PROGRAMMING AND TROUBLESHOOTING MANUAL
The SECURIKEY+ system is designed for use in vehicles equipped with
the factory installed Power Door Lock System
Topic
Form Number 128 - XXXX

Table of Contents

Pg.
2
2
4
6
7
8
9
9
10
7/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SECURIKEY+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audiovox SECURIKEY+

Summary of Contents for Audiovox SECURIKEY+

  • Page 1: Table Of Contents

    PROGRAMMING AND TROUBLESHOOTING MANUAL The SECURIKEY+ system is designed for use in vehicles equipped with the factory installed Power Door Lock System Table of Contents Topic Preparation for System Programming Programming New or Replacement Transmitters Testing the System Programming the Selectable Features Transmitter / Receiver Information Clearing Transmitter Codes from Memory Turning The Arm / Disarm Chirps On...

  • Page 2: Preparation For System Programming

    PREPARATION FOR SYSTEM PROGRAMMING: 1. CONNECTING COMPONENTS: CAUTION: THE SECURITY HARNESS MUST HAVE ALL VEHICLE CONNECTIONS INSTALLED PROPERLY AND ALL SECURITY COMPONENTS CONNECTED BEFORE CONNECTING THE VEHICLE’S BATTERY . FAILURE TO COMPLY WITH THIS CAUTION COULD RESULT IN SYSTEM FAILURE AND OR FAILURE TO PROGRAM PROPERLY.
  • Page 3 STEP 4 2 BEEPS CHANNEL 2 MEMORY MEMORY MEMORY MEMORY POSITION POSITION POSITION POSITION " UNLOCK " VALET SWITCH ON THEN OFF HORN SOUNDS Now press the UNLOCK button ( hold the button for 3 seconds until the horn sounds ) on all transmitters that you want to program ( up to 4 ), or continue on to the next step.

  • Page 4: Testing The System

    TESTING THE ALARM SYSTEM: Lock Button Unlock Button LED Light Green Button A. Test BOTH remote transmitters, one at a time. Press and release the "LOCK" button. If the LED light on the transmitters fails to glow, you need to check the transmitter battery. (Refer to the section on battery replacement in the Owner's Manual.) B.
  • Page 5 TESTING THE ALARM SYSTEM [CONTINUED]: E. DEFECTIVE OR LOST TRANSMITTER: I. INTRUSION TEST: 1. Press and release the "LOCK" button to arm the 1. Rearm the security system by pressing and system. Use the key to unlock and open the releasing the "LOCK"...

  • Page 6: Programming The Selectable Features

    PROGRAMMING THE SELECTABLE FEATURES: The SECURIKEY+ system offers a number of selectable features that can be changed, allowing you to custom fit the system to your customer. The following is a list of the features that are selectable and can be changed using the valet switch and any transmitter that is programmed to the system installed in the vehicle. FEATURE # FUNCTION 1 CHIRP...

  • Page 7: Transmitter / Receiver Information

    WHAT IS A RECEIVER CHANNEL ? The SECURIKEY+ control module includes a 6 Channel Receiver , and each channel can learn and memorize four different transmitter codes. Each receiver channel is reserved for a particular remote control function of the system. The chart shown below is a diagram of the actual configuration of the memory positions available in the SECURIKEY+ main control module.

  • Page 8: Clearing Transmitter Codes From Memory

    WHY IS THIS INFORMATION IMPORTANT ? Let's first consider that any SECURIKEY+5 transmitter code or button can be programmed into any one of the six receiver channels of the system. The system will allow you to program transmitter code 1 ( lock button ) into receiver channel 4 ( headlight activation ), but since the lock and unlock buttons are clearly marked with icons describing their function, these two buttons should always be pro- grammed into receiver channels 1 and 2.

  • Page 9: Turning The Arm / Disarm Chirps On

    TURNING THE ARM / DISARM CHIRPS ON: STEP 1 THEN THEN START WITH VALET SWITCH OFF TURN IGNITION KEY TO ON TURN IGNITION KEY TO OFF STEP 2 1 CHIRP = THEN CHIRPS ON HORN SOUNDS 1 CHIRP = CHIRPS ON WITHIN 5 SECONDS, VALET SWITCH ON AND THEN OFF 3 TIMES TURNING THE ARM / DISARM CHIRPS OFF: NOTE : Whenever the chirps are turned off, the 4 chirp intrusion indicator and 3 chirp defective zone...

  • Page 10: Troubleshooting

    TROUBLESHOOTING - Transmitters: SYMPTOM One or both of my transmitters doesn't work any more ( stopped working ). HELPFUL HINT : If a transmitter has been programmed to the system at one time, it will remain programmed. Disconnecting the vehicle's battery or removing the transmitter battery will not erase transmitter codes from the SECURIKEY+ system's memory.
  • Page 11 TROUBLESHOOTING - Horn / Chirps: My system does not chirp when Arming and Disarming. SYMPTOMS I cannot turn my chirps on ( or off ). The alarm will set, but will not sound when opening a door. HELPFUL HINTS : 1) The arm and disarm chirps are turned on and off by using the L.E.D.
  • Page 12 TROUBLESHOOTING: Reading the Connection Points at the 24 pin Main Alarm Connector : A. When checking the 24 pin main alarm connector, be sure that it is disconnected from the alarm control module. All other connections to the main alarm harness should remain connected. 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 24 PIN MAIN ALARM CONNECTOR...
