4 Wheel makes it ideal for larger gardens. Engine Mountfield RM55ES OHV Engine Capacity 160cc Powered by a Mountfield RM55ES OHV Net Power Output 2.51kW @ 2900rpm engine it has the added convenience of Starting Method Electric Key electric key start simply turn a key to...
Please Read These Instructions Before Using Your Mower Operating Instructions for model SP536 & SP536ES Lawnmowers with Mountfield RM55 & RM55ES engines Product Codes: 299265448/BQ 299325448/BQ Call our Helpline if you have any problems:- 0845 600 2912 Open from 9:00am to 5:00pm Monday to Saturday...
ITALIANO (Istruzioni Originali) - Norme di sicurezza..................4-7 - Funzionamento....................8-10 - Risoluzione problemi...................11 ENGLISH (Translation of the original instructions (Istruzioni Originali) - Safety precautions..................12-15 - How to get mowing ...................16-18 - Fault Finding....................19 GUARANTEE....................20...
Geazie per aver acquistato un rasaerba Mountfield. Questa macchina garantirà molti annI di affidabile e sicuro lavoro se utilizzata secondo le seguenti istruzioni. Preghiamo di leggere e capire attentamente le istruzioni di utilizzo prima di usare il rasaerba, eventuali omissioni potrebbe causare danni a persone o alla macchina.
Page 6
Comando acceleratore (posizione: ruota posteriore) Manopole fissaggio Tappo riempimento olio manico /Astina di livello (posizione: lato posteriore del motore) Motore Sacco di raccolta Parasassi (Batteria posizionata sotto qui nel modello SP536ES) Tappo serbatoio carburante (Posizione: lato posteriore motore) Candela Chassis...
Page 7
Le seguenti norme di sicurezza devono essere osservate ad ogni utilizzo. Preghiamo di leggerle attentamente. ADDESTRAMENTO 1) Leggere attentamente le istruzioni. Prendere familiarità con i comandi e con un uso appropriato del rasaerba. imparare ad arrestare rapidamente il motore. 2) Utilizzate il rasaerba per lo scopo al quale è destinato, cioè per il taglio e la raccolta dell’erba. Qualsiasi altro impiego può...
Page 8
10) Fermare la lama se il rasaerba deve essere inclinato per il trasporto, nell’attraversare superfici non erbose, e quando il rasaerba viene trasportato da o verso l’area che deve essere tagliata. 11) Non azionare mai il rasaerba se i ripari sono danneggiati, oppure senza il sacco raccoglierba o il parasassi 12) Non modificare le regolazioni del motore, e non fare raggiungere al motore un regime di giri eccessivo.
FUNZIONAMENTO Il vostro rasaerba Mountfield non contiene ne benzina ne olio motore, questi vanno aggiunti prima dell’accensione. L’utilizzo del rasaerba con un’insufficente quantità di olio può causare seri danni al motore e invalidare la vostra garanzia. NON INCLINARE IL RASAERBA SUL SUO FIANCO, LA FUORIUSCITA DI OLIO POTREBBE DANNEGGIARE IL FILTRO ARIA.
Page 10
Non rimuovere la fune dalla guida. • Mod. SP536ES: ruotare la chiave di avviamento. A motore avviato rilasciare la fune, portare gradualmente la leva dell’accelleratore dalla posizione “CHOKE” •...
Page 11
Nel caso la lama fosse danneggiata deve essere sostituita. Il kit di sostituzione della lama è disponibile c/o il vostro rivenditore Mountfield. Il codice del kit è MS1196. In caso di dubbi fare riferimento al vostro rivenditore o contattare il servizio telefonico 0845 600 2912. Le lame devono sempre essere marchiate 81004365/3.
(lato operatore) svuotando la benzina in un apposito contenitore Svuotare il carburatore svitando l’apposita vite, e poi riavvitare. Ricaricare la batteria per 24 ore (SP536ES) e riporla lontano dal rasaerba in un luogo fresco a secco. RISOLUZIONE PROBLEMI...
Thank you for purchasing a Mountfield lawnmower. This machine will give you many years of safe and reliable service if operated in accordance with these instructions. Please read and understand these Operating Instructions before using your mower, failure to do so could result in personal injury or damage to the equipment.
Page 14
Throttle Control (located at rear right wheel) Handle Securing Oil Filler Cap/Dipstick Knob (located at rear of engine) Engine Grass Collector Delector Flap (Battery located under here on SP536ES) Fuel Filler Cap (located at rear of engine) Spark Plug Cutter Deck...
Page 15
The following safety precautions must be observed at all times. Please read them very carefully. TRAINING 1) Read the instructions carefully. Get familiar with the controls and proper use of the equipment. Learn how to stop the engine quickly. 2) Only use the lawnmower for the purpose for which it was designed, i.e. for cutting and collecting grass.
Page 16
Exercise extreme caution when changing direction on slopes. Do not mow on slopes of more than 20 degrees. Exercise extreme caution when pulling the lawn mower towards you. 0) Stop the blade if the lawnmower has to be tilted for transportation when crossing surfaces other than grass, and when transporting the lawnmower to and from the area to be mown.
Then click the edge into the groove in the top starting 5-7mm from an end (Figure2). Figure 2 5-7 mm BA TT ERY CARE (SP536ES o nly) Before initial use charge the battery for 24 hours using the battery charger supplied with the mower and then leav e it to rest for 12 hours.
Page 18
Manual start (SP536) - pull the starter cord with a strong smooth pull. Do not remove the pull cord from the guide. Electric start (SP536ES) - turn the starter key. When the engine starts move the throttle control from “Choke” to the “Fast” position.
Page 19
Drain the carburettor by loosening the drain screw, retighten the drain screw. Charge the battery for 24 hours (SP536ES) and store away from the mower in a cool, dry place.
FAULT FINDING CERTIFICATE OF CONFORMITY A certificate of conformity is enclosed with the documentation as separate document. An EXAMPLE is shownbelow. R OB LEM Che ck th ere is ample clean , fre sh fue l in the tan k. gine w ill not start Che ck th e cutte r blade is not fo uling the g round p re venting free ro tatio n.
All repairs must be carried out by an authorised Mountfield dealer. Delivery and collection of the machine is the owner’s responsibility and not covered under the terms of this guarantee.
