Prism Sound ADA-8XR Multi-channel A/D D/A Converter
The upper left-hand corner of these menus identifies the Module Slot (e.g. 'AO1'), followed by
an abbreviated indicator of the module type, in this case 'Lin' to indicate Line Output.
For more information about the location of these menus within the overall Menu System,
descriptions of the different menu types, key definitions etc. see the Firmware Reference.

4.4.1 AO Line Level menu

AO1 Lin:+18.0dBu
[Set dBu=0dBFS]
The AO Line Level menu is a Per-Channel Selection menu. The output line-up adjustment is
specified in terms of the analogue output amplitude which corresponds to the peak handling
level of the D/A converter (i.e. 0dBFS). The user may adjust the line-up level for each of the
eight channels, over the range 0dBFS=+5.0dBu to 0dBFS=+24.0dBu, in 0.5dBu steps.
NOTE for Pro Tools users: the ADA-8XR nomenclature for analogue line-up varies from that
used by Pro Tools. Refer to section 6 for more details.

4.4.2 AO Line Trim menu

AO1 Lin:+0.00dB
[Set dBu=0dBFS]
The AO Line Trim menu is a Per-Channel Selection menu. The user may finely trim the line-
up level for each of the eight channels by ±0.5dBu in 0.05dBu steps. This control is
supplementary to the AO Line Level menu.

4.5 Module Dependent Factory Default Stores

Several of the Factory Default Stores (which include D/A Paths) depend on the fitment of an
analogue output module of some kind for correct operation (as described in the Firmware
Reference). If no analogue output module is available, loading these Stores results in any
available output module being assigned to the 'analogue output' Path, or no output module
being assigned if there is none available.

4.6 Specifications

Unless otherwise stated, all performance specifications are rms, unweighted, band-limited
20Hz-20kHz, sampling at 96kHz, wordlength 24-bits, analogue I/O line-up at 0dBFS=+18dBu.
Electronically-balanced outputs on male XLR connectors (pin 2 hot)
Differential input impedance: 50
Full-scale output range (software controlled):
Range: +5dBu..+24dBu in 0.5dB steps
Trim: ±0.5dB in 0.05dB steps
Absolute gain accuracy: ±0.05dB
Output balance: >54dB
THD+n (997Hz, -1dBFS): -102dB (0.0007%) typical
Dynamic range (997Hz, -60dBFS): 108dB typical
IMD (SMPTE/DIN, 60Hz at -3dBFS and 7kHz at -12dBFS): <-94dB
Maximum aharmonic spurium: (997Hz, -1dBFS): <-130dBFS
© Prism Media Products Limited, 2001-2005
Module Reference - Revision 1.01
Page 3.14
