X-Digital System X-Digital Systems XDS Quick Start Manual page 7

NOTE: Wiring pinout for the RELAY A port is the same as on the StarGuide receiver
with Westwood One Netcue Card.
The pinouts for the DB-37 connectors are:
RELAY A - DB37M
Pin Signal
1 RLY1A
2 RLY2A
3 RLY3A
4 RLY4A
5 GND
6 RLY5A
7 RLY6A
8 RLY7A
9 RLY8A
10 GND
11 RLY9A
12 RLY10A
13 RLY11A
14 RLY12A
15 NQ Txd
16 RLY13A
17 RLY14A
18 RLY15A
19 RLY16A
If you or your automation vendor has developed a program that can read Westwood
One Netcues directly, you may get the Netcue serial stream from pins 15 and 10 on the
Relay A port on your XDS receiver (see pinout above). The "NQ TxD" pin is RS-232
data with no flow control or handshaking. Baud rate is set by default to 9600 bps 8N1.
THREE CHARACTER NETCUES:
If you currently use a Netcue/Data card in your Starguide receiver, any 3-character
Netcue that Westwood One sends out can be mapped to any contact closure you wish.
Contact
our Technical Services department or contract Help Desk to help you map your existing
Netcues to the same relay pins on one of the DB-37 connectors on your new XDS
receiver.
2. VERIFY PROGRAMMING AND ACTIVATE
In the XDS system each program, not each channel, is permissioned and labeled for
station use. Therefore, instead of tuning to a channel to find a program, you will
Revision J 9/30/2014
Signal Pin
RLY1B 20
RLY2B 21
RLY3B 22
RLY4B 23
GND 24
RLY5B 25
RLY6B 26
RLY7B 27
RLY8B 28
RLY9B 29
RLY10B 30
RLY11B 31
RLY12B 32
GND 33
RLY13B 34
RLY14B 35
RLY15B 36
RLY16B 37
R830000-1060
RELAY B - DB37M
Pin Signal
1 RLY1A
2 RLY2A
3 RLY3A
4 RLY4A
5 GND
6 RLY5A
7 RLY6A
8 RLY7A
9 RLY8A
10 GND
11 RLY9A
12 RLY10A
13 RLY11A
14 RLY12A
15 NC
16 RLY13A
17 RLY14A
18 RLY15A
19 RLY16A
Quick Start Guide, XDSPRO Receiver
Page 7 of 11
Signal Pin
RLY1B 20
RLY2B 21
RLY3B 22
RLY4B 23
GND 24
RLY5B 25
RLY6B 26
RLY7B 27
RLY8B 28
RLY9B 29
RLY10B 30
RLY11B 31
RLY12B 32
GND 33
RLY13B 34
RLY14B 35
RLY15B 36
RLY16B 37
