Campbell Hausfeld AT122601 Operating Instructions Manual

See warranty on page 8 for important information about commercial use of this product.
operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
BUILT TO LAST
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety .Guidelines . . . . . . . . . . . . . . . . . .1
General .Safety .Information . . . . . . . . .1
Assembly . . . . . . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . . . . .3
Technical .Service . . . . . . . . . . . . . . . . . .3
Types .of .Abrasives . . . . . . . . . . . . . . . . .4
Suggested .Uses . . . . . . . . . . . . . . . . . . . .5
Troubleshooting .Chart . . . . . . . . . . . . . . . . . . . . . . . . . .6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . .8
Description
Campbell .Hausfeld .sandblasting .
equipment .is .designed .for .cleaning .and .
removing .rust, .scale, .and .paint . .It .is .the .
ideal .method .for .stripping, .polishing .
and .etching .projects . .This .equipment .
can .be .used .with .sand, .abrasive .
powders, .water .and .other .liquids . .
Unpacking
After .unpacking .the .unit, .inspect .
carefully .for .any .damage .that .may .
have .occurred .during .transit . .Make .sure .
to .tighten .fittings, .bolts, .etc ., .before .
putting .unit .into .service .
ReaD & Follow all InSTRUCTIonS
Save TheSe InSTRUCTIonS
Do noT DISCaRD
Safety Guidelines
This .manual .contains .information .
that .is .very .important .to .know .and .
© .2007 .Campbell .Hausfeld/Scott .Fetzer
understand . .This .information .is .
provided .for .SAFETY .and .to .PREVENT .
EQUIPMENT .PROBLEMS . .To .help .
recognize .this .information, .observe .the .
following .symbols .
an imminently hazardous situation
which, if not avoided, WILL result in
death or serious injury.
a potentially hazardous situation which,
if not avoided, COULD result in death or
serious injury.
a potentially hazardous situation which,
if not avoided, MAY result in minor or
moderate injury.
important information, that if not
followed, may cause damage to
equipment.
noTe: .Information .that .requires .special .
attention .
General Safety Information
CalIFoRnIa pRopoSITIon 65
or its power cord may contain chemicals
known to the State of California to
cause cancer and birth defects or other
reproductive harm. Wash hands after
handling.
You can create dust when
you cut, sand, drill or grind
materials such as wood,
paint, metal, concrete, cement, or other
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For .parts, .product .& .service .information
visit .www.chpower.com
aT122601, aT125102, aT121002, and aT121102
Sandblasting
Kits
Danger
indicates
Warning
indicates
Caution
indicates
Notice
indicates
This
product
masonry. This dust often contains
chemicals known to cause cancer, birth
defects, or other reproductive harm.
Wear protective gear.
STaTIC eleCTRICITy
Fire or Explosion Hazard!
Never use a sand blaster
around combustible or
flammable liquids, gases,
dusts, oily rags, or other
materials that can explode or
burn quickly. Some abrasives
create sparks when they hit
metal. Abrasives similar to aluminum
oxide may generate static electric
sparks. In an unsafe environment, these
sparks will start fires or explosions that
will result in death or serious personal
injury. For your safety and the safety
of people nearby, DO NOT USE this sand
blaster where there are combustible
or flammable liquids, gases, dusts,
oily rags, or other materials that can
explode or burn quickly.
Static electric shocks can
be painful. Some abrasives
similar to aluminum oxide can
create static electricity while you are
sand blasting. If you are not grounded,
the static electricity can build up on
your body and cause a shock when
you touch a metal object. You can
avoid static electricity by wearing
leather soled shoes and standing on
the ground. If necessary, a grounded
wire attached to the sand blast gun
will safely remove the static electricity.
Remember, you are not grounded if
you are insulated from the ground.
Rubber soled shoes, rubber boots, or
other rubber or plastic footwear are
insulators. Avoid standing on dry wood
IN239801AV .12/07
