o At the main screen with the Cumulus Media Networks logo, press the SET
key, then the left or right arrow keys to reach Setup. Press SET.
o Press the left or right arrow keys to reach Tuner. Press SET.
o Press the left or right arrow keys to reach Frequency. Press SET.
o Use the four arrow keys and the SET key to set the frequency to
01000500 kHz
o Press the left or right arrow keys to reach Symbol Rate. Press SET. Use
the four arrow keys and the SET key to set the symbol rate to
09259574 sps
The XDSPRO receiver should lock. (Green SIGNAL LED will illuminate
steadily).
If this XDS receiver is designated to supply DC power to the LNB at your dish, you
can turn on the LNB voltage on the XDS receiver front panel menu as follows:
• Make sure your downlink LNB is connected to the XDS receiver
• Apply AC power to the receiver
o From the main screen with the Cumulus Media Networks logo, press the SET
key, then press the left or right arrows to reach Setup. Press SET.
o Press the left or right arrows to reach Tuner. Press SET.
o Press the left or right arrows to reach LNBV, Press SET and turn the LNB
Voltage on.
If the front panel of your XDS receiver displays flashing red
lights, this indicates all Activation and Installation steps have
not been completed and/or your XDS receiver is not connected
to the internet. All Activation and Installation steps, including
your internet connection, must be completed or you will NOT
receive Westwood One programming. Your XDS receiver must
ALWAYS be connected to the internet 24/7/365.
Revision J 9/30/2014 R830000-1060
Page 3 of 11
Quick Start Guide, XDSPRO Receiver
