PLE0085
HomePlug 1.0 Turbo Ethernet Adapter
-
1 Power Line Port
-
1 Ethernet Port
Description
The PLE0085 provides convenient powerline access to
office/family users by sharing a simple AC power line
network.
Embedded Homeplug 1.0 Turbo interface
enables you to connect one PC ethernet port to another PC's
at other end of power line, and not limited by the wall or
layer that block RF wireless communication.
Features
1 Power Line Port
1 Ethernet Port
Full Compatibility tested
Advertisement
Related Manuals for Abocom HomePlug 1.0 Turbo Ethernet Adapter PLE0085
Summary of Contents for Abocom HomePlug 1.0 Turbo Ethernet Adapter PLE0085
- Page 1 PLE0085 HomePlug 1.0 Turbo Ethernet Adapter 1 Power Line Port 1 Ethernet Port Description The PLE0085 provides convenient powerline access to office/family users by sharing a simple AC power line network. Embedded Homeplug 1.0 Turbo interface enables you to connect one PC ethernet port to another PC’s at other end of power line, and not limited by the wall or layer that block RF wireless communication.
- Page 2 Specification Main Chipset Standard Support Interface Power Dimension (W x D x L) Operating Storage ERTIFICATIONS Intellon INT5500 + RTL8201 HomePlug 1.0 (14Mbps) & 1.0 Turbo (85Mbps) One Power Line port Power: Yellow-Green Powerline Link/Act: Yellow-Green Ethernet Link/Act: Yellow-Green AC 100~240V/ 50~60HZ/ 0.5A 103mm x 71.4mm x 27.8 (45.5 with AC plug) mm.
