BRIDGE ALARM SYSTEM BR-1000
SAFETY INSTRUCTIONS .............................................................................................................i
SYSTEM CONFIGURATION ........................................................................................................ii
EQUIPMENT LISTS.....................................................................................................................iii
1. HOW TO INSTALL THE EQUIPMENT .................................................................................1-1
1.1 Bridge Panel....................................................................................................................1-1
1.2 Processor Unit.................................................................................................................1-3
1.3 Cabin Panel, Timer Reset Panel.....................................................................................1-4
1.4 AC-DC Power Supply......................................................................................................1-5
1.5 Watertight Timer Reset Panel .........................................................................................1-6
2. HOW TO CONNECT EXTERNAL EQUIPMENT ..................................................................2-1
2.1 Connections Inside the Processor Unit ...........................................................................2-1
2.2 AC-DC Power Supply......................................................................................................2-5
OPERATOR FITNESS IN Signals...................................................................................2-7
3. HOW TO SET AND CHECK THE SYSTEM .........................................................................3-1
3.1 How to Set and Connect the PC for Maintenance ..........................................................3-1
3.2 Settings for Bridge Panel BR-1010 .................................................................................3-3
3.3 Settings for Processor Unit BR-1020 ............................................................................3-25
3.4 System Operation Check ..............................................................................................3-30
3.5 Service Menu ................................................................................................................3-34
3.6 How to Edit the Alarm List.............................................................................................3-42
APPENDIX 1 JIS CABLE GUIDE...........................................................................................AP-1
PACKING LISTS....................................................................................................................... A-1
OUTLINE DRAWINGS.............................................................................................................. D-1
INTERCONNECTION DIAGRAMS........................................................................................... S-1
PROCESSOR UNIT CONNECTION LISTS.............................................................................. S-3
