Schedule Management - NEC MP-01 Quick Reference Manual

Schedule Management

Schedule Management
Dialog box
Dialog box
Dialog box
①
Main Window
②
Dialog box
◆ Click [Schedule Management] in the main window.
◆ The <Schedule Management> dialog box will be displayed.
◆ Click "Schedule 01" in the "Schedule list".
◆ The <Schedule control properties> dialog box will be
displayed.
◆ Set the "Set time displayed in schedule settings" to "8:00 -
18:00".
◆ Click [Select Program].
◆ The <Program choice> dialog box will be displayed.
◆ The "sample program(s)" registered previously will be shown
in the list.
◆
Set the start and end times to "8:00 - 18:00".
◆ Click [OK] to confirm the setting.
USB Memory Procedures
11
