Abocom CAS1040 Specification Sheet

CAS1040
IP Share + Fast EtherSwitch
for Cable/xDSL Modem
Connect Internet and your Office/Home network
Sharing for Hi-speed Surfing
No need to apply for additional IP address or account, multi-users can
share just one this device, single IP address, and one Cable/xDSL Modem
for Internet surfing concurrently.
Plug & Play
Both DHCP client and server can complete the network configuration for
the device self and all computers on local network automatically. Zero
configuration effort is needed for users. Especially the 4 port
EtherSwitch design, users can just plug the cable into the device without
buying additional Hub/Switch.
Incoming Mail Indication
This product can check incoming mail for user periodically. User can
power on his computer to collect and read mail until this product blinks
the mail LED.

Specifications

Protocols
IP, NAT, ARP, ICMP, DHCP client/server, PPPoE, PPP , PAP, CHAP
Management
Telnet through network.
GUI program for Windows 95/98/ME/NT/2000 through network.
Local
4 ports 10/100Base-T N-way Ethernet Switching.
Internet
10Base-T Ethernet port to external Cable/DSL Modem, or other
network equipment.
MDIX/MDI Buttons
One for local uplink, the other for Cable/DSL modem connectivity.
LED Indicators
Power/Error Green/Red
Local x 4 100/10 Green/Orange
Internet 10 Orange
HaveMail Green
Electronic Specifications
Input Power DC 5V, @2.4A
Agency and Regulatory: FCC part 15 Class B, VCCI, CE
Physical Dimension: 160 x 105.4 x 27 mm (L x W x H)
Weight: 218g
Operating Temperature: 0 C to 50 C
Operating Humidity: 0-90% non-condensing
3
Features
Web UI management.
Support PPPoE.
Support VPN( PPTP pass thru )
LED indicator for received E-Mail.
Up to 8Mbps performance.
MDI/MDIX button for both LAN/WAN port uplink
Internet applications such as Web browser , ICQ, FTP,
Telnet, E-Mail, AoE, News, NetMeeting, Ping, mIRC, AOE,
PCAnyWhere......
DHCP server allocates up to 253 client IP addresses.
Proxy DNS.
Virtual server.
DMZ host
Rich Packet Filters.
Static routing.
Installation wizard.
Allow firmware upgrade through network.
Support Windows 95/98 /ME/NT/2000, Unix, and Mac.
Natural firewall keeps hackers out.
Carrier
ISP
Services
IP Share
10Mbps
Ethernet
Firewall
Cable / DSL
Modem
10/100Mbps Ethernet
