SHIP SECURITY ALERT SYSTEM (SSAS)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSAS and is the answer not in the manual?

Questions and answers

Summary of Contents for Furuno SSAS

  • Page 1 SHIP SECURITY ALERT SYSTEM (SSAS)
  • Page 2: Table Of Contents

    3.1 Operation Mode ......................12 3.1.1 Changing the password ..................12 3.1.2 SSAS manager mode ................... 13 3.2 Setting SSAS Report Destination and Message Contents..........14 3.3 Transmitting SSAS Report .................... 17 3.4 Testing the Button ......................19 3.5 SSAS Report Test ......................23 OUTLINE DRAWING ....................D-1...
  • Page 3: System Configuration

    SYSTEM CONFIGURATION Regulations require at least two SSAS units. FELCOM 15 ANTENNA UNIT IC-115 DGPS EGC Printer 24 VDC PP-50 100/115/220/230 VAC TERMINAL UNIT 1φ, 50/60 Hz IC-215 Personal AC-DC Power Supply Printer Computer PR-240-CE*2 (PC/AT compatible) GPS receiver 12/24...
  • Page 4: Connections

    JUNCTION BOX * Any AC-DC power supply IC-315 : Option fulfilling requirements of : Local Supply IEC 60945 may be used. : SSAS only SSAS ALERT UNIT IC-307 CATEGORY OF UNITS SSAS ALERT UNIT Antenna Unit Exposed to Weather IC-307...
  • Page 5: Overview Of Ssas

    No audible or visible alarm is generated while the SSAS report is being transmitted, to prevent discovery of the report by the intruders. The SSAS is protected with a password to prevent unauthorized setting or testing of it by other than the ship’s captain or authorized personnel.
  • Page 6 Open the cover of the button and then press the button. (This is a latch-type button; hit and release to activate the button.) ¯ If addresses have been preset, the SSAS report is sent to one address 30 seconds after the button is activated. (Max. 5 addresses) (You may cancel transmission of the SSAS report by pressing the button again with 30 seconds of the initial press.)
  • Page 7: Installation

    2.1 Mounting 2.1.1 Junction box (for FELCOM 16) The junction box IC-315 is required when installing the SSAS on the FELCOM 16; it is already installed on the FELCOM 15. Separate the junction box from a magnetic compass by the distances shown below to prevent deviation to a magnetic compass.
  • Page 8: Ssas Alert Unit

    2.1.2 SSAS alert unit Separate the junction box from the SSAS alert unit by the distances shown below to prevent deviation to a magnetic compass. Standard compass: 0.70 m Steering compass: 0.45 m Locate the SSAS alert unit where it cannot be found by intruders. The location should be known only by ship’s captain and authorized personnel.
  • Page 9 5. Attach the switch cover as shown below. Note that the cover may also be rotated 180 degrees. Press here and hold down for five seconds. Switch cover Flush mounting The optional flush mount kit OP16-28 (Code No. 004-448-010) is required. Name Type Code No.
  • Page 10: Wiring

    2.2 Wiring 2.2.1 Junction box (for FELCOM 16) Use the junction box IC-315 to connect the SSAS alert unit to the FELCOM 16. Unfasten four screws to remove the cover to connect cables to terminal board. For detailed wiring information see the interconnection diagram.
  • Page 11: Ssas Alert Unit

    2.2.2 SSAS alert unit Three SSAS alert units can be connected in series to the Junction Box IC-315. Use the terminals on the SSAS ALERT Board 16P0229 commonly and two connector entrances. To differentiate between units in case of multiple unit installation, change jumper block settings as shown below, in accordance with how many units are installed.
  • Page 12: Initial Settings

    FELCOM 16 6. Press [1], [Enter]. This enables the SSAS functions. 7. Press the [Esc] key several times to close the menu. Note: Test the SSAS button and SSAS report for proper operation, referring to paragraphs 3.4 and 3.5, respectively.
  • Page 13: Operation

    2. Internal GPS Setup Enter JOB No. : 3. On the Enter JOB No. field, type “ssas password” (without quotation marks) and then press the [Enter] key. The prompt OLD PASSWORD appears. 4. Type your current password and then press the [Enter] key. The prompt NEW PASSWORD appears.
  • Page 14: Ssas Manager Mode

    2. Internal GPS Setup Enter JOB No. : 3. On the Enter JOB No. field, type “ssas manager” (without the quotation marks) and then press the [Enter] key. 4. Type password and then press the [Enter] key. The window below appears; you are now in the SSAS manager mode.
  • Page 15: Setting Ssas Report Destination And Message Contents

    When the SSAS is activated, the SSAS report is sent according to the addresses (max. 5) and message content set with SSAS Report 1 – SSAS Report 5 on the SSAS Report menu. Note 1: The destination and message content of an SSAS report varies according to Administration.
  • Page 16 9. Enter time interval (00:10-99:59) to transmit the SSAS report and then press the [Enter] key. Note: After the SSAS report is transmitted and the button remains “ON” ( ), the SSAS report is transmitted at the interval set here.
  • Page 17 23. Press the [Esc] key twice to return to the standby display. Note 1: To delete entered subscriber’s data, choose “Remove” from “Status.” Note 2: SSAS report settings may be saved to a floppy disk for backup. FELCOM 15: [F8], [9], [6] to show the Save/Load window.
  • Page 18: Transmitting Ssas Report

    3.3 Transmitting SSAS Report In the normal mode, the SSAS report is sent 30 seconds after the button on the SSAS is pressed. The SSAS repeatedly transmits the report even if the button is pushed off ( ). Repeated transmission can only be stopped from the SSAS manager mode.
  • Page 19 OFF→ON→OFF→ON→OFF. You must allow no more than three seconds to elapse before pushing the button again. If more than three seconds elapses, repeat the procedure. When transmission is stopped, the message “INF: SSAS UNIT activation has been cancelled.” appears and, on the FELCOM 16 only, the POWER lamp on the communication unit flashes approx.
  • Page 20: Testing The Button

    6. Push the button in ( ). The CAUTION window displays the message “SSAS UNIT works correctly.” appears if the unit is functioning properly. Note: 30 seconds after step 6, the SSAS test report is automatically sent. If you do not need to send the SSAS report, go to step 8 within 30 seconds.
  • Page 21: Felcom 16

    4. If you do not need to send the test report, skip to step 7. 5. 30 seconds after LEDs start flashing the SSAS test report is sent once to the address specified for the youngest SSAS report number (1-5). At this time the LEDs flash rapidly.
  • Page 22: Felcom 16

    Note 3: The ERROR LED flashes if the button of an SSAS stays on for more than 10 seconds. It also flashes when the equipment switches to the normal mode (see Note 2). Turn off the button to stop the LED from flashing.
  • Page 23 Note: If the button is left pushed in ( ) when the communication unit is turned on, the equipment will go into the test mode if the SSAS is not transmitting repeatedly. To return to the standby display, push the button again to pop it out ( ) and then turn the communication unit off and on again.
  • Page 24: Ssas Report Test

    1. Press the [F5] key to open the Reports menu. 2. Press the [4] key to choose the SSAS Report menu. 3. Press the [1], [2], [3], [4] or [5] key as appropriate, and the SSAS report setting menu appears.
  • Page 26 Takahashi T...
