PLEASE CHECK THE FOLLOWING BEFORE CALLING FOR SERVICE:

1. Power Supply:

Check the power plug is properly connected to a suitable wall outlet.

Check the line fuse/circuit breaker is functioning properly.

2. When the door is opened, does the oven lamp turn on?

3. Place a cup of water (approx. 150 ml) in the oven and close the door securely.

Programme the oven for one minute on 900 W microwave power and start the oven.

Does the oven lamp come on?

Does the turntable rotate?

NOTE: The turntable turns in either direction.

Does the ventilation work?

(Place your hand over the ventilation openings and check for air flow.)

After 1 minute does the signal sound?

Does the cooking in progress indicator go off?

Is the cup of water warm after the above operation?

4. Take the cup of water out of the oven and close the door. Set the GRILL cooking mode using the top and

bottom grills for 3 minutes.

After 3 minutes do both GRILL heating elements become red?

If you answer "NO" to any of the above questions, call a Service Technician appointed by SHARP and report

the results of your check. See inside back cover for details of address.

IMPORTANT: If the display shows nothing even if the power supply plug is properly connected, the energy save

mode may be in operation. Open and close the oven door to operate the oven. See GB-5.

NOTE:

1. If you cook the food over the standard time with only the same cooking mode, the power of the oven will

lower automatically to avoid overheating. (The microwave power level will be reduced and the grill heating

elements will begin to light on and off.)

TOP GRILL

BOTTOM GRILL

TOP and BOTTOM GRILL

Dual 2

Dual 3

2. After the GRILL, DUAL, CONVECTION, INSTANT ACTION and AUTOMATIC OPERATION (except AUTO

DEFROST), the cooling fan will run and "NOW COOLING" will appear on the display. Also, when you

press the STOP key and open the door during the GRILL, DUAL, CONVECTION, INSTANT ACTION and/or

automatic cooking (except AUTO DEFROST), the cooling fan will run; you may, therefore, feel air blowing

from the ventilation openings.

3. If the display shows messages for "DEMO MODE", or the time in the display is counting down very rapidly,

the oven may be set in the demo mode. To cancel the demo mode, unplug the oven from the wall outlet and

replug.

3:59 PM

Page 25

Cooking mode

Microwave 900 W cooking

Grill cooking

Microwave 900W

Microwave 90 - 630W

Microwave 900W

Microwave 90 - 630W
