract All.
Browse to the newly created folder.
Note: Ensure to make a note of the location where the drivers were extracted. That
location will be used on the next step.
Windows usually saves the files to the Downloads folder associated with the user
account (e.g. C:\Users\useraccount\Downloads).
2. Open the folder corresponding to the Windows version installed on the Host
Computer.
3. Right-click the Installer Setup file. Click Run as administrator.
Note: If the Run as administrator option is not available, it could indicate an attempt
to run the Installer Setup from within the zipped Driver Package. Extract the files using
the instructions in Step 1 in the Install the Driver section.
4. Follow the On-Screen Instructions to install the Device Driver. Restart the Host
Computer if prompted.
macOS
Note: No driver is required because this product is natively supported in macOS for Fax
(up to 10.6.x) and Dial-up (up to 12.x.x).
Quick-Start Guide
Manual Revision: July 2, 2024 9:39 AM
