OPERATING PROCEDURES AND SAFETY INSTRUCTIONS
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER NO USER FRIENDLY PARTS
Battery Charger
Sealed or Valve Regulated
Lead Acid Batteries
Models: PSC 6300A, PSC-61000A,
PSC 12300A and PSC 12800A
CAUTION
THIS UNIT SHOULD NOT BE USED IN OUTDOOR APPLICATIONS.
EXPOSURE TO MOISTURE MAY RESULT IN FIRE OR SHOCK HAZARD
1
Advertisement
Table of Contents
Related Manuals for Power-Sonic PSC 6300A
Summary of Contents for Power-Sonic PSC 6300A
- Page 1 Battery Charger Sealed or Valve Regulated Lead Acid Batteries Models: PSC 6300A, PSC-61000A, PSC 12300A and PSC 12800A OPERATING PROCEDURES AND SAFETY INSTRUCTIONS CAUTION: CAUTION TO PREVENT THE RISK OF ELECTRIC SHOCK, DO THIS UNIT SHOULD NOT BE USED IN OUTDOOR APPLICATIONS.
- Page 2 PSC-6300A, PSC-61000A, PSC-12300A and PSC-12800A CHARGERS IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This document contains important safety and operating instructions for Models PSC-6300A, PSC- 61000A, PSC-12300A and PSC-12800A battery chargers. Before using the battery charger, please read all instructions and cautionary markings on the battery charger, the battery, and the product using the battery.
- Page 3 GENERAL DESCRIPTION This unit is a two stage, constant voltage battery charger with current limiting, current fold back, and automatic temperature compensation of the output voltage. It is protected against shorting the out- put terminals and reversing the output terminals on a battery. Various output cables are available. There is one indicator light.
- Page 4 CHARGING NOTES AND TIPS For safer and more efficient charging, batteries should be charged with higher voltages when cold and lower voltages when warm. This unit incorporates automatic temperature compensation of the output voltage. It will increase the charge voltage in cold conditions and decrease charge voltage in warm conditions.
- Page 5 Check the open circuit voltage of the battery to see if it has any shorted cells - there should be about 2.15 V/cell for a properly charged battery (divide the battery voltage by two to get the number of cells). If the battery voltage looks correct then you may be trying to charge a battery which has too large a capacity for the charger (see charging notes and tips).
- Page 6 PSC-12800A Charge Amps (lmax) 800 mA ± 2& Charge Voltage 13.68 ± 0.12 Switch Amps (lsw) 60 mA ± 5% Max. Continuous Load w/ Battery 400mA CHARGING BATTERIES Our Technical Manual provides detailed information about charging procedure. A copy can be downloaded from our website: www.power-sonic.com (go to Technical and click on the tab at the right hand side of the page).
