Summary of Contents for Radio Shack 200 Ch VHF/Air/UHF Home Scanner

  • Page 1 Cat. No. 20-422 OWNER’S MANUAL Please read before using this equipment. 200CH VHF/Air/UHF Home Scanner with Scanner Control Protocol and WX Alert...
  • Page 2 FEATURES Your RadioShack 200Ch VHF/Air/UHF Ten Monitor Memories — let you tem- Home Scanner lets you in on all the ac- porarily save ten frequencies located tion! This scanner gives you direct ac- during a frequency search, so you can cess over 23,000...
  • Page 3 Key Confirmation Tones — the scan- This table shows the preset frequency ner sounds a tone when you perform an steps your scanner uses for each fre- operation correctly and sounds an error quency range. tone if you make an error. Frequency Range (MHz) Step (kHz)
  • Page 4: Fcc Notice

    FCC NOTICE most every transmission your scanner can receive. However, there are some transmissions you should never inten- Your scanner might cause TV or radio tionally listen to. These include: interference even when it is operating properly. To determine whether your •...
  • Page 5: Table Of Contents

    CONTENTS Preparation ......................6 Removing the Display Protector ................. 6 Connecting an Antenna ..................6 Connecting Power ....................7 Connecting an External Speaker ................ 8 Connecting an Earphone or Headphones ............8 Understanding Your Scanner ................9 A Look at the Front Panel ................... 9 A Look at the Display ..................
  • Page 6: Preparation

    PREPARATION This scanner is designed for use in the ception of the transmissions you want to home as a base station. You can place it hear, adjust the antenna’s length. on any flat surface such as a desk, shelf, or table. Frequency Antenna Length (MHz)
  • Page 7: Connecting Power

    adapter. Your local RadioShack store Cautions: carries a wide variety of coaxial antenna You must use a Class 2 cable and connectors. power source that supplies 10V AC and delivers 300 Once you choose an antenna, follow the mA. Its plug must fit the scanner’s mounting instructions supplied with the jack.
  • Page 8: Connecting An External Speaker

    CONNECTING AN Insert the earphone’s or headphones’ plug into the jack on the back of EXT. SP. EXTERNAL SPEAKER the scanner. You can connect an optional external speaker with a -inch (3.5-mm) plug to the scanner. Use an 8-ohm external speaker that can handle at least 2.5 watts of power.
  • Page 9: Understanding Your Scanner

    UNDERSTANDING YOUR SCANNER A LOOK AT THE FRONT PANEL Turns the scanner on or off and adjusts the volume. VOLUME Adjusts the scanner’s squelch. SQUELCH Sets the search direction. Searches a band you select. BAND Programs a 2-second delay for the selected channel; sets a DELAY delay for all active frequencies during a search.
  • Page 10: A Look At The Display

    Each key has a single-digit label, and the – keys 1–9, 0 also have a range of numbers. Use the digits on the keys to enter the numbers for a channel or a frequency. Use the range of numbers above the key ( , for example) to se- 61–80 lect or deselect the channels in a channel-storage bank.
  • Page 11 Appears when the priority feature is turned on. (lockout) Appears when you lock out channels or skip a frequency, or when you manually select a channel or frequency that is locked out or skipped . Appears when the scanner is scanning or searching when you have programmed a 2-second delay .
  • Page 12: Understanding Banks And Bands

    UNDERSTANDING BANKS AND BANDS You can store frequencies into either a MONITOR MEMORIES programmable memory location called a channel, or a temporary memory loca- Monitor memories are temporary stor- tion called a monitor memory. You can age areas where you can store up to ten store a frequency in each of the scan- frequencies during a search while you ner’s channels (up to 200) and up to 10...
  • Page 13 This table shows the frequency band ranges displayed by the scanner and the typical usage, frequency coverage, and step for each. Displayed Frequency Coverage Step Frequency Typical Usage (MHz) (kHz) Band Range 10-Meter Amateur Radio, VHF 29.000 to 54.000 29-54 Lo, 6-Meter Amateur Radio Aircraft 108.000 to 136.975...
  • Page 14: Operation

    OPERATION TURNING ON THE • if the scanner is dropped or sub- jected to an electrical shock SCANNER/SETTING VOLUME AND SQUELCH Caution: This procedure clears all the information you have programmed into 1. Turn fully VOLUME SQUELCH the scanner. Use this procedure only counterclockwise.
  • Page 15: Searching For And Temporarily Storing Active Frequencies

    SEARCHING FOR AND Follow these steps to manually store a frequency into a channel. TEMPORARILY STORING 1. If the scanner is scanning, press ACTIVE FREQUENCIES MANUAL You can search for transmissions using 2. Using the number keys, enter the either a band or direct search, then tem- channel number where you want to porarily store the frequencies for those store a frequency.
  • Page 16: Listening To Monitor Memories

    2. To manually search the band, press the search. Press • to enter the dec- after the scanner starts auto- imal point. HOLD matically searching the frequen- 3. Press to search up or down cies. The scanner displays (hold), from the selected frequency. , and a frequency within the (direct) and appear, and the...
  • Page 17: Moving A Frequency From A Monitor Memory To A Channel

    You can also select a monitor memory DELETING A FREQUENCY by repeatedly pressing until MONITOR FROM A CHANNEL the desired monitor memory appears. 1. If the scanner is scanning, press Note: To listen to the monitor memories, MANUAL the priority channel feature must be 2.
  • Page 18: Manually Selecting Achannel

    Notes: • You can manually select any chan- nel in a bank, even if the bank is turned off. • You cannot turn off all ten banks. • The scanner skips channels that have been locked out (see “Skipping Frequencies/Channels” on Page 19. MANUALLY SELECTING A CHANNEL You can continuously monitor a specific...
  • Page 19: Special Features

    SPECIAL FEATURES DELAY SKIPPING FREQUENCIES/ CHANNELS Many agencies use a two-way radio sys- tem that might have a pause of several You can scan channels faster by skip- seconds between a query and a reply. ping ones that have a continuous trans- To avoid missing a reply, you can pro- mission, such as a weather channel.
  • Page 20: Priority

    Note: If you turned the key tone off (see scans, it checks the priority channels in “Turning the Key Tone On or Off” on each selected bank for activity every 2 Page 21), the scanner does not beep seconds. when you hold down S/S-LOCKOUT Notes: •...
  • Page 21: Listening To The Weather Band

    To turn off the priority feature, press 2. Press appears and the PRI- ALERT disappears. broadcast turns off. ORITY When a severe weather emergency sig- Note: If you are scanning more than one nal is broadcast, the scanner sounds a bank in which a priority channel has loud alarm (regardless of the volume been programmed, the scanner stops...
  • Page 22: A General Guide To Scanning

    A GENERAL GUIDE TO SCANNING Your scanner’s reception is mainly “line-of-sight.” You usually cannot hear stations that are beyond the horizon. GUIDE TO FREQUENCIES Ham Radio Frequencies Ham radio operators often broadcast emergency information when other means of communication break down. The following chart shows the voice frequencies that you can monitor: Wavelength (Meters) Voice (MHz)
  • Page 23: Guide To The Action Bands

    GUIDE TO THE ACTION BANDS Typical Band Usage VHF Band (29.00-300.00 MHz) Low Range 29.00–50.00 MHz 6-Meter Amateur 50.00–54.00 MHz U.S. Government 137.00–144.00 MHz 2-Meter Amateur 144.00–148.00 MHz High Range 148.00–174.00 MHz UHF Band (300 MHz-3.0 GHz) U.S. Government 406.00–420.00 MHz 70-cm Amateur 420.00–450.00 MHz Low Range...
  • Page 24: Band Allocation

    BAND ALLOCATION Use the following listing of the typical services within your scanner’s frequency cover- age to assist you to decide which frequency ranges to scan. These frequencies are subject to change, and might vary from area to area. For a more complete listing, re- fer to the “Police Call Radio Guide including Fire and Emergency Services,”...
  • Page 25 TSB ..........Trunked Systems TVn .
  • Page 26 152.030–152.240 ..........TELB 152.270–152.480 .
  • Page 27: Frequency Conversion

    70-cm Amateur Band (420–450 MHz) 420.000–450.000 ..........HAM Low Band (450–470 MHz) 450.050–450.925 .
  • Page 28: Troubleshooting

    TROUBLESHOOTING If your scanner is not working as it should, these suggestions might help you elimi- nate the problem. If the scanner still does not operate properly, take it to your local RadioShack store for assistance. SYMPTOM SUGGESTION Scanner is on, but will not scan. Be sure is adjusted proper- SQUELCH...
  • Page 29: Care And Maintenance

    CARE AND MAINTENANCE Your RadioShack 200Ch VHF/Air/UHF Home Scanner is an example of superior de- sign and craftsmanship. The following suggestions will help you care for your scan- ner so you can enjoy it for years. Keep the scanner dry. If it gets wet, wipe it dry immediately. Liquids might contain minerals that can corrode the electronic circuits.
  • Page 30: Specifications

    SPECIFICATIONS Frequency Coverage: VHF Lo ................. 29.7 50 MHz (in 5 kHz steps) – Amateur Radio ............. 29 29.7 MHz (in 5 kHz steps) – 54 MHz (in 5 kHz steps) – 148 MHz (in 5 kHz steps) – 450 MHz (in 12.5 kHz steps) –...
  • Page 31 Antenna Impedance ..................50 Ohms Audio Power .................. 840 mW Maximum Built-In Speaker ......... 2 Inch (57 mm), 8-Ohm, Dynamic Type AC Adapter ....................10 Volts AC × 9 × 6 Inches (60 × 238 × 170 mm) Dimensions (HWD) ......2 Weight (without AC Adapter) ............
  • Page 32 Limited One-Year Warranty This product is warranted by RadioShack against manufacturing defects in material and workman- ship under normal use for one (1) year from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, Ra- dioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED...
