See Warranty on page 5 for important information about commercial use of this product.
Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
BUILT TO LAST
Description
Detail sanders are designed for
uniform sanding and polishing in
corners and tight spaces. Ideal for flush
sanding along edges This sander has a
built-in dust port for vacuum or dust
bag attachment.
Unpacking
When unpacking this product, carefully
inspect for any damage that may have
occurred during transit.

General Safety

This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
WARNING
!
To help recognize this information,
observe the following symbols.
contains chemicals known to the State
of California to cause cancer and birth
Danger indicates
DANGER
!
defects or other reproductive harm.
an imminently
Wash hands after handling.
hazardous situation which, if not
avoided, will result in death or serious The following safety precautions must be
injury.
followed at all times along with any
Warning indicates other existing safety rules.
WARNING
!
a potentially
1. Read all manuals
hazardous situation which, if not
included with this
avoided, could result in death or serious
product carefully. Be
injury.
thoroughly familiar with
Caution indicates a
CAUTION
! the controls and the
potentially
proper use of the equipment.
hazardous situation which, if not
avoided, may result in minor or moderate 2. Only persons well acquainted with
injury.
these rules of safe operation should
Notice indicates be allowed to use the tool.
NOTICE
important
information, that if not followed, may WARNING
!
cause damage to equipment.
glasses and ear protection
CALIFORNIA PROPOSITION 65
must be worn during
You
DANGER operation.
!
can
3. Do not wear loose fitting clothing,
create dust when you cut,
scarves, or neck ties in work area.
sand, drill or grind
materials such as wood, Loose clothing may become caught
paint, metal, concrete, in moving parts and result in serious
cement, or other masonry. This dust
personal injury.
often contains chemicals known to
4. Do not wear jewelry when
cause cancer, birth defects, or other
operating any tool. Jewelry may
reproductive harm. Wear protective
become caught in moving parts and
gear.
result in serious personal injury.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2006 Campbell Hausfeld/Scott Fetzer
For parts, product & service information
visit www.chpower.com
Detail Sander
This product or its 5. Always use attachments designed
power cord for use with this tool. Do not use
damaged or worn attachments.
6. Never trigger the tool when not
applied to a work object.
Attachments must be securely
attached. Loose attachments can
cause serious injury.
7. Never point a tool at oneself or any
other person. Serious injury could
occur.
MANUAL
8. Use steady, even pressure when
using tool. Do not force. Too much
pressure can cause tool to overheat.
9. Keep all nuts, bolts and screws tight
and ensure equipment is in safe
working condition.
10. Do not put hands near or under
moving parts.
Safety
Specifications
Tool
Voltage
Power Rating
Sanding Surface
Weight
DG480000CK
120V 60Hz
0.8 A
140 x 140 x
80 mm
2 lbs.
IN714300AV 3/06
