MS810 Laser Scanner

Product Reference Guide

Rev. A
Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS810 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unitech MS810

Summary of Contents for Unitech MS810

  • Page 1: Product Reference Guide

    MS810 Laser Scanner Product Reference Guide Rev. A Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 2: About This Manual

    Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 3: Support

    UTT (Taipei, Taiwan) http://www.unitech.com.tw APAC (Taipei, Taiwan) http://www.unitech-adc.com UTJ (Japan) http://www.unitech-japan.co.jp UTA (USA, Canada) http://www. ute.com UTA (Latin America) http://www.latin.ute.com UTI (Europe) http://www.unitech-europe.nl Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 4: Table Of Contents

    Introducing the MS810 ........
  • Page 5 Other Product Questions ........40 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 6: Introduction

    The MS810 is a powerful and reliable handheld scanner without compromise. It is compatible with USB and K/B interfaces, and numerous configurations. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 7: A Tour Of The Ms810

    If the barcode is not successfully read, the LED will show red and the beep will not sound. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 8: Laser Scan Engine Specifications

    10% to 85% relative humidity, non-condensing Storage Humidity: 5% to 95% relative humidity, non-condensing Light Level: Up to 36000 Lux Shock: 1.5m drop onto concrete Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 9: Decode Zone

    “dead zone” where decoding is difficult. Practice a few times to find what range of angles works best. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 10: Installation

    “Reset Configuration to Defaults” barcode. This will reset the scanner to its factory defaults settings in USB interface. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 11: Ps2 (K/B) Cable Connection

    “Reset Configuration to Defaults” barcode. This will reset the scanner to its factory defaults settings in PS/2 interface. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 12: Operating The Ms810

    Wipe the scanner window gently with a lens tissue or other material suitable for cleaning optical material. Do not spray water or other cleaning liquids directly onto the window. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 13: Bar Code Setup Menu

    GOOD READ BEEP TONE - RESET 014200 0B142 DECODE OPTIONS REVERSE IMAGE IMAGE DECODE OPTIONS REVERSE IMAGE – ENABLE - DISABLE 01391 01390 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 14: Code Id

    ID – AS A PREFIX 01400 01401 DECODE OPTIONS SEND BAR CODE DECODE OPTIONS SEND BAR CODE ID - RESET ID – AS A SUFFIX Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 15: Multi-Interface Functions

    LASER/CCD TIMEOUT – 5 SECONDS LASER/CCD TIMEOUT – 2 SECONDS 0134005 0134002 LASER/CCD PULSE RATE - 7 LASER/CCD PULSE RATE - 3 013507 013503 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 16: Pc Communication

    LANGUAGE KEYBOARD COUNTRY - USA KEYBOARD COUNTRY - GERMAN 0005000 0005010 KEYBOARD COUNTRY – FRANCE KEYBOARD COUNTRY - UNIVERSAL 0005009 0005025 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 17: Introduction

    CODE 11 - DISABLE 01261 01260 CODE 39 CODE 39 ENABLE CODE 39 DISABLE 00221 00220 FULL ASCII ENABLE FULL ASCII DISABLE 00231 00230 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 18: Symbologies On/Off

    CODABAR CODABAR - ENABLE CODABAR - DISABLE 00851 00850 INTERLEAVED 2 OF 5 I2OF5 - ENABLE I2OF5 - DISABLE 00961 00960 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 19: Industrial 2 Of 5

    Symbologies On/Off - 2 (cont.) INDUSTRIAL 2 OF 5 ID2OF5 - ENABLE ID2OF5 - DISABLE 01061 01060 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 20: Symbologies On/Off

    UPC-A DISABLE 00341 00340 UPC-E ENABLE UPC-E DISABLE 00351 00350 EAN-13 ENABLE EAN-13 DISABLE 00361 00360 EAN-8 ENABLE EAN-8 DISABLE 00371 00370 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 21: Symbologies Setup

    CODE 39 SEND START/STOP CHARS ENABLE DISABLE 00281 00280 CODE 39 ID CHARACTER ‘a’ CODE 39 ID CHARACTER ‘z’ 0031A 0031Z Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 22 Symbologies Setup - 1 (cont.) CODE 39 CODE 39 LASER/CCD REDUNDANCY CODE 39 LASER/CCD REDUNDANCY ENABLE DISABLE 00331 00330 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 23: Symbologies Setup

    - ENABLE - DISABLE 00841 00840 CODABAR CODABAR SEND START/STOP CHARS CODABAR SEND START/STOP CHARS - ENABLE - DISABLE 00861 00860 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 24 Symbologies Setup - 2 (cont.) CODABAR WIDE GAPS ALLOWED - CODABAR WIDE GAPS ALLOWED CODABAR ENABLE - DISABLE 00901 00900 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 25: Symbologies Setup

    I2OF5 ID CHARACTER – ‘i’ I2OF5 ID CHARACTER – ‘Z’ 0104i 0104Z I2OF5 LASER/CCD REDUNDANCY - I2OF5 LASER/CCD REDUNDANCY ENABLE - DISABLE 01051 01050 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 26: Industrial 2 Of 5

    ID2OF5 BAR START/STOP - ENABLE ID2OF5 BAR START/STOP - DISABLE 01071 01070 ID2OF5 BAR START/STOP - ENABLE ID2OF5 BAR START/STOP - DISABLE 0113j 0113Z Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 27: Symbologies Setup

    MSI LASER/CCD REDUNDANCY - ENABLE - DISABLE 01251 01250 UPC/EAN EXPAND UPC-E TO UPC-A ENABLE EXPAND UPC-E TO UPC-A DISABLE 00381 00380 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 28 EXPAND UPC-A TO EAN-13 ENABLE EXPAND UPC-A TO EAN-13 DISABLE 00391 00390 CONVERT EAN-13 TO ISBN ENABLE CONVERT EAN-13 TO ISBN DISABLE 00481 00480 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 29: Symbologies Setup - 5

    SEND EAN-8 CHECK DIGIT ENABLE SEND EAN-8 CHECK DIGIT DISABLE 00471 00470 UPC-A ID CHARACTER ‘b’ UPC-A ID CHARACTER ‘Z’ 0049b 0049Z Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 30 Symbologies Setup - 5 (cont.) UPC-E ID CHARACTER ‘c’ UPC-E ID CHARACTER ‘Z’ 0050c 0050Z EAN-13 ID CHARACTER ‘e’ EAN-13 ID CHARACTER ‘Z’ 0051e 0051Z Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 31: Symbologies Setup

    UPC/EAN SUPPLEMENTS – 5 DIGIT ONLY UPC/EAN SUPPLEMENTS – 2 & 5 DIGIT 00552 00553 UPC/EAN LASER/CCD REDUNDANCY UPC/EAN LASER/CCD REDUNDANCY ENABLE DISABLE 00541 00540 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 32: Edit Setup Bar Codes

    EDIT #1 - OFF 020001040000032 0B20001 EDIT – DISABLE FILTER OF ALL ‘-’ EDIT – FILTER ALL’-’ CHARACTERS CHARS 020000050000045 0B20000050000045 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 33 Edit Setup Bar Codes (cont.) EDIT – DISABLE INSERT LEADING EDIT - INSERT LEADING ZERO ZERO 020000060000000048 0B20000060000000048 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 34: Macro/Special Keys Setup Bar Codes

    SPECIAL KEY –MAP F3 TO ‘0’ MAPPING 0162048 0B162 SPECIAL KEY – DISABLE KEYPAD SPECIAL KEY – MAP KEYPAD ENTER TO ‘2’ ENTER MAPPING 0182050 0B182 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 35: Termination String Setup Bar Codes

    0B20202 STRING – CODE 39 TERMINATION CHAR STRING – CODE 39 TERMINATION CHAR - TAB – TAB - REMOVED 0202001020$09 0B202001020$09 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 36 Termination String Setup Bar Codes (cont.) STRING ALL CODES POSTAMBLE STRING ALL CODES PREAMBLE - STX - ETX 0202002000$02 0202003000$03 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 37: Factory Default Settings

    Code 39 Enable Code 32 Disable CODABAR Enable ITF 2 of 5 Enable Disable Code 93 Enable Code 128 Enable EAN-128 Disable Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 38: Troubleshooting

    Try scanning test symbols of the same barcode type. Distance between scanner and barcode Move the scanner closer or further from is incorrect. the barcode. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 39 Lock mode to send the data properly. numeric data as keypad numerics, or setting the keyboard country mode to UNIVERSAL. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.

  • Page 40: Other Product Questions

    For any other technical issues, please contact your regional Unitech office for support. Contact information can be found on their websites as listed on Page 3 of this Product Reference Guide. Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
  • Page 41 Copyright 2007 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
