X-Digital System X-Digital Systems XDS Quick Start Manual page 6

Assigning a Static IP address to the WAN Port:
If you elect to connect your receiver in a firewall zone called a "DMZ"
(demilitarized zone) or '"Outside" the firewall where it can see the internet
directly, connect your network cable to the receiver's WAN port. You must
assign a static IP WAN Address, WAN Subnet, and Gateway. Follow the
"Assigning a Static IP address to a LAN Port" instructions above to go to the
appropriate WAN menus and change settings as desired.
NOTE: If your network requires the use of a proxy server, please refer to the
online user's guide located at your affiliate's website. Refer to Section 2 on page
7 for instructions on how to login to you your website.
B. Test connection to the Westwood One NOC
o At the main screen with the Cumulus Media Networks logo, press the SET
key, then the left or right arrow keys to reach Setup. Press SET.
o Press the left or right arrow keys to reach Network. Press SET.
o Press the left or right arrow keys to TEST NOC. Press SET.
o Press the NOC softkey to perform the test.
The test will take a minute or two. You will get a SUCCESFULLY CONNECTED
TO NOC message if your IP settings are correct. Otherwise you will get a
CANNOT CONNECT TO NOC message and you will need to adjust your IP
settings (on the receiver, or in your network's switches, routers or firewall) until
the receiver can connect to the NOC.
To troubleshoot, you can use the PING softkey to verify your receiver can locally
connect to your network gateway.
1.4 AUTOMATION RELAY CLOSURES
There are two DB-37 connectors on the rear panel which together contain a total of 32
mappable relay (or contact) closures to drive your station automation.
Your XDS receiver is delivered with a parts kit including two mating DB-37 connectors
with shells.
Revision J 9/30/2014 R830000-1060
Page 6 of 11
Quick Start Guide, XDSPRO Receiver
