Page 1: Table Of Contents
Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with CD AM/FM stereo with in-dash six CD Climate Controls Manual heating and air conditioning Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Tires, Wheels and Loading Tire Information Changing tires Wheel lug nut torque Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction control Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch...
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 8: Vehicle Symbol Glossary
Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Base instrument cluster Optional instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 11 Instrument Cluster Service Engine Soon: The Service Engine Soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter.
Page 12 Instrument Cluster Anti-lock brake system (if equipped): If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated. Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains...
Page 13 Instrument Cluster Traction Control active (if equipped): Flashes when the Traction Control is active. If the light remains on a malfunction has been detected; have the system serviced immediately, refer to the Driving chapter for more information. Overdrive off (automatic transmission): Illuminates when the overdrive function of the transmission has been turned off,...
Page 14 Instrument Cluster Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on. Daytime running lamps (DRL) (if equipped): Illuminates when the Daytime running lamps are on.
Page 15: Gauges
Instrument Cluster GAUGES Base instrument cluster gauges Optional instrument cluster gauges...
Page 16 Instrument Cluster Speedometer: Indicates the current vehicle speed. • Base instrument cluster • Optional instrument cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating.
Page 17 Instrument Cluster Trip odometer: Registers the miles (kilometers) of individual journeys. • Base instrument cluster Press and release the RESET button on the cluster to toggle between odometer and trip odometer display. To reset, press and hold for less than 2 seconds. •...
Page 18 Instrument Cluster Battery voltage gauge (if equipped): Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked as soon as possible. Engine oil pressure gauge (if equipped): Indicates engine oil pressure.
Page 19: Entertainment Systems
Entertainment Systems AM/FM STEREO/ SINGLE CD SOUND SYSTEM (IF EQUIPPED) Tuner: Press to manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media.
Page 20 Entertainment Systems Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting. Press MENU to access and use SEEK to adjust the volume setting.
Page 21 Entertainment Systems 10. Fast forward: Press to manually advance in a CD track. 11. Rewind: Press to manually reverse in a CD track. 12. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.
Page 22: Am/Fm Stereo With In-Dash Six Cd
Entertainment Systems SHAKER 500 — AUDIOPHILE IN-DASH SIX CD/MP3 SOUND SYSTEM (IF EQUIPPED) SHAKER 1000 — AUDIOPHILE IN-DASH SIX CD/MP3 SOUND SYSTEM (IF EQUIPPED)
Page 23 Entertainment Systems Your vehicle may be equipped with the SHAKER 1000 audio system. This system is equipped with a rack of amplifiers and subwoofers in the trunk of the vehicle. The SHAKER 1000 audio system is capable of producing very high sound pressure levels.
Page 24 Entertainment Systems will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. You can then access the stations by pressing the memory presets. To disengage, press MENU to access and press SEEK to turn the feature off.
Page 25 Entertainment Systems 4. Aux: If no auxiliary sources are available, NO AUX AUDIO will be displayed. 5. Seek: Press to access the next strong station or track. Also use in menu mode to select various settings. 6. Text: In CD mode, this feature reads and displays track song title, artist name and album title.
Page 26 Entertainment Systems 16. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. 17.
Page 27 Entertainment Systems from 01–01 to 99–99. The first two digits denote the folder number and the last two digits denote the track number within that folder. • Creating discs with only one level of folders will help with navigation through the disc files. ACCESSORY DELAY With accessory delay, the window switches, moon roof (if equipped) and audio system may be used for up to ten minutes after the ignition switch...
Page 28 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 29: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Mode selections: Controls the location of the airflow in the vehicle. See the following for a brief description of each selection. MAX A/C: Distributes recirculated air through the instrument panel vents to cool the vehicle.
Page 30 Climate Controls 6. Fan speed adjustment: Controls the volume of air circulated in the vehicle. Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the (defrost) position. • To reduce humidity build up inside the vehicle, do not drive with the airflow selector in the O (OFF) position or with recirculated air engaged.
Page 31: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER (R Ensure that the ignition is in the 3 (ON) position. Press the control to clear the rear window of thin ice and fog. The LED will illuminate. The rear window defroster turns off automatically after 10 minutes, or when the ignition is turned to the 1 (OFF/LOCK) position.
Page 32: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Foglamp control (if equipped) The foglamps can be turned on when the headlamp control is in position and the high beams are not on.
Page 33 Lights High beams Pull the lever towards you, to the second detent, to activate. Pull the lever towards you again to deactivate. Flash to pass Pull toward you, to the first detent, to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during...
Page 34 Lights Headlamp vertical aim adjustment 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away. • (1) Eight feet • (2) Center height of lamp to ground • (3) Twenty five feet •...
Page 35: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. The flash rate of the turn signal will speed up considerably if the Lighting Control Module detects a left or right turn lamp bulb (front or rear) is burned out.
Page 36 Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
Page 37 Lights 3. Remove the bulb by rotating it counterclockwise and pulling it straight out. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
Page 38 Lights Replacing front parking lamp/turn signal bulbs 1. Make sure the headlamp control is in the OFF position and open the hood. 2. Locate the lamp assembly from underneath the vehicle and rotate the bulb socket counterclockwise and remove from lamp assembly. 3.
Page 39 Lights Replacing tail lamp/brake/rear turn signal lamp bulbs The tail lamp, the brake lamp and the turn signal lamp bulbs are located in the tail lamp assembly. Follow the same steps to replace either bulb. 1. Make sure headlamp switch is in OFF position, then open the trunk.
Page 40 Lights Replacing backup bulbs The backup lamp is located in the tail lamp assembly. Follow the same steps to replace either bulb. 1. Make sure headlamp switch is in OFF position, then open the trunk. 2. Carefully remove fasteners around the lamp area, then remove the interior trunk trim.
Page 41 Lights Replacing high-mount brake lamp bulbs 1. Make sure the headlamp switch is in the OFF position and then open the trunk. 2. Inside trunk, pull the trim panel straight off of the underside of the trunk lid. 3. Locate the lighting assembly and push the release tab to access the bulb socket.
Page 42: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: For intermittent operation, move control up one position. Adjust the rotary control to the desired speed setting. For normal or low speed wiper operation, move control up two positions from OFF. For high speed wiper operation, move control up three positions from OFF.
Page 43: Steering Wheel Adjustment
Driver Controls Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 44: Power Windows
Driver Controls AUXILIARY POWER POINT (12VDC) Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet for this will damage the outlet and blow the fuse. Do not hang any type of accessory or accessory bracket from the plug.
Page 45 Driver Controls When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings. Press and pull the switches to open and close windows. •...
Page 46 Driver Controls Bounce Back Override (Front windows only) To override Bounce Back, within 2 seconds after reaching Bounce Back position, if the switch is moved from the Neutral to the Express Up position the window will travel up with no bounce back protection. If the switch is released before the window reaches fully closed position, the window will stop.
Page 47: Mirrors
Driver Controls • Push down and hold the switch to open. • Pull up and hold the switch to close. Rear Power Windows Manual Override (Convertible Only) The rear quarter window switch will not operate under the following conditions: • Convertible top is moving. •...
Page 48 Driver Controls Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release 2. Accelerate to the desired speed. 3. Press the SET + control and release it.
Page 49 Driver Controls Increasing speed while using speed control There are three ways to set a higher speed: • Press and hold the SET + control until you get to the desired speed, then release the control. • Press and release the SET + control to operate the Tap-Up function. Each tap will increase the set speed by 1 mph (1.6 km/h).
Page 50: Message Center
Driver Controls Use only soft cups in the cupholder. Hard objects can injure you in a collision. Cell phone use The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment.
Page 51 Driver Controls Selectable features Reset Press this control to select and reset functions shown in the INFO menu and SETUP menu. Info menu This control displays the following control displays: • Odometer • Trip odometer • Distance to Empty • Average Fuel Economy •...
Page 52 Driver Controls DTE is calculated using a running average fuel economy, which is based on your recent driving history of 500 miles (800 km). This value is not the same as the average fuel economy display. The running average fuel economy is reinitialized to a factory default value if the battery is disconnected.
Page 53 Driver Controls Fuel Used Select this function from the INFO menu to display the fuel used since last reset. The information displayed will be in gallons or liters, depending on English/metric mode state. Trip elapsed drive time Select this function from the INFO menu to display a timer.
Page 54 Driver Controls System check Selecting this function from the SETUP menu causes the message center to cycle through each of the systems being monitored. For each of the monitored systems, the message center will indicate either an OK message or a warning message for two seconds.
Page 55 Driver Controls 1. Press SETUP to get to the DISPLAY COLOR set up menu. 2. Pressing RESET will scroll through the following selectable colors: Green Blue Purple White Orange MyColor Adjust (to define MyColor) Adjusting MyColor: MyColor is a user defined backlighting color. The backlighting colors are achieved through the blending of light from Red, Green, and Blue LEDs.
Page 56 Driver Controls Language 1. Select this function from the SETUP menu for the current language to be displayed. 2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems.
Page 57 Driver Controls Warning display Status Low oil pressure Warning returns after 10 minutes Reduced engine power Engine failsafe mode Check engine temperature Check charging system Check traction control Traction control active Check fuel cap Low fuel level Check brake system Warning returns after the ignition key is turned from OFF to ON.
Page 58 Driver Controls when the engine is idling at a low speed, turn off as many of the electrical loads as soon as possible. If the warning stays on or comes on when the engine is operating at normal speeds, have the electrical system checked as soon as possible.
Page 59 Driver Controls SECURITY EVENT OCCURRED (if equipped). Displayed when the active anti-theft system (if equipped) was activated since the prior ignition cycle. TURN SIGNAL ON REMINDER. Displayed when the turn signal is activated and the vehicle is driven more that 1/2 mile (0.8 km). DATA ERR.
Page 60 Driver Controls To lower the convertible top: 1. Bring vehicle to a complete stop. Engage the parking brake. Key must be in the ON position. It is recommended that the vehicle’s engine is running when lowering the top to prevent draining the battery. 2.
Page 61 Driver Controls 2. Push the convertible top switch, holding it until the windows lower completely and the top unfolds and moves forward toward the windshield header. 3. Open both handles before the top meets the windshield header 4. Continue to use the convertible top switch to raise the top until it has reached the fully closed position flush to the header.
Page 62: Locks And Security
Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your dealer supplied keys, replacement keys are available through your authorized dealer.
Page 63 Locks and Security Autolock (if equipped) On vehicles equipped with an automatic transmission, this feature automatically locks all vehicle doors when: • all doors are closed, • the ignition is in the 3 (ON) position, • the brake is pressed before reaching 5 mph (8 km/h), and •...
Page 64 Locks and Security Central locking and unlocking feature Your keys can be used to lock or unlock the driver’s door and open the trunk. With the active anti-theft system (if equipped), the key can also be used to perform central locking and unlocking: •...
Page 65 Locks and Security Opening all windows (if equipped) You can open the vehicle’s windows by using the door key or the unlock control on the remote entry transmitter. Press and hold the unlock control on the remote entry transmitter, or turn the key toward the front of the vehicle and hold it for more than two seconds to begin to open all the windows.
Page 66 Locks and Security To open the luggage compartment door (lid) from within the luggage compartment, pull the illuminated “T” shaped handle and push up on the trunk lid. The handle is composed of a material that will glow for hours in darkness following brief exposure to ambient light.
Page 67 Locks and Security Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The typical operating range for your remote entry transmitter is approximately 33 feet (10 meters). A decrease in operating range could be caused by: •...
Page 68 Locks and Security equipped with active anti-theft system) are closed and locked. If the vehicle is not equipped with the active anti-theft system, the turn signal lamps will flash if all doors and the trunk are closed and locked. 2. Press and release again within three seconds to confirm that all the doors are closed and locked.
Page 69 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE RUBBER COVER AND CIRCUIT BOARD OFF THE FRONT HOUSING OF THE REMOTE ENTRY TRANSMITTER.
Page 70 Locks and Security How to reprogram your remote entry transmitters You must have all remote entry transmitters (maximum of four) available before beginning this procedure. To reprogram the remote entry transmitters: 1. Ensure the vehicle is electronically unlocked. 2. Put the key in the ignition. 3.
Page 71: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 72 Locks and Security If a problem occurs with the SecuriLock system, the indicator will flash rapidly or glow steadily when the ignition is in the 3 (ON) position. If this occurs, the vehicle should be taken to an authorized dealer for service.
Page 73 Locks and Security Programming spare keys You can program your own coded keys to your vehicle. Please read and understand the entire procedure before you begin. Tips: • A maximum of eight keys can be coded to your vehicle. • Only use Securilock keys.
Page 74 Locks and Security your vehicle’s engine and the theft indicator light will flash on and off rapidly. If failure repeats, bring your vehicle to your dealer to have the new key(s) programmed. To program additional new unprogrammed key(s), repeat this procedure from Step 1 for each additional key.
Page 75 Locks and Security If there is any potential active anti-theft problem with your vehicle, ensure ALL remote entry transmitters are taken to the dealership to aid in troubleshooting. Arming the system When armed, the active anti-theft system is designed to notify you of an unauthorized entry.
Page 76: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 77 Seating and Safety Restraints Adjusting the front manual seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Lift handle to move seat forward or backward.
Page 78 Seating and Safety Restraints Using the power lumbar support (if equipped) The power lumbar control is located on the top of the seat side shield. Press one side of the control to increase lower back firmness. Press the other side of the control to decrease lower back firmness.
Page 79 Seating and Safety Restraints Move the switch in the direction of the arrows to raise or lower the front portion of the seat cushion. Move the switch in the direction of the arrows to raise or lower the rear portion of the seat cushion. Press the switch in the direction of the arrows to move the seat forward, backward, up or down.
Page 80: Safety Restraints
Seating and Safety Restraints Use the recliner handle to return the seatback to the desired position. REAR SEATS 2nd seat/split-folding rear seat One or both rear seatbacks (coupe only) can be folded down to provide additional cargo space. To lower the seatback(s) from inside the vehicle, pull strap to release seat back and then fold seatback down.
Page 81 Seating and Safety Restraints reduce the risk of air bag-related injuries. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations. Your vehicle’s Personal Safety System consists of: •...
Page 82 Seating and Safety Restraints Front crash severity sensor The front crash severity sensor enhances the ability to detect the severity of an impact. Positioned up front, it provides valuable information early in the crash event on the severity of the impact. This allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage air bags and safety belt pretensioners.
Page 83 Seating and Safety Restraints restrain children in the rear seat. The sensor also turns off the passenger front air bag and side air bag (if equipped) when the passenger seat is empty to prevent unnecessary replacement of air bag(s) after a collision. When the front passenger seat is occupied and the sensing system has turned off the passenger’s frontal air bag, the “pass air bag off”...
Page 84 Seating and Safety Restraints • The warning light will either flash or stay lit. • The warning light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and warning light are repaired.
Page 85 Seating and Safety Restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
Page 86 Seating and Safety Restraints 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. 2.
Page 87 Seating and Safety Restraints BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the safety belt assembly “automatic locking retractor” feature or any other safety belt function is not operating properly when checked according to the procedures in Workshop Manual. Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions.
Page 88 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 89 Seating and Safety Restraints After any vehicle collision, the front passenger and rear outboard seat belt systems must be checked by a qualified technician to verify that the “automatic locking retractor” feature for child seats is still functioning properly. In addition, all seat belts should be checked for proper function.
Page 90 Seating and Safety Restraints BeltMinder The BeltMinder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders by intermittently sounding a chime and illuminating the safety belt warning lamp in the instrument cluster when the driver’s and front passenger’s safety belt is unbuckled.
Page 91 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts (All statistics based on U.S. data): Reasons given... Consider... “Crashes are rare events” 36700 crashes occur every day. The more we drive, the more we are exposed to “rare”...
Page 92 Seating and Safety Restraints Reasons given... Consider... “I’d rather be thrown Not a good idea. People who are ejected clear” are 40 times more likely to DIE. Safety belts help prevent ejection, WE CAN’T “PICK OUR CRASH”. Do not sit on top of a buckled safety belt to avoid the Belt Minder chime.
Page 93 Seating and Safety Restraints To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle. 1. Turn the ignition switch to the RUN (or ON) position. (DO NOT START THE ENGINE) 2. Wait until the safety belt warning light turns off. (Approximately 1 minute) •...
Page 94: Air Bags
(if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 95 Seating and Safety Restraints Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
Page 96 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln/Mercury dealer. Modifying or adding equipment to the front end of the vehicle...
Page 97 Seating and Safety Restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains a longitudinal deceleration sufficient to cause the air bag sensors to close an electrical circuit that initiates air bag inflation.
Page 98 Seating and Safety Restraints • a readiness light and tone • a diagnostic module • and the electrical wiring which connects the components The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system wiring (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors.
Page 99 Seating and Safety Restraints • A smaller person, such as a child who has outgrown child restraints, or a small adult occupies the front passenger seat. Even with the front passenger sensing system, children 12 and under should be properly restrained in the back seat. When the front passenger seat is occupied and the sensing system has turned off the passenger’s...
Page 100 Seating and Safety Restraints After all occupants have adjusted their seats and put on safety belts, it’s very important that they continue to sit upright with their back against the seatback, with their feet comfortably extended on the floor while the vehicle is still in motion.
Page 101 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owners Guide.
Page 102 Seating and Safety Restraints How does the side air bag system work? The design and development of the side air bag system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Air Bag Technical Working Group.
Page 103 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with...
Page 104: Child Restraints
Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Air bag supplemental restraint system (SRS) in this chapter for special instructions about using air bags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.
Page 105 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 106 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 107 Seating and Safety Restraints Follow all instructions provided by the manufacturer of the booster seat. Never put the shoulder belt under a child’s arm or behind the back because it eliminates the protection for the upper part of the body and may increase the risk of injury or death in a collision. Never use pillows, books, or towels to boost a child.
Page 108 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
Page 109 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. Children 12 and under should be properly restrained in the rear seat whenever possible. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.
Page 110 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 111 Seating and Safety Restraints 9. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward.
Page 112 Seating and Safety Restraints 1. Position the child safety seat on the seat cushion. 2. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seatback.
Page 113 Seating and Safety Restraints For Convertible only: The tether anchors on the convertible are located on the lower backside of the seatback. Note: For easier access, attach the tether with the convertible top up. 4. Access tether anchors located behind the seatback and pull away vinyl flap to expose anchors.
Page 114: Attaching Safety Seats With Latch Attachments
Seating and Safety Restraints If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments Some child safety seats have two rigid or web mounted attachments that connect to two anchors at certain seating positions in your vehicle.
Page 115 Seating and Safety Restraints Locator symbols on the seat cushion indicate the seat has LATCH anchors. The LATCH anchors are located behind the slits in the seat cushion. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments. Attach LATCH lower attachments of the child seat only to the anchors shown.
Page 116: Tires, Wheels And Loading
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 117: Tire Information
Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 118 At least once a month and before long trips, inspect each tire and check the tire pressure with a tire gauge (including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company.
Page 119 (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge.
Page 120 Tires, Wheels and Loading Maximum Permissible Inflation Pressure is the tire manufactures’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on either the tire label or certification label which is located on the B-Pillar or the edge of the driver’s door.
Page 121: Changing Tires
Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 122 Tires, Wheels and Loading label on the wheel. Both of these spare tires are considered “temporary”. Replace these temporary emergency spare tires on the vehicle with a tire of the same size, speed rating and load carrying capacity as the other road tires as soon as possible.
Page 123 Tires, Wheels and Loading Before changing the tire: 1. Park on a level surface. 2. Activate the hazard flashers. 3. Place the gearshift lever in P (Park) (automatic transmission) or R (Reverse) (manual transmission). 4. Set the parking brake. 5. Turn off the ignition. To change the tire: Note: Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 124 Tires, Wheels and Loading 3. Remove the center ornament (if equipped) from the wheel. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 4. Put the jack in the jack notch next to the tire you are changing.
Page 125: Wheel Lug Nut Torque
20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the front disc brake hub and rotor that contacts the wheel.
Page 126 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 127 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
Page 128 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
Page 129 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 130 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 131 Tires, Wheels and Loading TIRE CARE Improper or inadequate vehicle maintenance can also cause tires to wear abnormally. Here are some of the important maintenance items: Tire wear Measure and inspect the tire tread on all your tires periodically. Advanced and unusual tire wear can reduce the ability of tread to grip the road in adverse (wet, snowy, etc.) conditions.
Page 132 If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have a qualified technician at a Ford or Lincoln/Mercury dealer check the wheel alignment periodically.
Page 133 Tires, Wheels and Loading The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire rotation Rotating your tires at the recommended interval (as indicated in the scheduled maintenance information that comes with your vehicle) will help your tires wear more evenly, providing better tire performance and longer tire life.
Page 134 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln/Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 135: Vehicle Loading
Tires, Wheels and Loading Snow tires must be the same size and grade as the tires you currently have on your vehicle. If your vehicle has P215/65R16 or P235/55R17 tires, they have all weather treads to provide traction in rain or snow. However, in some climates, you may need to use snow tires and chains.
Page 136 Tires, Wheels and Loading Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 137 Tires, Wheels and Loading GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the driver’s...
Page 138 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 139 Tires, Wheels and Loading Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX pounds” on your vehicle’s placard. 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle.
Page 140: Trailer Towing
Tires, Wheels and Loading have enough cargo capacity to carry that much weight. You will need to reduce the load weight by at least 240 lb. (104 kg). If you remove 3-100 lb. (45 kg) cement bags, then the load calculation would be: 1400 –...
Page 141 Tires, Wheels and Loading If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 142: Recreational Towing
• Maximum distance is 50 miles (80 km) If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 143: Driving
Driving STARTING Positions of the ignition 1. OFF/LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. Note: The ignition key can not be removed from the ignition unless the gearshift lever is securely latched in P (Park). 2.
Page 144 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 145 Driving • Make sure the gearshift is in P (Park). • Make sure the parking brake is set. If starting a vehicle with a manual transmission: • Make sure the parking brake is set. • Push the clutch pedal to the floor...
Page 146 Driving 3. Turn the key to 3 (ON) without turning the key to 4 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate.
Page 147 Driving Starting the engine 1. Turn the key to 3 (ON) without turning the key to 4 (START). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely. 2. Turn the key to 4 (START), then release the key as soon as the engine starts.
Page 148: Brakes
Driving BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by a qualified service technician. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician.
Page 149 Driving Brake Assist (if equipped) The Brake Assist system provides full braking force during panic braking situations. It detects a rapid application of the brake pedal and maximizes the amount of brake booster assist, helping the driver to achieve maximum braking pressure. Once a panic brake application is detected, the system will remain activated as long as the brake pedal is depressed.
Page 150: Traction Control
Driving • Do not operate the vehicle with a low power steering pump fluid level (below the MIN mark on the reservoir). If the power steering system breaks down (or if the engine is turned off), you can steer the vehicle manually, but it takes more effort. If the steering wanders or pulls, check for: •...
Page 151: Transmission Operation
Driving The Traction Control switch, located above the radio, illuminates when the system is off. The Traction Control system will automatically turn on every time the ignition is turned OFF and ON. If you should become stuck in snow or ice or on a very slippery road surface, try switching the Traction Control system off.
Page 152 Driving If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1. Apply the parking brake, turn ignition key to LOCK, then remove the key. 2. Using a flat head screwdriver, remove the plastic cover. 3.
Page 153 Driving Understanding the gearshift positions of the 5–speed automatic transmission This vehicle is equipped with an adaptive Transmission Shift Strategy. Adaptive Shift Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
Page 154 Driving To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle.
Page 155 Driving • Overdrive mode is automatically returned each time the key is turned off. 3 (Third) This position allows for third gear only. • Provides engine braking. • To return to D (Drive) without Overdrive, move the transmission shift lever into the D (Drive) position. •...
Page 156 Driving MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch The manual transmission has a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. To start the vehicle: 1. Make sure the parking brake is fully set. 2.
Page 157 Driving Reverse 1. Make sure that your vehicle is at a complete stop before you shift into R (Reverse). Failure to do so may damage the transmission. 2. Move the gearshift lever into the neutral position and wait at least three seconds before shifting into R (Reverse).
Page 158: Roadside Emergencies
50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...
Page 159: Hazard Flasher Switch
1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673;...
Page 160: Fuel Pump Shut-Off Switch
Roadside Emergencies FUEL FUEL PUMP SHUT-OFF SWITCH RESET This device stops the electric fuel pump from sending fuel to the engine when your vehicle has had a substantial jolt. After an accident, if the engine cranks but does not start, this switch may have been activated.
Page 161 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 162 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Mini relay Accessory delay #1 — Not used Wiper power Power mirrors — Not used Accessory delay feeds Overdrive cancel Cluster, Data Link Connector (DLC) —...
Page 163 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Restraint Control Module (RCM), Passenger Occupant Detection System (PODS), Passenger Air bag Deactivation Indicator (PADI) Anti-lock Brake System (ABS), Positive Crankcase Ventilation (PCV) valve heater, Ignition Powertrain Control Module (PCM) relays, Passive Anti-Theft System (PATS) Radio (Start)
Page 164 Roadside Emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Not used 30A* Climate control blower 40A* Cooling fan 30A* Starter 30A* Right front window motor 30A* Rear amplifier (Shaker 1000 radio) 30A* Left front window motor...
Page 165 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 30A* Convertible top 30A* Seat — Not used 30A* Front amplifier (Shaker 500 radio) Mini relay PCM #2 Micro relay Fuel pump Mini relay Starter Micro relay PCM #1 Micro relay A/C clutch Mini relay...
Page 166 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 25A** Horn 15A** Engine #1 Diode A/C clutch 15A** A/C clutch 15A** High beams 10A** Convertible top 30A** Rear defroster Diode 10A** PCM delay — Not used 20A** Radio 20A** Decklid release 15A**...
Page 167: Jump Starting
Roadside Emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes and clothing, if contacted.
Page 168 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) jumper cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 169 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 170 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 171 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 172: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the front using wheel lift equipment, it is recommended that the rear wheels (drive wheels) be placed on a dolly to prevent damage to the transmission.
Page 173: Customer Assistance
Center at the number below. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 174 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 175 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the...
Page 176 THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes. • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford...
Page 177 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 178 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 179 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 180 4,600 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 181: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 182: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 183 Cleaning • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips. • Always read the instructions before using the products. ALUMINUM WHEELS AND WHEEL COVERS Aluminum wheels and wheel covers are coated with a clearcoat paint finish.
Page 184 Cleaning • 4.0L SOHC V6 engine • 4.6L 3V SOHC V8 engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage.
Page 185 Cleaning PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3–A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
Page 186 Cleaning Do not use chemical solvents or strong detergents when cleaning the steering wheel or instrument panel to avoid contamination of the air bag system. • Be certain to wash or wipe your hands clean if you have been in contact with certain products such as insect repellent and suntan lotion in order to avoid possible damage to the interior painted surfaces.
Page 187 FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 188 Cleaning Motorcraft Detail Wash (ZC-3–A) Motorcraft Tire Clean and Shine (ZC-28) Motorcraft Triple Clean (ZC-13) Motorcraft Ultra-Clear Spray Glass Cleaner (not available in Canada) (ZC-23) Motorcraft Engine Shampoo and Degreaser (ZC-20)
Page 189: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 190 Maintenance and Specifications • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral). 2. Block the wheels. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1.
Page 191: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Engine coolant reservoir 8.
Page 192 Maintenance and Specifications 4.6L 3V SOHC V8 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Engine coolant reservoir 8. Windshield washer fluid reservoir 9.
Page 193: Engine Oil
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 194 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). • 4.0L V6 engine • 4.6L 3V V8 engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN—MAX marks, the oil level is acceptable.
Page 195 Maintenance and Specifications • 4.0L V6 engine • 4.6L 3V SOHC V8 engine • Oil levels above the MAX mark may cause engine damage. Some oil must be removed from the engine by a service technician. 7. Put the indicator back in and ensure it is fully seated. Adding engine oil 1.
Page 196 Approval Committee (ISLAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 197 Change your engine oil according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 198: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the Scheduled Maintenance Guide for the service interval schedules.
Page 199 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 200 Maintenance and Specifications will not affect function or durability of the transmission. Over time the adaptive learning process will fully update transmission operation to its optimum shift feel. If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected.
Page 201 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 202 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA and OR), VC-7–B (CA and OR only), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
Page 203 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 204 Maintenance and Specifications Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section. Fill your engine coolant reservoir as outlined in Adding engine coolant in this section. Severe climates If you drive in extremely cold climates (less than –34°...
Page 205 Maintenance and Specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The “engine coolant temperature” indicator will illuminate. • The Service engine soon indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.
Page 206: Fuel Information
Maintenance and Specifications Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible. WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire.
Page 207 Maintenance and Specifications • Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. •...
Page 208 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 209 Gasolines that meet the World-wide Fuel Charter should be used when available. Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality.
Page 210 Maintenance and Specifications Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: • You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 211 Maintenance and Specifications vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank. For consistent results when filling the fuel tank: •...
Page 212 Maintenance and Specifications Habits • Smooth, moderate operation can yield up to 10% savings in fuel. • Steady speeds without stopping will usually give the best fuel economy. • Idling for long periods of time (greater than one minute) may waste fuel.
Page 213 Maintenance and Specifications • Adding certain accessories to your vehicle (for example bug deflectors, rollbars/light bars, running boards, ski/luggage racks) may reduce fuel economy. • Using fuel blended with alcohol may lower fuel economy. • Fuel economy may decrease with lower temperatures during the first 8–10 miles (12–16 km) of driving.
Page 214 Maintenance and Specifications If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 215 Maintenance and Specifications 3. The fuel cap may not have been securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel and/or properly tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the Check engine/Service engine soon light should turn off.
Page 216 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be...
Page 217 Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid The 5R55S transmission does not have a transmission fluid dipstick. Refer to your Scheduled Maintenance Guide for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 218 Maintenance and Specifications Checking and adding manual transmission fluid (if equipped) 1. Clean the filler plug. 2. Remove the filler plug and inspect the fluid level. 3. Note: There are two different manual transmissions used in this vehicle and they have different fluid levels. For vehicles equipped with a V6 engine the correct manual transmission fill level is at the lower edge of the filler hole.
Page 219: Part Numbers
4. Add enough fluid through the filler opening to bring the fluid up to the recommended levels. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter. MOTORCRAFT PART NUMBERS Component 4.0L V6 engine...
Page 220: Refill Capacities
Refer to the Scheduled Maintenance Guide for the appropriate intervals for changing the PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 221 Fill 1/4 inch to 9/16 inch (6 mm to 14 mm) below bottom of fill hole. Add 4 oz. (118 ml) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles.
Page 222: Lubricant Specifications
Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford specification WSS-M2C929-a (4.0L) or WSS-M2C930-A (4.6L) and the API Certification mark.
Page 223 Maintenance and Specifications Item Ford part Ford part Ford name number specification Engine oil 4.6L engine XO-5W20-QSP WSS-M2C Motorcraft SAE (US) 930-Awith API 5W-20 Super CXO-5W20–LSP12 Certification Premium Motor (Canada) Mark Oil (US) Motorcraft SAE 5W-20 Super Premium Motor Oil (Canada) 4.0L V6 engine...
Page 224 Ford specification EST-M2C118-A for complete refill of Traction-Lok axles. Ford design rear axles contain a synthetic lubricant that does not require changing unless the axle has been submerged in water. Ensure the correct automatic transmission fluid is used. MERCON and MERCON V are not interchangeable.
Page 225 Maintenance and Specifications VEHICLE DIMENSIONS Vehicle dimensions Base - inches (mm) GT - inches (mm) (1) Vehicle height 55.4 (1407) 55.4 (1407) (2) Track Width- 62.8 (1594) 62.3 (1582) Front (2) Track Width- Rear 63.0 (1600) 62.5 (1588) (3) Vehicle width 73.9 (1877) 73.9 (1877) (4) Wheelbase...
Page 226: Certification Label
Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety MFD. BY FORD MOTOR CO. IN U.S.A. Administration Regulations require DATE: XXXXX GVWR:XXXXXXXXXXXX that a Certification label be affixed FRONT GAWR: XXXXXX/XXXXXXX REAR GAWR: XXXXXXX/XXXXXXX to a vehicle and prescribe where the THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL Certification label may be located.
Page 227 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block and transmission.
Page 228: Accessories
Accessories GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local authorized Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs;...
Page 229 Accessories Interior style Electrochromatic compass/temperature interior mirrors Floor mats Lifestyle Bike racks Cargo organization and management Peace of mind First aid and highway safety kits Full vehicle covers Locking gas cap Keyless entry Keyless entry keypad Remote start Vehicle security systems Mobile-ease hands-free communication system Wheel locks For maximum vehicle performance, keep the following information in...
Page 230 Amateur Radio Antennas in the area of the driver’s side hood. • Electrical or electronic accessories or components that are non-Genuine Ford Accessories added to the vehicle by the dealer or the owner may adversely affect battery performance and durability.
Page 231: Index
Index replacement, specifications ...219 servicing ........198 Accessory delay ......45 BeltMinder ........90 Air bag supplemental restraint Brakes ........148 system ......94–95, 101 anti-lock ......148–149 and child safety seats ....96 anti-lock brake system (ABS) description ......95, 101 warning light ......148 disposal ........103 fluid, checking and adding ..216 driver air bag ....97, 102 fluid, refill capacities ....220 indicator light ......103...
Page 232 Emission control system ..213 Cruise control (see Speed control) ....47 Engine ........224–225 cleaning ........183 Customer Assistance ....158 coolant ........200 Ford accessories for your fail-safe coolant ......204 vehicle ........187 idle speed control ....198 Ford Extended Service lubrication specifications ..222, Plan ..........180 refill capacities ......220...
Page 233 Index bulb specifications ....36 daytime running lights .....32 Fail safe cooling ......204 flash to pass ......33 Floor mats ........59 high beam .........33 replacing bulbs ......36 Fluid capacities ......220 turning on and off ....32 Foglamps ........32 Heating Fuel ..........206 heating and air conditioning calculating fuel system ........29 economy ......52, 210...
Page 234 Index Lamps Octane rating ......209 bulb replacement Oil (see Engine oil) ....193 specifications chart ....36 daytime running light ....32 fog lamps ........32 headlamps ......32, 36 Parking brake ......149 headlamps, flash to pass ..33 Parts (see Motorcraft parts) ..219 instrument panel, dimming ..33 interior lamps ......35 Passenger Occupant replacing bulbs ....35–41...
Page 235 Index Safety restraints ....80, 84–88 label .........130 belt minder .......90 replacing ........121 extension assembly ....93 rotating ........133 for adults ......85–88 safety practices .......132 for children ......104 sidewall information ....125 Occupant Classification snow tires and chains ....134 Sensor ........82 safety belt maintenance ...94 spare tire .........121 warning light and chime ..89 terminology ......117...
Page 236 Index Windshield washer fluid and wipers Warning lights (see Lights) ..10 checking and adding fluid ..193 Washer fluid ......193 operation ........42 Water, Driving through .....157 replacing wiper blades .....43 Windows Wrecker towing ......172 power .........44...
