8.10.5 PCM to PCM (Synchronous Sample Rate Converter) Performance

The following specifications are unweighted and apply to all combinations of input and output
rates unless otherwise stated.
Absolute gain accuracy: -0.05dB
All input and output rates except 32kHz:
THD+n (997Hz, -1dBFs): <-130dB (0.000032%)
Dynamic range (997Hz, -60dBFS): >130dB
Frequency response:
-0.05dB: 0Hz...20kHz
-3dB: 0Hz...45% of lowest fs
Input and/or output at 32kHz:
THD+n (997Hz, -1dBFs): <-126dB (0.00005%)
Dynamic range (997Hz, -60dBFS): >128dB
Frequency response:
-0.05dB: 0Hz...14.5kHz

8.10.6 DB25 Connector

I/O Impedance: 75Ω
Output carrier amplitude (loaded): 3.6V p-p
Pinout:
25-way 'D' pin
14
15
16
17
18
19
20
21
22
10
23
11
24
12
25
13
© Prism Media Products Limited, 2001-2005
Signal
1 DSD Input 1
DSD Input 2
2 GND
DSD Input 3
3 DSD Input 4
GND
4 DSD Input 5
DSD Input 6
5 GND
DSD Input 7
6 DSD Input 8
GND
7 DSD Output 1
DSD Output 2
8 GND
DSD Output 3
9 DSD Output 4
GND
DSD Output 5
DSD Output 6
GND
DSD Output 7
DSD Output 8
GND
CLK Output
Module Reference - Revision 1.01
Tentacle
Blue "1"
Blue "2"
Screen (1 & 2)
Blue "3"
Blue "4"
Screen (3 & 4)
Blue "5"
Blue "6"
Screen (5 & 6)
Blue "7"
Blue "8"
Screen (7 & 8)
Red "1"
Red "2"
Screen (1 & 2)
Red "3"
Red "4"
Screen (3 & 4)
Red "5"
Red "6"
Screen (5 & 6)
Red "7"
Red "8"
Screen (7 & 8 & CLK)
Black
Page 3.48
