Campbell Hausfeld Sanders Operating Instructions Manual

See Warranty on page 4 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
BUILT TO LAST
Description
Sanders are air tools designed for
automotive applications on both flat
and contour surfaces.
Unpacking
When unpacking this product,
carefully inspect for any damage that
may have occurred during transit.
General Safety
Information
CALIFORNIA PROPOSITION 65
DANGER
!
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
This manual contains information that
is very important to know and under-
stand. This information is provided for
SAFETY and to PREVENT EQUIPMENT
PROBLEMS. To help recognize this
information, observe the following
symbols.
Danger indicates
DANGER
!
an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
Warning indicates
WARNING
!
a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
Caution indicates a
CAUTION
!
potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Notice indicates
NOTICE
important
information, that if not followed, may
cause damage to equipment.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2002 Campbell Hausfeld/Scott Fetzer
This product is a part of a high pressure
system and the following safety
precautions must be followed at all
times along with any other existing
safety rules.
1. Read all manuals
included with this
product carefully. Be
thoroughly familiar with
the controls and the
proper use of the equipment.
2. Only persons well acquainted with
these rules of safe operation should
be allowed to use the air tool.
CAUTION
!
Do not exceed the maximum
operating pressure of the air
tool (90 PSI). This can reduce
the life of the tool.
3. Do not exceed any pressure rating
of any component in the system.
Maximum operating pressure of 90
PSI is measured at the tool inlet
while the tool is running. The
pressure drop between the
compressor and tool needs to be
compensated for at the compressor.
4. Disconnect the air tool from air
supply before changing tools or
attachments, servicing and during
non-operation.
WARNING
!
Safety glasses and ear
protection must be worn
during operation.
5. Do not wear loose fitting clothing,
scarves, or neck ties in work area.
Loose clothing may become caught
in moving parts and result in
serious personal injury.
6. Do not wear jewelry when
operating any tool. Jewelry may
become caught in moving parts and
result in serious personal injury.
7. Do not depress trigger when
connecting the air supply hose.
For parts, product & service information
visit www.chpower.com
Sanders
8. Always use attachments designed
for use with air powered tools. Do
not use damaged or worn
attachments.
9. Never trigger the tool when not
applied to a work object.
Attachments must be securely
MANUAL
attached. Loose attachments can
cause serious injury.
10. Protect air lines from damage or
puncture.
11. Never point an air tool at oneself or
any other person. Serious injury
could occur.
12. Check air hoses for weak or worn
conditions before each use. Make
sure all connections are secure.
WARNING
!
Release all pressure from
the system before
attempting to install,
service, relocate or perform any
maintenance.
13. Keep all nuts, bolts and screws tight
and ensure equipment is in safe
working condition.
14. Do not put hands near or
under moving parts.
15. Always secure workpiece
in a vise or clamp.
WARNING
!
exposure to vibration, work in
awkward positions, and repetitive
work motions can cause injury to hands
and arms. Stop using any tool if
discomfort, numbness, tingling, or pain
occur, and consult a physician.
Operation
LUBRICATION
Proper lubrication is the owner's
responsibility. Failure to lubricate the
air tool properly will dramatically
shorten the life of the tool and will
void the warranty.
Do not misuse this
product. Excessive
IN241202AV 11/02
